Suzuki King Quad LT-A400/F LT-F400/F Complete Workshop Service Repair Manual 2008 2009 2010

Normaler Preis
$133.00
Verkaufspreis
$133.00
Normaler Preis
The Suzuki King Quad LT-A400/F, produced for the 2008, 2009, and 2010 model years, is a mid-size utility All-Terrain Vehicle designed for recreational riders, ranchers, and property owners. This capable machine offers a robust 376 cc, 4-stroke engine with electronic fuel injection, paired with an automatic CVT transmission and selectable 2WD/4WD drive modes. Known for its utility focus, the King Quad features ample cargo racks, a towing capacity of 661 lbs, and a sturdy steel frame, making it versatile for tasks ranging from trail riding to farm work. Its value proposition lies in a strong balance of performance, reliability, and affordability, enhanced by the potential for effective DIY maintenance and repair. This comprehensive Workshop Service Repair Manual in English provides complete service and repair procedures for the Suzuki King Quad LT-A400/F. It covers all essential systems, including the engine, transmission, drivetrain, suspension, brakes, electrical system, and fuel and cooling systems. The manual details scheduled maintenance, troubleshooting common issues, step-by-step repair instructions, and component rebuilds. It also includes critical technical specifications, torque values, and fluid requirements, empowering owners and technicians to maintain and repair the vehicle effectively, ensuring its longevity and optimal performance. 🏷️ Basic Information Identification Make: Suzuki Model: King Quad LT-A400/F Model Variant: LT-F400/F Model Years Covered: 2008, 2009, 2010 Codes Product Code: N/A 👋 Introduction Market Position Segment: Mid-size utility ATV (All-Terrain Vehicle) Target User: Recreational riders, ranchers, farmers, property owners seeking a reliable and capable utility ATV. Competitive Analysis Competitors: Honda FourTrax, Yamaha Kodiak, Polaris Sportsman, Kawasaki Brute Force (in its class and price point). Key Features Utility Focus: Designed for practical use with features like ample cargo racks, towing capacity, and robust construction. Versatility: Suitable for a range of tasks from trail riding to farm work and hunting. Value Proposition: Offers a strong balance of performance, reliability, and affordability, enhanced by DIY repair capabilities with this manual. 📋 Manual Details Coverage Areas General Coverage: Complete service and repair procedures Specific Systems: Engine, Transmission, Drivetrain, Suspension, Brakes, Electrical System, Fuel System, Cooling System, Chassis, Bodywork, Troubleshooting Page Count Estimated Pages: Detailed information suggests a comprehensive manual, likely exceeding 500 pages (exact count not provided in product info). Manual Type Type: Workshop Service Repair Manual Language Language: English Format Format: PDF Download 📖 Manual Coverage Systems Covered Engine: Complete overhaul, diagnostics, fuel injection, ignition, lubrication, cooling, emissions control, torque specifications. Transmission: Automatic transmission (CVT) operation, maintenance, repair, fluid specifications, internal components. Drivetrain: Shaft drive, differential maintenance, axle repair, gearcase service, propeller shaft. Suspension: Front and rear suspension systems, shock absorbers, control arms, bushings, alignment procedures. Brakes: Hydraulic brake system, disc brake servicing, caliper repair, master cylinder, brake fluid specifications, bleeding procedures. Electrical System: Wiring diagrams, battery, charging system (stator, regulator/rectifier), starter motor, lighting, ignition system troubleshooting, CDI unit. Fuel System: Fuel pump, fuel filter replacement, throttle body servicing, fuel injector cleaning and testing, fuel pressure specifications. Cooling System: Radiator, cooling fan operation, coolant specifications, thermostat replacement, water pump. Chassis And Bodywork: Frame inspection, body panel removal and installation, seat, handle bars, fenders, rack systems. Procedures Included Maintenance: Scheduled maintenance, oil changes, filter replacements, spark plug service, valve clearance checks, lubrication points. Troubleshooting: Diagnostic procedures for common and uncommon issues, symptom-based troubleshooting guides, electrical fault finding. Repair: Step-by-step instructions for component disassembly, repair, reassembly, and adjustment for all covered systems. Rebuilds: Comprehensive instructions for engine and transmission overhauls, including component specifications and tolerances. Specifications: Torque values, clearances, fluid types and capacities, diagnostic readings, electrical resistance values. Technical Depth Depth: Comprehensive, from basic routine maintenance to complete engine and transmission rebuilds and advanced electrical diagnostics. 📊 Manual Specifications File Format File Type: Portable Document Format (PDF) Searchability: Likely text-searchable PDF, allowing for quick information retrieval (standard for quality manuals). Print Quality Printability: Printable on demand, allowing users to print entire sections or individual pages. Binding Type Binding: Not applicable (Digital PDF download) Paper Type Paper Quality: Not applicable (Digital PDF download) ⚙️ Engine Specifications Primary Engine Type: 4-stroke, SOHC, 4-valve, liquid-cooled, single-cylinder gasoline engine. Displacement: 376 cc (23.0 cu. in.) Bore X Stroke: 81.0 mm x 72.8 mm (3.19 in. x 2.87 in.) Compression Ratio: 9.3:1 Performance Horsepower: Approx. 23-25 HP (actual may vary slightly by model year and tuning). Torque: Approx. 21-23 lb-ft (actual may vary slightly by model year and tuning). Fuel System Induction: Electronic Fuel Injection (EFI) Fuel Type: Unleaded gasoline, Octane Rating 87 or higher. Ignition System: Electronic ignition (CDI) 🔧 Transmission Standard Type: Automatic (CVT - Continuously Variable Transmission) with selectable 2WD/4WD Gear Selection: High, Low, Neutral, Reverse, Park Features Engine Braking: Provides engine braking in lower gears. Drive Modes: Shaft drive to rear wheels, front differential with mechanical or electronic locking (depending on specific LT-A/LT-F sub-model). 📐 Dimensions Exterior Length: Approx. 81.3 in. (2065 mm) Width: Approx. 45.9 in. (1165 mm) Height: Approx. 48.4...
19 people are viewing this right now
Typ: Atv
Anbieter:
Art.-Nr: 86459
Sammlungen: ALL ATV Powersports Suzuki

VerfügbarkeitAuf Lager

Suzuki King Quad LT-A400/F LT-F400/F Complete Workshop Service Repair Manual 2008 2009 2010Suzuki King Quad LT-A400/F LT-F400/F Complete Workshop Service Repair Manual 2008 2009 2010Suzuki King Quad LT-A400/F LT-F400/F Complete Workshop Service Repair Manual 2008 2009 2010Suzuki King Quad LT-A400/F LT-F400/F Complete Workshop Service Repair Manual 2008 2009 2010
The Suzuki King Quad LT-A400/F, produced for the 2008, 2009, and 2010 model years, is a mid-size utility All-Terrain Vehicle designed for recreational riders, ranchers, and property owners. This capable machine offers a robust 376 cc, 4-stroke engine with electronic fuel injection, paired with an automatic CVT transmission and selectable 2WD/4WD drive modes. Known for its utility focus, the King Quad features ample cargo racks, a towing capacity of 661 lbs, and a sturdy steel frame, making it versatile for tasks ranging from trail riding to farm work. Its value proposition lies in a strong balance of performance, reliability, and affordability, enhanced by the potential for effective DIY maintenance and repair. This comprehensive Workshop Service Repair Manual in English provides complete service and repair procedures for the Suzuki King Quad LT-A400/F. It covers all essential systems, including the engine, transmission, drivetrain, suspension, brakes, electrical system, and fuel and cooling systems. The manual details scheduled maintenance, troubleshooting common issues, step-by-step repair instructions, and component rebuilds. It also includes critical technical specifications, torque values, and fluid requirements, empowering owners and technicians to maintain and repair the vehicle effectively, ensuring its longevity and optimal performance.
🏷️ Basic Information
Identification
Make:
Suzuki
Model:
King Quad LT-A400/F
Model Variant:
LT-F400/F
Model Years Covered:
2008, 2009, 2010
Codes
Product Code:
N/A
👋 Introduction
Market Position
Segment:
Mid-size utility ATV (All-Terrain Vehicle)
Target User:
Recreational riders, ranchers, farmers, property owners seeking a reliable and capable utility ATV.
Competitive Analysis
Competitors:
Honda FourTrax, Yamaha Kodiak, Polaris Sportsman, Kawasaki Brute Force (in its class and price point).
Key Features
Utility Focus:
Designed for practical use with features like ample cargo racks, towing capacity, and robust construction.
Versatility:
Suitable for a range of tasks from trail riding to farm work and hunting.
Value Proposition:
Offers a strong balance of performance, reliability, and affordability, enhanced by DIY repair capabilities with this manual.
📋 Manual Details
Coverage Areas
General Coverage:
Complete service and repair procedures
Specific Systems:
Engine, Transmission, Drivetrain, Suspension, Brakes, Electrical System, Fuel System, Cooling System, Chassis, Bodywork, Troubleshooting
Page Count
Estimated Pages:
Detailed information suggests a comprehensive manual, likely exceeding 500 pages (exact count not provided in product info).
Manual Type
Type:
Workshop Service Repair Manual
Language
Language:
English
Format
Format:
PDF Download
📖 Manual Coverage
Systems Covered
Engine:
Complete overhaul, diagnostics, fuel injection, ignition, lubrication, cooling, emissions control, torque specifications.
Transmission:
Automatic transmission (CVT) operation, maintenance, repair, fluid specifications, internal components.
Drivetrain:
Shaft drive, differential maintenance, axle repair, gearcase service, propeller shaft.
Suspension:
Front and rear suspension systems, shock absorbers, control arms, bushings, alignment procedures.
Brakes:
Hydraulic brake system, disc brake servicing, caliper repair, master cylinder, brake fluid specifications, bleeding procedures.
Electrical System:
Wiring diagrams, battery, charging system (stator, regulator/rectifier), starter motor, lighting, ignition system troubleshooting, CDI unit.
Fuel System:
Fuel pump, fuel filter replacement, throttle body servicing, fuel injector cleaning and testing, fuel pressure specifications.
Cooling System:
Radiator, cooling fan operation, coolant specifications, thermostat replacement, water pump.
Chassis And Bodywork:
Frame inspection, body panel removal and installation, seat, handle bars, fenders, rack systems.
Procedures Included
Maintenance:
Scheduled maintenance, oil changes, filter replacements, spark plug service, valve clearance checks, lubrication points.
Troubleshooting:
Diagnostic procedures for common and uncommon issues, symptom-based troubleshooting guides, electrical fault finding.
Repair:
Step-by-step instructions for component disassembly, repair, reassembly, and adjustment for all covered systems.
Rebuilds:
Comprehensive instructions for engine and transmission overhauls, including component specifications and tolerances.
Specifications:
Torque values, clearances, fluid types and capacities, diagnostic readings, electrical resistance values.
Technical Depth
Depth:
Comprehensive, from basic routine maintenance to complete engine and transmission rebuilds and advanced electrical diagnostics.
📊 Manual Specifications
File Format
File Type:
Portable Document Format (PDF)
Searchability:
Likely text-searchable PDF, allowing for quick information retrieval (standard for quality manuals).
Print Quality
Printability:
Printable on demand, allowing users to print entire sections or individual pages.
Binding Type
Binding:
Not applicable (Digital PDF download)
Paper Type
Paper Quality:
Not applicable (Digital PDF download)
⚙️ Engine Specifications
Primary Engine
Type:
4-stroke, SOHC, 4-valve, liquid-cooled, single-cylinder gasoline engine.
Displacement:
376 cc (23.0 cu. in.)
Bore X Stroke:
81.0 mm x 72.8 mm (3.19 in. x 2.87 in.)
Compression Ratio:
9.3:1
Performance
Horsepower:
Approx. 23-25 HP (actual may vary slightly by model year and tuning).
Torque:
Approx. 21-23 lb-ft (actual may vary slightly by model year and tuning).
Fuel System
Induction:
Electronic Fuel Injection (EFI)
Fuel Type:
Unleaded gasoline, Octane Rating 87 or higher.
Ignition
System:
Electronic ignition (CDI)
🔧 Transmission
Standard
Type:
Automatic (CVT - Continuously Variable Transmission) with selectable 2WD/4WD
Gear Selection:
High, Low, Neutral, Reverse, Park
Features
Engine Braking:
Provides engine braking in lower gears.
Drive Modes:
Shaft drive to rear wheels, front differential with mechanical or electronic locking (depending on specific LT-A/LT-F sub-model).
📐 Dimensions
Exterior
Length:
Approx. 81.3 in. (2065 mm)
Width:
Approx. 45.9 in. (1165 mm)
Height:
Approx. 48.4 in. (1230 mm)
Weights
Dry Weight:
Approx. 589 lbs (267 kg) for LT-A400F
Curb Weight:
Approx. 617 lbs (280 kg) for LT-A400F
Towing Capacity:
661 lbs (300 kg)
Dimensions
Ground Clearance:
Approx. 7.1 in. (180 mm)
🛡️ Safety Features
Ratings
Crash Tests:
ATVs are not typically subjected to automotive crash testing standards like cars. Safety relies on rider skill and adherence to operational guidelines.
Active Features
Braking System:
Hydraulic disc brakes front and rear, providing strong stopping power.
Selectable 4Wd:
Allows the rider to engage 4WD for increased traction when needed.
Passive Features
Frame Construction:
Sturdy steel frame designed for durability and stability.
Ergonomics:
Designed for rider comfort and control, with handlebar grips and footpegs.
💡 Technology Features
Infotainment
Features:
Basic instrumentation typically includes speedometer, odometer, trip meter, fuel gauge, and indicator lights. No advanced infotainment systems.
Driver Assistance
Features:
No advanced driver assistance systems (ADAS). Focus is on core mechanical and electrical systems.
Connectivity
Features:
No connectivity features like Bluetooth or GPS typically found on this model.
🔧 Maintenance
Service Intervals
Engine Oil Change:
Every 2,000 km (1,200 miles) or 12 months, whichever comes first. Refer to manual for specific intervals in hours or operating conditions.
Air Filter Cleaning:
Inspect every 1,000 km (600 miles), clean as needed, replace if damaged. More frequent cleaning in dusty conditions.
Spark Plug Replacement:
Recommended every 6,000 km (3,700 miles) or 24 months. Check and adjust gap at 1,000 km (600 miles).
Valve Clearance Check:
Every 4,000 km (2,500 miles) or 24 months.
Fluid Specifications
Engine Oil:
SAE 10W-40 API SG or higher. Suzuki recommends Suzuki Genuine 4-stroke Motor Oil or equivalent. Capacity: 2.7 L (2.8 US qt) with filter change.
Coolant:
Suzuki Super Long Life Coolant (50% solution) or equivalent high-quality ethylene glycol-based coolant with demineralized water.
Brake Fluid:
DOT 3 or DOT 4 brake fluid.
Gear Oil:
Suzuki Gear Oil API GL-5, SAE 80W-90 (for front and rear differentials). Capacity: Front Differential: 0.25 L (0.26 US qt); Rear Gearcase: 0.32 L (0.34 US qt).
Known Issues
Common Problems:
Some owners have reported occasional issues with the CVT belt in demanding conditions, requiring timely replacement. General wear items like suspension bushings, brake pads, and tires are typical for any ATV of this age and usage.
Preventative Maintenance:
Regularly checking and cleaning the air filter, ensuring proper tire pressure, and performing timely oil changes are crucial for longevity.
📚 Vehicle History
Brand Heritage
Manufacturer:
Suzuki Motor Corporation, a Japanese multinational corporation known for its wide range of vehicles, including motorcycles and ATVs.
Model Evolution
Lineage:
The King Quad line has a history of offering robust utility ATVs. The LT-A400/F represents Suzuki's approach to a capable and reliable mid-displacement utility machine, evolving from earlier models with fuel injection and updated chassis designs.
Production
Manufacturing Location:
Primarily manufactured by Suzuki, with assembly potentially occurring in various global locations. (Specific plant not detailed in product info).
🏆 Awards & Recognition
Recognitions
Industry Acclaim:
While specific awards for the 2008-2010 LT-A400/F are not readily cited, Suzuki's King Quad line is generally recognized for its durability, reliability, and value in the utility ATV market.
