This manual covers the Chevrolet Orlando, a versatile compact MPV/crossover introduced by Chevrolet globally in 2011. Built on the GM Theta Premium platform, the 2012 model year Orlando is recognized for its flexible seating arrangements and practical interior, designed to meet the needs of families and individuals seeking adaptable transportation. Notable features include modern styling for its segment and a 5-star Euro NCAP safety rating, highlighting its commitment to passenger protection. The Orlando aims to provide a reliable and comfortable driving experience, competing within the compact MPV segment with its blend of utility and contemporary design. This comprehensive English-language manual, estimated at over 500 pages, serves as both an owner's guide and a detailed service and repair resource. It provides extensive coverage of all major vehicle systems, including powertrain, chassis, electrical, and body components. Within its scope are detailed procedures for scheduled maintenance, fluid changes, troubleshooting common issues, diagnostic interpretation, component repair and replacement, and essential technical specifications like torque values. This guide is an indispensable tool for owners, mechanics, and technicians to ensure the proper upkeep, maintenance, and repair of the Chevrolet Orlando, promoting its longevity and optimal performance. 🏷️ Basic Information Identification Make: Chevrolet Model: Orlando Year: 2012 Generation Generation Code: J300 Codes Platform: GM Theta Premium 👋 Introduction Market Position Segment: Compact MPV / Crossover SUV Target Audience: Families, individuals seeking versatile transportation Competitive Analysis Key Competitors: Ford C-Max, Volkswagen Touran, Mazda 5, Citroën C4 Picasso Key Features Unique Selling Points: Flexible seating, practical interior, modern styling for its segment 📋 Manual Details Coverage Areas Covered Models: Chevrolet Orlando 2012 Page Count Estimated Pages: 500+ Manual Type Type: Owner's Manual / Service & Repair Manual (Combined) Language Language: English Format Format: PDF Download 📖 Manual Coverage Systems Covered Powertrain: Engine, Transmission, Drivetrain Chassis: Suspension, Steering, Brakes, Wheels & Tires Electrical: Battery, Charging System, Ignition, Lighting, Instrumentation, Infotainment, HVAC Controls Body: Body Exterior, Interior Trim, Doors, Windows, Seats Procedures Included Maintenance: Scheduled Maintenance, Fluid Changes, Filter Replacements, Lubrication Diagnostics: Troubleshooting Guides, Symptom Analysis, Diagnostic Trouble Codes (DTCs) Interpretation Repair: Component Disassembly & Reassembly, Component Replacement, System Repair Technical Data: Torque Specifications, Component Dimensions, Material Specifications Technical Depth Depth: Comprehensive (from basic owner information to detailed repair procedures) 📊 Manual Specifications File Format File Type: PDF Print Quality Resolution: High-resolution (suitable for printing) Binding Type Binding: Not Applicable (Digital Download) Paper Type Paper: Not Applicable (Digital Download) ⚙️ Engine Specifications Primary Engine Engine Code: A14NET (1.4L Turbo Ecotec) Configuration: Inline 4-cylinder, turbocharged Displacement: 1364 cc (1.4 Liters) Horsepower: 140 PS (138 hp) @ 6000 rpm Torque: 200 Nm (148 lb-ft) @ 1850-4900 rpm Fuel System Induction: Turbocharged, Direct Injection (DI) Fuel Type: Unleaded Gasoline (Octane rating typically 95 RON) Performance Emissions Standard: Euro 5 🔧 Transmission Standard Type: 6-speed Manual Transmission Optional Type: 6-speed Automatic Transmission (often with ActiveSelect) Features Gear Ratios: Specific ratios detailed in manual Transmission Fluid Type: Dexron VI (for automatic) 📐 Dimensions Exterior Length: 4685 mm (184.4 inches) Width: 1836 mm (72.3 inches) (excluding mirrors) Height: 1638 mm (64.5 inches) Wheelbase: 2760 mm (108.7 inches) Cargo Cargo Volume Seats Up: Approx. 89.5 cubic feet (with second and third rows folded) Cargo Volume Seats Down: Approx. 120-300 liters (depending on seat configuration) Weights Curb Weight: Approx. 1500-1600 kg (depending on configuration) 🛡️ Safety Features Ratings Euro Ncap Rating: 5 Stars (for models tested) Active Features ABS: Anti-lock Braking System Esc: Electronic Stability Control Traction Control: Traction Control System (TCS) Passive Features Airbags: Front, Side, Curtain Airbags (number varies by trim) Seatbelts: 3-point seatbelts with pretensioners Child Seat Anchors: ISOFIX/LATCH System 💡 Technology Features Infotainment Audio System: Chevrolet MyLink infotainment system (optional on some trims), with USB, Bluetooth connectivity. Navigation: Optional GPS Navigation system. Driver Assistance Parking Sensors: Rear parking assist sensors (optional) Rearview Camera: Optional rearview camera integrated into infotainment screen. Connectivity Bluetooth: Standard on most trims for hands-free calling and audio streaming. 🔧 Maintenance Service Intervals Oil Change Interval: Typically 10,000-15,000 miles or 12 months, whichever comes first (check manual for exact specification) Air Filter Replacement: Recommended every 30,000-45,000 miles or as needed based on driving conditions. Spark Plug Replacement: Recommended around 60,000-100,000 miles for iridium-tipped plugs. Fluid Specifications Engine Oil Type: SAE 5W-30 (API SN or higher, GM dexos1™) Coolant Type: GM Dex-Cool (Orange, Long-life, Pre-diluted 50/50) Brake Fluid Type: DOT 4 Known Issues Common Complaints: Potential for turbocharger issues (wastegate rattle), early transmission issues in some automatic models, minor electrical gremlins. 📚 Vehicle History Brand Heritage Manufacturer: Chevrolet (division of General Motors) Model Evolution Segment Entry: Chevrolet introduced the Orlando as a global compact MPV/crossover in 2011 for the 2011 model year. Production Production Locations: Primarily South Korea (GM Korea), also some production in other GM facilities globally. 🏆 Awards & Recognition Recognitions Safety Awards: Achieved 5-star safety rating from Euro NCAP in...
