🏷️ Basic Information Identification Make: Kia Model: Rio / Rio5 Year: 2013 Chassis Codes: UB Generation Generation Name: Third Generation (UB) Generation Years: 2011-2017 Codes Engine Code: G4FD 👋 Introduction Market Position Vehicle Class: Subcompact car (B-segment) Target Audience: Budget-conscious buyers, urban commuters, first-time car owners Competitive Analysis Key Competitors: Honda Fit, Toyota Yaris, Ford Fiesta, Chevrolet Sonic, Hyundai Accent Key Features Value Proposition: Affordability, fuel efficiency, practical interior space for its class, modern styling Manual Benefit: Empowers owners and independent mechanics with OEM-level diagnostic and repair information, reducing reliance on expensive dealership services 📋 Manual Details Coverage Areas Manual Coverage Scope: Comprehensive bumper-to-bumper repair and maintenance Page Count Estimated Page Count: Varies by specific OEM manual, typically 1500-3000+ pages for FSMs Manual Type Manual Type: Factory Service Manual (FSM) / Shop Repair Manual Language Language: English Format File Format: PDF Accessibility: Single PDF file, no additional software or internet required 📖 Manual Coverage Systems Covered Engine: Engine mechanical, GDI system, ignition, fuel, cooling, lubrication, emissions control, engine management (ECM/PCM) Transmission: Manual transmission (M/T) and Automatic transmission (A/T) diagnosis, repair, and overhaul Drivetrain: Front-wheel drive (FWD) system, axles, CV joints, differentials Suspension: Front suspension (McPherson strut), rear suspension (torsion beam), steering system (electric power steering - EPS), wheel alignment Brakes: Front disc brakes, rear drum brakes (or disc depending on trim), ABS, EBD, brake fluid specifications Electrical: Battery, charging system, starting system, lighting, interior/exterior electrical components, body control module (BCM), power distribution HVAC: Air conditioning system, heating system, ventilation, refrigerant types, service procedures Body And Interior: Body panels, doors, windows, seats, trim, airbags, safety restraint systems Diagnostics: On-Board Diagnostics (OBD-II) system, diagnostic trouble codes (DTCs), troubleshooting flowcharts Procedures Included Maintenance Procedures: Routine inspections, oil changes, filter replacements, spark plug service, brake fluid flush, coolant service Repair Procedures: Engine component removal/installation, transmission overhaul, brake caliper replacement, suspension component replacement, electrical diagnostics and repair Troubleshooting: System-specific diagnostic procedures, symptom-based troubleshooting guides Technical Specifications: Torque specifications, clearances, fluid capacities, electrical resistance values, diagnostic data Technical Depth Diagnostic Depth: Advanced diagnostics, including sensor data interpretation and control module programming guidance Repair Depth: Complete engine and transmission disassembly and reassembly procedures, including detailed internal component repair Illustrations: Detailed line drawings, exploded views, and diagnostic diagrams Searchability: Fully searchable text for quick access to specific information 📊 Manual Specifications File Format PDF Quality: High-resolution, professional quality for clear text and diagrams Printability: Printable pages for on-site reference Binding Type Binding Type: N/A (Digital PDF) Paper Type Paper Type: N/A (Digital PDF) ⚙️ Engine Specifications Primary Engine Engine Code: G4FD Engine Type: Inline 4-cylinder, Naturally Aspirated Displacement: 1.6 Liters (1591 cc) Aspiration: Gasoline Direct Injection (GDI) Bore X Stroke: 77.0 mm x 85.4 mm Compression Ratio: 10.5:1 Performance Horsepower Output: 138 hp @ 6300 rpm (approx.) Torque Output: 123 lb-ft @ 4850 rpm (approx.) Fuel System Fuel Delivery: Gasoline Direct Injection (GDI) Fuel Type: Unleaded Gasoline (87 octane recommended) Fuel Tank Capacity: 11.4 gallons (43 liters) Engine Management Engine Control Module: Kia proprietary ECU, typically programmable 🔧 Transmission Standard Transmission Type Std: 6-speed Manual Transmission (M/T) Optional Transmission Type Opt: 6-speed Automatic Transmission (A/T) with Shiftronic capability Features Automatic Features: Lock-up torque converter, electronic control, possible sport mode Fluid Specifications Automatic Transmission Fluid: Refer to manual for specific Kia SP-IV or equivalent Manual Transmission Fluid: Refer to manual for specific API GL-4, SAE 75W-90 or equivalent 📐 Dimensions Exterior Length: 160.2 inches (4070 mm) - Sedan / 160.6 inches (4080 mm) - Hatchback Width: 66.1 inches (1680 mm) Height: 57.9 inches (1470 mm) - Sedan / 57.7 inches (1465 mm) - Hatchback Wheelbase: 97.4 inches (2475 mm) Ground Clearance: Approx. 5.3 - 5.5 inches (135-140 mm) Interior Passenger Volume: Approx. 89.1 cu ft (2523 L) Cargo Cargo Volume Sedan: Approx. 13.7 cu ft (388 L) Cargo Volume Hatchback: Approx. 15.1 cu ft (427 L) with seats up Weights Curb Weight: 2,400 - 2,600 lbs (1089 - 1179 kg) depending on configuration Gross Vehicle Weight Rating: Refer to VIN sticker or manual 🛡️ Safety Features Ratings NHTSA Overall Rating: Generally good for its class, refer to specific NHTSA reports for 2013 model year IIHS Crash Test Ratings: Refer to specific IIHS reports for 2013 model year Active Features ABS: Standard Anti-lock Braking System Ebd: Standard Electronic Brake-force Distribution Esc: Standard Electronic Stability Control Traction Control: Standard Traction Control System (TCS) Passive Features Airbags: Front airbags, front side-impact airbags, side curtain airbags (standard on most trims) Seatbelts: 3-point seatbelts with pretensioners and load limiters in the front Child Anchors: LATCH (Lower Anchors and Tethers for CHildren) system 💡 Technology Features Infotainment Audio System: Standard AM/FM/CD/MP3 with USB/Aux input, Bluetooth connectivity available on higher trims Navigation: Optional navigation system available on select trims Driver Assistance Camera: Available rearview camera on higher trims Cruise Control: Available cruise control system Connectivity Bluetooth:...
