🏷️ Basic Information Identification Make: Hyundai Model: Terracan Engine Type: 2.9 CRDi Diesel Model Years Covered: 2005, 2006, 2007, 2008, 2009, 2010, 2011 👋 Introduction Market Position Vehicle Segment: Mid-size SUV (Body-on-frame construction) Target Audience: Owners seeking to perform their own maintenance and repairs, DIY enthusiasts, independent repair shops Competitive Analysis Key Competitors: Mitsubishi Pajero Sport, Toyota 4Runner (Fortuner), Nissan X-Trail (earlier models), Land Rover Discovery Key Features Manual Advantage: Empowers owners to save money on repairs and maintenance with detailed, easy-to-follow instructions. Illustrations: Includes pictures/illustrations for clarity on procedures. Accessibility: Downloadable to multiple devices (PC, Mac, tablet, smartphone). 📋 Manual Details Coverage Areas Manual Scope: Complete Service and Repair Procedures Page Count Page Count Estimate: High (estimated 1500+ pages based on typical comprehensive manuals for this era and vehicle) Manual Type Manual Type: Workshop Service Repair Manual Language Language: English Format Format: Downloadable Digital File (PDF) 📖 Manual Coverage Systems Covered Engine: 2.9 CRDi Diesel Engine (Mechanical, Fuel System, Lubrication, Cooling, Ignition/Glow Plug System, Air Intake) Transmission: Manual and Automatic Transmissions (Service, Repair, Diagnostics) Drivetrain: 4WD System, Differentials, Drive Shafts, Axles Suspension: Front and Rear Suspension Systems (Components, Alignment, Diagnosis) Brakes: Brake System (Hydraulics, Discs, Pads, ABS) Steering: Steering System (Components, Power Steering) Electrical: Electrical System (Wiring Diagrams, Battery, Alternator, Starter, Lighting, Fuses, Relays) Body: Bodywork (Exterior Panels, Doors, Interior Trim, Seats, HVAC System) Climate Control: HVAC System (Air Conditioning, Heating) Safety Systems: Airbag System, Seatbelt Systems Procedures Included Maintenance: Scheduled Maintenance, Oil Changes, Filter Replacements, Fluid Checks and Replacements Diagnostics: Troubleshooting Guides, Symptom-based Diagnostics, Fault Code Interpretation (where applicable for the era) Repair: Engine Overhaul, Transmission Rebuild, Brake Caliper Replacement, Suspension Component Replacement, Electrical Component Diagnosis and Replacement Disassembly Assembly: Step-by-step instructions for removing and installing major components and sub-assemblies Specifications Data: Torque Specifications, Clearances, Alignment Data, Fluid Capacities Technical Depth Depth: Comprehensive (from basic fluid changes to complete engine and transmission overhauls) Detail Level: Detailed, with clear step-by-step instructions and illustrations/diagrams 📊 Manual Specifications File Format File Type: PDF Searchability: Searchable text (standard for professionally created PDFs) Print Quality Printability: High Quality, printable pages Binding Type Binding Type Digital: N/A (Digital Download) Paper Type Paper Type Digital: N/A (Digital File) Software Requirement Required Software: Adobe Reader (Free) ⚙️ Engine Specifications Primary Engine Engine Code: D4CB (2.9L CRDi) Engine Displacement: 2902 cc Engine Configuration: Inline 4-cylinder, Turbocharged Diesel with Common Rail Direct Injection Performance Horsepower Approx: 163 PS (120 kW) @ 3800 rpm (typical for Euro 3/4 spec) Torque Approx: 338 Nm (249 lb-ft) @ 2000 rpm (typical for Euro 3/4 spec) Fuel System Fuel Injection Type: Bosch Common Rail Direct Injection Fuel Type: Diesel Cooling System Coolant Type: Ethylene Glycol based coolant (e.g., Hyundai Long Life Coolant or equivalent) Lubrication Engine Oil Capacity: Approx. 6.5 - 7.0 Liters (with filter change) Engine Oil Viscosity: 5W-30 or 10W-40 (API CI-4 or higher for diesel engines) 🔧 Transmission Standard Transmission Type Standard: 5-speed Manual Transmission Optional Transmission Type Optional: 4-speed Automatic Transmission Features Drivetrain Options: Part-time 4WD with transfer case and low-range gearing Fluid Specs Manual Transmission Fluid: API GL-4 or GL-5, SAE 75W-90 gear oil (check manual for specific type) Automatic Transmission Fluid: Hyundai Genuine ATF SP-III or equivalent (check manual for specific type) 📐 Dimensions Exterior Length Approx: 4700 - 4750 mm Width Approx: 1865 mm Height Approx: 1795 mm Weights Curb Weight Approx: 2000 - 2150 kg 🛡️ Safety Features Ratings Crash Test Ratings: Variable depending on region and specific tests conducted during its production run. (Early 2000s SUVs often had mixed results compared to modern standards). Active Features ABS: Standard (Anti-lock Braking System) Ebd: Electronic Brakeforce Distribution (often paired with ABS) Passive Features Airbags: Front driver and passenger airbags (standard), potential for side airbags in higher trims. Seatbelts: 3-point seatbelts with pre-tensioners for front occupants. 💡 Technology Features Infotainment Audio System: Base models likely had AM/FM radio with CD player. Higher trims might feature upgraded audio systems with more speakers. Navigation: Optional, typically aftermarket or dealer-installed for this era of vehicle. Driver Assistance Parking Sensors: Available as an option on some higher trim levels. Connectivity Aux Input: May be present on some later models or as an aftermarket addition. Not standard on early models. 🔧 Maintenance Service Intervals Oil Change Interval: Typically 10,000 km or 12 months, whichever comes first (refer to manual for exact specification based on driving conditions). Air Filter Replacement: Recommended every 20,000-40,000 km, or as per manual depending on dust exposure. Fuel Filter Replacement: Crucial for diesel engines. Typically every 40,000-60,000 km (essential to prevent injector issues). Fluid Specifications Coolant Capacity: Approx. 8.0 - 8.5 Liters Brake Fluid Type: DOT 3 or DOT 4 (refer to manual) Power Steering Fluid Type: ATF Dexron II/III or equivalent (check manual) Known Issues Glow Plugs: Can fail over time, requiring replacement for cold-start performance....
