Best 2016 Nissan Juke Service Repair Manual

Normaalihinta: $141.00
Myyntihinta: $141.00
Normaalihinta
Yksikköhinta: kohti

🏷️ Basic Information Identification Make: Nissan Model: Juke Year: 2016 Codes Chassis Code: F15 👋 Introduction Market Position Segment: Subcompact Crossover SUV (B-segment) Design Philosophy: Bold, distinctive styling, sporty driving dynamics, compact practicality Competitive Analysis Key Competitors: Honda HR-V, Chevrolet Trax, Mazda CX-3, Ford EcoSport, Fiat 500X Key Features Engine Options: Available with efficient 1.6L naturally aspirated and potent 1.6L turbocharged engines Drivetrain Options: Available in Front-Wheel Drive (FWD) and All-Wheel Drive (AWD) configurations Transmission Options: Choice between a 6-speed manual or an advanced CVT transmission Interior Design: Motorcycle-inspired cockpit, sporty accents, customizable interior lighting (on some trims) 📋 Manual Details Coverage Areas Regions Covered: North America, Europe, Asia Page Count Estimated Pages: 2500+ Manual Type Type: Factory Service Manual (FSM) / Repair Manual Language Language: English Format Format: Digital Download (PDF) 📖 Manual Coverage Systems Covered Engine Mechanical: 1.6L Turbocharged (MR16DDT), 1.6L Naturally Aspirated (HR16DE) - DOHC, CVTC, timing chain, lubrication, cooling, fuel injection, exhaust, emissions controls, engine management Engine Electrical: Ignition system, starting and charging system, ECU, sensors, wiring diagrams, diagnostic trouble codes (DTCs) Transmission Manual: 6-speed manual transmission (RM6F45A) - internal components, clutch operation, shifting mechanisms, maintenance, repair Transmission Automatic: CVT (Continuously Variable Transmission) - JF015E/RE0F11E (for 1.6L NA) and JF016E/RE0F10F (for 1.6L Turbo) - operation, fluid service, internal components, control systems, diagnostic procedures Drivetrain: All-Wheel Drive (AWD) system (ATTESA ET-S), front-wheel drive (FWD), differentials, drive shafts, CV joints, hub bearings, 4WD coupling unit Brakes: Front and rear disc brakes, ABS (Anti-lock Braking System), EBD (Electronic Brake-force Distribution), VDC (Vehicle Dynamic Control), brake fluid, hydraulic lines, caliper and rotor service, parking brake Steering: Electric Power Steering (EPS) system, steering column, tie rod ends, steering gear assembly, alignment specifications Suspension: Front struts (MacPherson), rear torsion beam/multi-link (depending on FWD/AWD), springs, shock absorbers, bushings, stabilizer bars, wheel bearing replacement Body Exterior: Body panels, doors, hood, tailgate, bumpers, glass, seals, exterior trim, paint and coating information Body Interior: Seats, dashboard, door panels, headliner, HVAC controls, interior trim, airbags system, seat belt mechanisms Electrical Body: Lighting (headlights, taillights, interior), power windows, power locks, mirrors, wipers, horn, fuses, relays, body control module (BCM) HVAC: Air conditioning system (compressor, refrigerant, evaporator, condenser), heating system, climate control unit, blower motor, cabin air filter replacement Safety Systems: Airbag system (SRS), occupant classification system, seat belt pretensioners, safety restraint system (SRS) diagnosis and repair Procedures Included Scheduled Maintenance: Oil changes, filter replacements, fluid checks and top-offs, tire rotations, brake inspections, spark plug replacement, belt inspection/replacement Engine Repair: Head gasket replacement, piston and ring replacement, bearing service, valve adjustment, complete engine rebuild procedures Transmission Repair: CVT fluid and filter change, CVT clutch pack replacement, valve body diagnosis and repair, manual transmission gear set replacement Brake Repair: Brake pad and rotor replacement, caliper rebuilding, brake line bleeding, ABS sensor replacement, master cylinder replacement Suspension Steering Repair: Strut and shock absorber replacement, control arm bushing replacement, ball joint replacement, tie rod end replacement, power steering pump/motor replacement Electrical Diagnosis: Wiring harness testing, sensor testing and replacement, actuator testing, diagnostic trouble code (DTC) interpretation and troubleshooting Body Repair: Panel alignment, dent repair, rust repair, door/tailgate adjustment, glass replacement, bumper cover repair/replacement HVAC Repair: Refrigerant recharge, compressor replacement, evaporator core replacement, heater core replacement, blower motor replacement Troubleshooting Guides: Detailed symptom-based troubleshooting charts for common and uncommon issues Technical Specifications Data: Torque specifications, fluid capacities, diagnostic parameters, alignment specifications, electrical component data Technical Depth Depth: Comprehensive (from basic maintenance to complete overhaul and advanced diagnostics) Diagnostics: Detailed diagnostic procedures, including use of Nissan CONSULT scanner (or equivalent) and interpretation of data streams Wiring Diagrams: Full system wiring diagrams with component locations and wire colors Special Tools: Identification and usage of specialized tools required for specific repairs 📊 Manual Specifications File Format File Type: PDF Searchability: Fully searchable text Print Quality Resolution: High-resolution images and diagrams Binding Type Binding: N/A (Digital Download) Paper Type Paper Quality: N/A (Digital Download) ⚙️ Engine Specifications Primary Engine Engine Code Turbo: MR16DDT Engine Displacement Turbo: 1.6 Liters (1618 cc) Engine Configuration Turbo: Inline 4-cylinder, DOHC, 16-valve, Turbocharged, Intercooled Bore X Stroke Turbo: 79.5 mm x 80.3 mm Compression Ratio Turbo: 10.0:1 Horsepower Turbo: 188 hp @ 5600 rpm (approx.) Torque Turbo: 177 lb-ft @ 2000-5200 rpm (approx.) Secondary Engine Engine Code Na: HR16DE Engine Displacement Na: 1.6 Liters (1598 cc) Engine Configuration Na: Inline 4-cylinder, DOHC, 16-valve, CVTC (Continuously Variable Valve Timing Control) Horsepower Na: 117 hp @ 6000 rpm (approx.) Torque Na: 114 lb-ft @ 4000 rpm (approx.) Fuel System Fuel Type: Unleaded gasoline Fuel Delivery: Multi-point Fuel Injection (MPI) / Direct Injection (on some turbo variants) Fuel Tank Capacity: 13.2 US gallons (50 Liters) 🔧 Transmission Standard Standard Transmission: 6-Speed Manual Transmission (for 1.6T) Optional Optional Transmission: CVT (Continuously Variable Transmission) - JF015E/RE0F11E (for 1.6L NA), JF016E/RE0F10F (for 1.6T) Features AWD Integration: CVT models...

15 people are viewing this right now

Type: Car

Myyjä:

Sku: 586112

Collections: ALL Featured Nissan

Availability: In stock

Tags: 2016 Car Cars Featured Juke Nissan

Tuoteversiot

Description

🏷️ Basic Information

Identification

Make:

Nissan

Model:

Year:

Codes

Chassis Code:

👋 Introduction

Market Position

Segment:

Subcompact Crossover SUV (B-segment)

Design Philosophy:

Bold, distinctive styling, sporty driving dynamics, compact practicality

Competitive Analysis

Key Competitors:

Honda HR-V, Chevrolet Trax, Mazda CX-3, Ford EcoSport, Fiat 500X

Key Features

Engine Options:

Available with efficient 1.6L naturally aspirated and potent 1.6L turbocharged engines

Drivetrain Options:

Available in Front-Wheel Drive (FWD) and All-Wheel Drive (AWD) configurations

Transmission Options:

Choice between a 6-speed manual or an advanced CVT transmission

Interior Design:

Motorcycle-inspired cockpit, sporty accents, customizable interior lighting (on some trims)

📋 Manual Details

Coverage Areas

Regions Covered:

North America, Europe, Asia

Page Count

Estimated Pages:

2500+

Manual Type

Type:

Factory Service Manual (FSM) / Repair Manual

Language

Language:

English

Format

Format:

Digital Download (PDF)

📖 Manual Coverage

Systems Covered

Engine Mechanical:

1.6L Turbocharged (MR16DDT), 1.6L Naturally Aspirated (HR16DE) - DOHC, CVTC, timing chain, lubrication, cooling, fuel injection, exhaust, emissions controls, engine management

Engine Electrical:

Ignition system, starting and charging system, ECU, sensors, wiring diagrams, diagnostic trouble codes (DTCs)

Transmission Manual:

6-speed manual transmission (RM6F45A) - internal components, clutch operation, shifting mechanisms, maintenance, repair

Transmission Automatic:

CVT (Continuously Variable Transmission) - JF015E/RE0F11E (for 1.6L NA) and JF016E/RE0F10F (for 1.6L Turbo) - operation, fluid service, internal components, control systems, diagnostic procedures

Drivetrain:

All-Wheel Drive (AWD) system (ATTESA ET-S), front-wheel drive (FWD), differentials, drive shafts, CV joints, hub bearings, 4WD coupling unit

Brakes:

Front and rear disc brakes, ABS (Anti-lock Braking System), EBD (Electronic Brake-force Distribution), VDC (Vehicle Dynamic Control), brake fluid, hydraulic lines, caliper and rotor service, parking brake

Steering:

Electric Power Steering (EPS) system, steering column, tie rod ends, steering gear assembly, alignment specifications

Suspension:

Front struts (MacPherson), rear torsion beam/multi-link (depending on FWD/AWD), springs, shock absorbers, bushings, stabilizer bars, wheel bearing replacement

Body Exterior:

Body panels, doors, hood, tailgate, bumpers, glass, seals, exterior trim, paint and coating information

Body Interior:

Seats, dashboard, door panels, headliner, HVAC controls, interior trim, airbags system, seat belt mechanisms

Electrical Body:

Lighting (headlights, taillights, interior), power windows, power locks, mirrors, wipers, horn, fuses, relays, body control module (BCM)

HVAC:

Air conditioning system (compressor, refrigerant, evaporator, condenser), heating system, climate control unit, blower motor, cabin air filter replacement

Safety Systems:

Airbag system (SRS), occupant classification system, seat belt pretensioners, safety restraint system (SRS) diagnosis and repair

Procedures Included

Scheduled Maintenance:

Oil changes, filter replacements, fluid checks and top-offs, tire rotations, brake inspections, spark plug replacement, belt inspection/replacement

Engine Repair:

Head gasket replacement, piston and ring replacement, bearing service, valve adjustment, complete engine rebuild procedures

Transmission Repair:

CVT fluid and filter change, CVT clutch pack replacement, valve body diagnosis and repair, manual transmission gear set replacement

Brake Repair:

Brake pad and rotor replacement, caliper rebuilding, brake line bleeding, ABS sensor replacement, master cylinder replacement

Suspension Steering Repair:

Strut and shock absorber replacement, control arm bushing replacement, ball joint replacement, tie rod end replacement, power steering pump/motor replacement

Electrical Diagnosis:

Wiring harness testing, sensor testing and replacement, actuator testing, diagnostic trouble code (DTC) interpretation and troubleshooting

Body Repair:

Panel alignment, dent repair, rust repair, door/tailgate adjustment, glass replacement, bumper cover repair/replacement

HVAC Repair:

Refrigerant recharge, compressor replacement, evaporator core replacement, heater core replacement, blower motor replacement

Troubleshooting Guides:

Detailed symptom-based troubleshooting charts for common and uncommon issues

Technical Specifications Data:

Torque specifications, fluid capacities, diagnostic parameters, alignment specifications, electrical component data

Technical Depth

Depth:

Comprehensive (from basic maintenance to complete overhaul and advanced diagnostics)

Diagnostics:

Detailed diagnostic procedures, including use of Nissan CONSULT scanner (or equivalent) and interpretation of data streams

Wiring Diagrams:

Full system wiring diagrams with component locations and wire colors

Special Tools:

Identification and usage of specialized tools required for specific repairs

📊 Manual Specifications

File Format

File Type:

Searchability:

Fully searchable text

Print Quality

Resolution:

High-resolution images and diagrams

Binding Type

Binding:

N/A (Digital Download)

Paper Type

Paper Quality:

N/A (Digital Download)

⚙️ Engine Specifications

Primary Engine

Engine Code Turbo:

MR16DDT

Engine Displacement Turbo:

1.6 Liters (1618 cc)

Engine Configuration Turbo:

Inline 4-cylinder, DOHC, 16-valve, Turbocharged, Intercooled

Bore X Stroke Turbo:

79.5 mm x 80.3 mm

Compression Ratio Turbo:

10.0:1

Horsepower Turbo:

188 hp @ 5600 rpm (approx.)

Torque Turbo:

177 lb-ft @ 2000-5200 rpm (approx.)

Secondary Engine

Engine Code Na:

HR16DE

Engine Displacement Na:

1.6 Liters (1598 cc)

Engine Configuration Na:

Inline 4-cylinder, DOHC, 16-valve, CVTC (Continuously Variable Valve Timing Control)

Horsepower Na:

117 hp @ 6000 rpm (approx.)

Torque Na:

114 lb-ft @ 4000 rpm (approx.)

Fuel System

Fuel Type:

Unleaded gasoline

Fuel Delivery:

Multi-point Fuel Injection (MPI) / Direct Injection (on some turbo variants)

Fuel Tank Capacity:

13.2 US gallons (50 Liters)

🔧 Transmission

Standard

Standard Transmission:

6-Speed Manual Transmission (for 1.6T)

Optional

Optional Transmission:

CVT (Continuously Variable Transmission) - JF015E/RE0F11E (for 1.6L NA), JF016E/RE0F10F (for 1.6T)

Features

AWD Integration:

CVT models available with intelligent All-Wheel Drive (i-AWD) system

Manual Gear Ratios:

Detailed ratios available in manual

Cvt Fluid Type:

Nissan CVT Fluid NS-2 or NS-3 (specific to transmission variant)

📐 Dimensions

Exterior

Length:

163.4 in (4150 mm)

Width:

69.7 in (1770 mm)

Height:

64.2 in (1630 mm) / 65.1 in (1655 mm) AWD

Wheelbase:

102.4 in (2600 mm)

Ground Clearance:

7.2 in (183 mm) FWD / 7.7 in (195 mm) AWD

Cargo

Cargo Volume Rear Seats Up:

24.3 cu ft (688 L)

Cargo Volume Rear Seats Down:

50.5 cu ft (1430 L)

Weights

Curb Weight:

Approx. 3000-3300 lbs (1360-1500 kg) depending on configuration

Gross Vehicle Weight Rating:

Available in manual

Towing Capacity:

Not recommended or specified

Wheels Tires

Wheel Bolt Pattern:

5x114.3 mm (5x4.5 inches)

Standard Tire Size:

215/55R17 (common)

Optional Wheel Size:

18-inch alloy wheels

🛡️ Safety Features

Ratings

NHTSA Overall Rating:

4 out of 5 stars (for models tested)

IIHS Top Safety Pick:

Not consistently awarded, varied by year and testing criteria

Active Features

Standard Anti-lock Braking System

Standard Electronic Brake-force Distribution

Standard Vehicle Dynamic Control (Traction Control and Stability Control)

Brake Assist:

Standard Brake Assist

Passive Features

Airbags:

Front, side, and curtain airbags (number varies by trim)

Seatbelts:

3-point front and rear seat belts with pretensioners and load limiters

Child Seat Anchors:

LATCH (Lower Anchors and Tethers for CHildren) system

💡 Technology Features

Infotainment

Display Size:

5.0-inch or 5.8-inch color touchscreen (depending on trim and options)

Audio System:

AM/FM/CD/MP3, SiriusXM Satellite Radio capability, USB port, Auxiliary input

Navigation:

Optional navigation system with real-time traffic

Driver Assistance

Backup Camera:

Standard or optional rear view monitor

Keyless Entry Start:

Nissan Intelligent Key with Push Button Ignition

Connectivity

Bluetooth:

Standard Bluetooth hands-free phone system and streaming audio

🔧 Maintenance

Service Intervals

Oil Change Interval:

Every 5,000 miles or 6 months, or 7,500 miles/12 months with synthetic oil (refer to owner's manual for exact recommendation)

Air Filter Replacement:

Every 15,000-30,000 miles or as needed based on inspection

Cabin Air Filter Replacement:

Every 15,000-20,000 miles or annually

Spark Plug Replacement:

Iridium-tipped plugs: 105,000 miles

Brake Fluid Flush:

Every 2 years or 30,000 miles

Cvt Fluid Change:

Every 30,000-60,000 miles, depending on driving conditions (refer to manual)

Fluid Specifications

Engine Oil Type:

SAE 0W-20 Synthetic (API SN or ILSAC GF-5 certified)

Engine Oil Capacity:

Approx. 4.0-4.2 quarts (3.8-4.0 Liters) for 1.6L, 4.4 quarts (4.2 Liters) for 1.6T (with filter)

Coolant Type:

Nissan Genuine Super Long Life Coolant (Blue) or equivalent (50/50 mix)

Transmission Fluid Manual:

API GL-4 SAE 75W-85

Brake Fluid Type:

SAE J1703 or FMVSS No. 116 DOT 3

Known Issues

Cvt Problems:

Some reports of CVT hesitation, shuddering, or premature failure, often linked to fluid maintenance or overheating.

Turbo Lag:

Characteristic of the 1.6T engine, though generally well-managed.

Ignition Coils:

Occasional reports of ignition coil failure leading to misfires.

Suspension Noise:

Worn strut mounts or bushings can lead to knocking or creaking noises.

📚 Vehicle History

Brand Heritage

Manufacturer Origin:

Japan

Model Evolution

Introduction Year:

2010 (Global Debut), 2011 (US Market)

Design Inspiration:

Inspired by sports cars and motorcycles, aiming for a unique and sporty compact crossover

Facelift Updates:

Mid-cycle refresh for the 2014 model year introduced revised styling, updated interior, and powertrain enhancements for some markets.

Production

Manufacturing Plants:

Oppama, Japan; Sunderland, UK; St. Petersburg, Russia; Smyrna, Tennessee, USA

🏆 Awards & Recognition

Recognitions

Initial Reception:

Praised for distinctive styling and engaging driving dynamics, but criticized for polarizing looks and practicality by some.

Ratings

Fuel Economy Ratings:

EPA estimates vary by engine/drivetrain, typically ranging from 25-29 MPG combined.

Certifications

Emissions Standards:

Meets EPA and CARB emissions standards for the model year
