2007-2013 Kawasaki Concours Models 14 Service Repair Workshop Manual PDF The Kawasaki Concours 14 (also known as the GTR1400 in international markets) is a sport-touring powerhouse born from the legendary ZX-14 superbike platform. Introduced in 2007 for the 2008 model year, the Concours 14 was Kawasakis answer to riders who wanted the performance and technology of a liter-class sportbike combined with legitimate long-distance touring capability. The engine is a detuned version of the ZX-14s massive 1352cc inline-four, modified for broader midrange torque and smoother power delivery -- ideal for carrying rider, passenger, and luggage across continents. Kawasaki equipped the Concours 14 with an advanced shaft drive system (Kawasakis Tetra-Lever), electronic adjustable suspension on certain markets, an integrated hard-luggage system, and an advanced combined braking system. The aluminum monocoque frame provides rigidity for spirited canyon carving while the adjustable windscreen and ergonomic seating position make 500-mile days comfortable. This is a motorcycle that asks no compromises between sport and touring, and its mechanical complexity demands thorough, accurate service information for proper maintenance. SERVICE AND REPAIR SCOPE - Complete engine top-end service with cam chain tensioner inspection - Valve clearance measurement and shim replacement for all 16 valves - Throttle body synchronization with vacuum gauge procedure for four individual bodies - Fuel injector resistance testing, spray pattern inspection, and cleaning - Fuel pressure regulator testing and fuel pump flow rate verification - Oil change with oil filter replacement and oil cooler inspection - Clutch plate wear measurement and spring free-length check - 6-speed transmission shift drum and fork inspection during cases split - Shaft drive final drive gear oil change with gear inspection - Tetra-Lever suspension system diagnostics and joint replacement - Electronic suspension actuator testing and calibration (where equipped) - Combined braking system bleed procedure with ABS module attention - Brake pad replacement front and rear with disc thickness measurement - Windscreen motor mechanism servicing and cable adjustment - Hard luggage latch mechanism adjustment and hinge lubrication - Tire pressure monitoring system sensor replacement and programming (TPMS) - Radiator flush and thermostat replacement - Battery removal with ECM memory preservation procedure - Steering head bearing replacement with angular contact bearing set TECHNICAL SPECIFICATIONS - Engine Type: Liquid-cooled, 4-stroke, DOHC, 16-valve, inline-4 - Displacement: 1352cc - Bore and Stroke: 84.0 x 61.0mm - Compression Ratio: 10.7:1 - Fuel System: Dual throttle bodies with sub-throttle valves, fuel injection - Ignition: Digital transistorized - Transmission: 6-speed with return shift - Clutch: Wet multiplate - Final Drive: Shaft drive (Tetra-Lever system) - Frame Type: Aluminum monocoque - Front Suspension: 43mm USD fork, adjustable preload and rebound - Rear Suspension: Uni-Trak monoshock, adjustable preload and rebound - Front Brakes: Dual 310mm floating discs, 4-piston radial calipers - Rear Brake: Single 270mm disc - Combined Braking: K-ACTS linked braking system - Wet Weight: Approximately 321 kg (707 lbs) - Fuel Capacity: 22 liters DIAGNOSTIC INFORMATION - Uneven throttle response across cylinders: Perform throttle body synchronization with vacuum gauges on all four ports, check throttle position sensor voltage, inspect intake boot for air leaks, verify IACV operation - Combined braking feels incorrect: Check brake fluid level in both master cylinder reservoirs, confirm no air in ABS modulator, verify delay valve function, inspect caliper slide pin movement - Shaft drive noise from rear: Check final drive gear oil level and condition, inspect universal joint boot for tears, examine rear hub bearing for play, verify Tetra-Lever link joint wear - ECM warning light illuminated: Connect diagnostic tool and read fault codes, clear codes after repair to confirm fix, check electrical connectors for corrosion, verify sensor ground circuits - Windscreen does not raise or lower: Check motor function with direct power application, inspect drive cable for binding or breakage, verify switch continuity, check limit switch function - Excessive engine vibration at certain RPM: Check engine mounting bolt torque, inspect exhaust hanger rubber condition, verify crankshaft balancer function, examine frame flex points - Oil consumption above normal: Monitor consumption rate over 1000 km, inspect valve stem seals, check piston ring end gap, examine cylinder wall for honing wear pattern ILLUSTRATIONS AND DIAGRAMS INCLUDED - Engine exploded view with cam drive and oil circuit details - Throttle body assembly with IACV and sub-throttle detail - Complete wiring harness diagram with ECU pin assignments - Tetra-Lever shaft drive system cross-section - Combined braking system hydraulic circuit diagram - Aluminum monocoque frame weld locations with torque points - Suspension linkage geometry with bearing locations - Complete torque specification reference tables - Scheduled maintenance interval charts COMPATIBILITY - Covers 2008 through 2013 model years (launched 2007) - Applies to Kawasaki Concours 14 / GTR1400 all variants - Includes models with and without electronic suspension and TPMS - English language manual FILE PROPERTIES - Format: Searchable PDF - Language: English - Delivery: Instant digital download - Access: Download anytime after purchase
