Basic Information Identification Make: Kia Model: Soul Year: 2011 Generation Generation: 1st Generation (AM) Codes Platform Code: AM Introduction Market Position Segment: Subcompact Crossover SUV / Urban Crossover Competitive Analysis Key Competitors 2011: Nissan Juke, Honda Element (discontinued but similar niche), Scion xB, Chevrolet HHR Key Features Design Philosophy: Unique, boxy styling with a focus on urban practicality and spacious interior for its size. Target Audience: Younger buyers, singles, couples, those seeking distinctive styling and versatile utility. Manual Details Coverage Areas Coverage: Full Service, Repair, Maintenance, Diagnostics, Wiring Diagrams Page Count Estimated Page Count: Likely 1000+ pages (typical for full service manuals) Manual Type Manual Type: Full Service & Repair Manual Language Language: English Format File Format: PDF Manual Coverage Systems Covered Engine Mechanical: Engine assembly, cylinder head, block, crankshaft, pistons, camshafts, valve train, timing system Engine Performance: Fuel injection, ignition system, emissions control, cooling system, lubrication system Transmission Manual: Clutch, gearbox assembly, shift mechanism, internal components Transmission Automatic: Torque converter, transmission control module (TCM), hydraulic system, internal components Drivetrain: Front-wheel drive, axles, CV joints, differential Suspension: Front and rear suspension, struts, shock absorbers, control arms, bushings, springs Steering: Power steering system, steering column, rack and pinion, tie rods Brakes: Front and rear disc brakes, ABS (Anti-lock Braking System), brake calipers, pads, rotors, hydraulic lines Electrical System: Battery, alternator, starter motor, charging system, lighting system Body Exterior: Body panels, doors, hood, trunk, bumpers, glass, exterior trim Body Interior: Dashboard, seats, upholstery, interior trim, headliner, HVAC controls HVAC: Heating, Ventilation, and Air Conditioning system, climate control, refrigerant service Infotainment Audio: Audio system, speakers, radio, CD player, auxiliary input, potential USB/Bluetooth (depending on trim) Body Control Modules: BCM, ECU (Engine Control Unit), TCM (Transmission Control Module) diagnostics and repair Safety Systems: Airbag system, seat belts, SRS module Wiring Diagrams: Comprehensive electrical wiring diagrams for all systems Procedures Included Scheduled Maintenance: Oil changes, filter replacements, fluid checks, tire rotations, spark plug replacement intervals Diagnostic Troubleshooting: Step-by-step troubleshooting guides for common and uncommon faults Repair Procedures: Detailed instructions for component removal, installation, and repair Rebuilding Procedures: Instructions for major component rebuilds (e.g., engine, transmission) Refurbishment Restoration: Guidance for restoring worn or damaged components Electrical Diagnostics: Circuit testing, component testing, voltage/resistance checks Special Tools: Identification of required special tools for specific procedures Technical Depth Depth: Comprehensive: Covers everything from basic maintenance to advanced diagnostics and major component overhauls. Manual Specifications File Format File Format: PDF Print Quality Printability: Full Printable (all pages) Binding Type Binding Type: Digital Download (No physical binding) Paper Type Paper Type: N/A (Digital) Software Requirements Required Software: Adobe PDF Reader, WinRAR Compatibility Operating Systems: Compatible with all versions of Windows and Mac OS Engine Specifications Primary Engine Engine Code 1: G4FC (Beta II) Engine Displacement 1: 1.6 Liters (1591 cc) Engine Configuration 1: Inline 4-Cylinder, DOHC, 16 Valves Horsepower 1: 122 hp @ 6300 rpm Torque 1: 118 lb-ft @ 4200 rpm Optional Engine Engine Code 2: G4KD (Theta II) Engine Displacement 2: 2.0 Liters (1998 cc) Engine Configuration 2: Inline 4-Cylinder, DOHC, 16 Valves Horsepower 2: 142 hp @ 6000 rpm Torque 2: 137 lb-ft @ 4600 rpm Fuel System Fuel Delivery: Electronic Multi-Point Fuel Injection (MPI) Fuel Type: Unleaded Regular Gasoline (87 Octane recommended) Transmission Standard Standard Transmission 1.6L: 5-Speed Manual Standard Transmission 2.0L: 5-Speed Manual Optional Optional Transmission 1.6L: 4-Speed Automatic Optional Transmission 2.0L: 4-Speed Automatic Features Drivetrain: Front-Wheel Drive (FWD) Dimensions Exterior Length: 160.8 inches (4084 mm) Width: 69.1 inches (1755 mm) Height: 63.0 inches (1600 mm) Wheelbase: 100.4 inches (2550 mm) Weights Curb Weight 1.6L Manual: Approx. 2,700 lbs (1225 kg) Curb Weight 2.0L Auto: Approx. 2,850 lbs (1293 kg) Safety Features Ratings NHTSA Front Crash Test Rating: 4 Stars (Driver), 4 Stars (Passenger) NHTSA Side Crash Test Rating: 5 Stars (Driver), 5 Stars (Passenger) IIHS Front Offset Crash Test: Good IIHS Side Impact Crash Test: Good Active Features ABS: Standard (4-wheel disc brakes with ABS) Electronic Stability Control: Optional (ESC) on some trims/packages Traction Control: Standard with ESC where equipped Passive Features Airbags: Front airbags, front side-impact airbags, side-curtain airbags Seat Belts: 3-point seat belts with pretensioners for all occupants Technology Features Infotainment Audio System Standard: AM/FM/CD/MP3 player with 4 speakers, auxiliary input jack. Audio System Optional: Upgraded audio with additional speakers, USB port, Bluetooth (depending on trim level like '2' or '3') Driver Assistance Cruise Control: Available on higher trims Parking Sensors: Not typically standard, may have been an aftermarket option. Connectivity Bluetooth Handsfree: Available on higher trim levels or as an option, enabling hands-free calling. Maintenance Service Intervals Oil Change Interval: Every 7,500 miles or 6 months, whichever comes first (under normal driving conditions). Consult manual for severe conditions. Air Filter Replacement: Every 15,000 miles or 12 months Spark Plug Replacement: 105,000 miles (for Iridium type plugs) Coolant Flush: Every 30,000 miles or...
