🏷️ Basic Information Identification Make: Harley-Davidson Model Family: Dyna Covered Models: • 2017 Harley-Davidson Street Bob (FXDB) • 2017 Harley-Davidson Low Rider (FXDL) • 2017 Harley-Davidson Low Rider S (FXDLS) • 2017 Harley-Davidson Fat Bob (FXDF) • 2017 Harley-Davidson Wide Glide (FXDWG) Model Year: 2017 Codes Product Type: OEM Factory Parts Catalog 👋 Introduction Market Position Product Role: Essential resource for owners, technicians, and parts departments seeking genuine Harley-Davidson replacement parts for the 2017 Dyna lineup. Critical for maintaining vehicle integrity and performance. Competitive Analysis Value Proposition: Provides the most accurate and complete listing of OEM part numbers, ensuring correct fitment and quality. Superior to generic aftermarket catalogs for guaranteed compatibility and adherence to manufacturer specifications. Key Features Catalog Benefits: • Access to correct Harley-Davidson part numbers • Detailed exploded view diagrams • Cross-referencing for component relationships • Identification of superseded or obsolete parts (where applicable) • Crucial for accurate ordering and inventory management 📋 Manual Details Coverage Areas Coverage Scope: Comprehensive parts listing for all major mechanical, electrical, and cosmetic components across the specified 2017 Dyna models. Model Specific Variations: The catalog accounts for variations in parts between the different Dyna models (Street Bob, Low Rider, Low Rider S, Fat Bob, Wide Glide), highlighting model-specific components. Page Count Total Pages: 418 Manual Type Manual Classification: Parts Catalog Language Language Type: English Format File Format: PDF 📖 Manual Coverage Systems Covered Mechanical Systems: • Engine (Twin Cam 103B) • Transmission (Cruise Drive 6-Speed) • Primary Drive • Clutch • Braking System (Front & Rear) • Suspension (Front Forks, Rear Shocks) • Chassis & Frame • Wheels & Tires • Fuel System • Exhaust System • Cooling System (Oil Cooling) Electrical Systems: • Ignition System • Lighting (Headlight, Taillight, Turn Signals) • Instrumentation • Wiring Harnesses • Battery & Charging System • Starter System Bodywork And Accessories: • Fuel Tank • Fenders (Front & Rear) • Seat • Handlebars & Controls • Foot Controls • Footpegs & Floorboards • Mirrors • Exhaust Shields • Covers (Engine, Primary, Transmission) • Mounting Hardware • Decorative Trim Procedures Included Catalog Functionality: Identification and ordering of genuine Harley-Davidson replacement parts. Detailed exploded diagrams for visual reference of component assembly and part numbers. Part Number Reference: Every part is listed with its unique Harley-Davidson part number, critical for accurate ordering and inventory control in dealerships and repair shops. Technical Depth Diagnostic Capabilities: Not a diagnostic or repair manual; focuses exclusively on part identification, part numbers, and assembly breakdown. Limited to identifying the correct component for replacement. Assembly Complexity: Diagrams illustrate the assembly of sub-systems, allowing for understanding of how components fit together, which aids in identifying missing or incorrectly installed parts. 📊 Manual Specifications File Format Digital Format: PDF Searchability: PDF format generally allows for text searching, provided the PDF is text-based and not an image scan. This greatly enhances the ability to locate specific parts quickly. Print Quality Readability: Designed for digital viewing, with clear diagrams and text. Printability is dependent on user's printer capabilities. Binding Type Digital Binding: N/A (Digital File) Paper Type Digital Paper Emulation: N/A (Digital File) ⚙️ Engine Specifications Primary Engine Engine Family: Harley-Davidson Twin Cam 103B Engine Configuration: Air-cooled, 45-degree V-twin Displacement: 1690 cc (103 cubic inches) Bore X Stroke: 3.875 in x 4.375 in (98.4 mm x 111.1 mm) Valvetrain: Overhead valves (OHV), two valves per cylinder, pushrod actuated Performance Horsepower Rating: Approximately 78 hp @ 5010 rpm (claimed) Torque Rating: Approximately 102 lb-ft @ 3500 rpm (claimed) Fuel System Fuel Delivery: Electronic Sequential Port Fuel Injection (ESPFI) Fuel Type: Unleaded Gasoline, minimum 91 octane Ignition System Ignition Type: High-performance, dual-fire, non-adjustable, solid-state electronic ignition 🔧 Transmission Standard Transmission Type: Harley-Davidson Cruise Drive 6-Speed Transmission Clutch Type: Clutched, hydraulically operated, 9-plate, wet Features Gear Ratios: 1st: 9.315, 2nd: 6.652, 3rd: 4.943, 4th: 3.851, 5th: 3.105, 6th: 2.742 (Typical values, may vary slightly) Primary Drive: Gear, 34/46 ratio Final Drive: Belt, 32/66 ratio Clutch Actuation: Hydraulic 📐 Dimensions Exterior Wheelbase: Varies by model (e.g., approx. 64.5 inches for Low Rider) Seat Height: Varies by model (e.g., approx. 26.3 inches unladen for Low Rider) Weights Dry Weight: Varies by model (e.g., approx. 632 lbs for Low Rider) Gross Vehicle Weight Rating Gvwr: Typically around 1160 lbs Fuel Capacity: Typically 5.0 gallons (18.9 L) 🛡️ Safety Features Ratings Crash Test Data: Motorcycles are not subject to standardized crash testing in the same way as cars. Safety relies heavily on rider skill, maintenance, and adherence to safety guidelines. Active Features Braking System: Hydraulic disc brakes, front and rear. Some models may offer ABS as an option or standard. Lighting: Halogen headlight, LED taillight, incandescent turn signals. Reflectors integrated into fenders and side. Passive Features Chassis Design: Robust steel frame designed for stability and rider control. Tire Specifications: Specific tire sizes and types vary...
