🏷️ Basic Information Identification Make: Mazda Model: MX-6 Year: 1994 Codes Chassis Code: GE 👋 Introduction Market Position Target Audience: DIY enthusiasts, independent repair shops, Mazda MX-6 owners seeking to perform maintenance and repairs. Competitive Analysis Advantage Over Print: Instant access, searchability, interactive diagrams, up-to-date information (depending on software updates), cost-effectiveness compared to some print versions. Key Features Licensing: Officially licensed, derived from OE (Original Equipment) materials. User Interface: User-friendly interface, easy navigation, push-button access to information. Cost Savings: Enables significant cost savings by performing repairs and maintenance independently. 📋 Manual Details Coverage Areas Primary Coverage: 1994 Mazda MX-6 Service and Repair Secondary Coverage: Official OE licensed information Page Count Estimated Page Count: Varies by software version, typically thousands of pages equivalent in digital format Manual Type Type: Digital Service and Repair Manual Software Language Language: English Format Format: Online Software/Web-based Access Access Duration: 1 Year (with options for renewal) 📖 Manual Coverage Systems Covered Engine Mechanical: Engine removal/installation, cylinder head, crankshaft, pistons, connecting rods, lubrication system, cooling system, timing belt/chain. Engine Management: Fuel system, ignition system, emission control systems, engine control unit (ECU) diagnostics and parameters, sensor and actuator testing. Transmission: Manual transmission (M/T) and Automatic transmission (A/T) overhaul, removal/installation, operation, and diagnostics. Drivetrain: Front-wheel drive (FWD) system, driveshafts, constant velocity (CV) joints, differential, transaxle. Brakes: Hydraulic system, brake fluid, master cylinder, brake boosters, front and rear brake components (discs, calipers, pads), parking brake, ABS system. Steering: Power steering system, steering gear, steering column, tie rods, wheel alignment specifications. Suspension: Front and rear suspension components, shock absorbers, struts, springs, control arms, sway bars, bushings, wheel bearing replacement. Electrical System: Battery, charging system (alternator), starting system (starter motor), lighting system, horn, wipers, power accessories. Body And Chassis: Body panels, doors, hood, trunk, interior trim, glass, bumpers, structural components. HVAC: Heating, ventilation, and air conditioning (HVAC) system diagnosis, component replacement, refrigerant handling (where applicable and legally permissible). Wiring Diagrams: Complete electrical schematic diagrams for various systems. Procedures Included Maintenance: Oil changes, filter replacements, fluid checks and top-offs, tire rotation, spark plug replacement, brake pad inspection. Diagnostics: Step-by-step troubleshooting guides for common and complex issues, diagnostic trouble codes (DTCs) interpretation, component testing procedures. Repair: Detailed instructions for component removal, disassembly, inspection, repair, reassembly, and installation. Adjustment: Torque specifications for all fasteners, idle speed adjustments, brake adjustments, clutch adjustments. Rebuilds: Complete overhaul procedures for major components like engines and transmissions. Technical Depth Depth: Comprehensive, covering routine maintenance to complete engine and transmission rebuilds, including electrical system diagnostics. 📊 Manual Specifications File Format File Type: Proprietary software/web access Compatibility: PC, Laptop, Smartphone, Tablet with internet connection and web browser. Print Quality Printability: Information is accessible for printing specific sections. Binding Type Binding: N/A (Digital Format) Paper Type Paper Type: N/A (Digital Format) ⚙️ Engine Specifications Primary Engine Engine Code: FS-DE (2.0L DOHC) Engine Type: Naturally Aspirated Inline 4-Cylinder, DOHC, 16 Valves Displacement: 1998 cc (2.0 Liters) Bore X Stroke: 83.0 mm x 92.0 mm Compression Ratio: 9.4:1 Horsepower: 120 HP @ 5500 RPM (approximate, may vary slightly by market) Torque: 125 lb-ft @ 4500 RPM (approximate, may vary slightly by market) Fuel System Fuel Delivery: Electronic Fuel Injection (EFI), Sequential Multi-Port Fuel Injection (MPI) Fuel Type: Unleaded Gasoline (Octane rating as specified by manufacturer, typically 87 or higher) Fuel Pump Type: In-tank electric 🔧 Transmission Standard Type: 5-Speed Manual Transmission (M/T) Optional Type: 4-Speed Automatic Transmission (A/T) Features Fluid Type Mt: API GL-4 or GL-5 Gear Oil (viscosity as per manual, e.g., 75W-90) Fluid Type At: Dexron III or equivalent ATF (Automatic Transmission Fluid) Clutch Type: Hydraulically operated dry single-plate clutch 📐 Dimensions Exterior Length: Approximately 4620 mm (181.9 inches) Width: Approximately 1730 mm (68.1 inches) Height: Approximately 1315 mm (51.8 inches) Wheelbase: Approximately 2615 mm (103.0 inches) Front Track: Approximately 1475 mm (58.1 inches) Rear Track: Approximately 1460 mm (57.5 inches) Weights Curb Weight: Approximately 1300-1400 kg (2866-3086 lbs), depending on transmission and options. Gross Vehicle Weight Rating: Refer to vehicle's VIN plate or owner's manual for specific GVWR. 🛡️ Safety Features Ratings NHTSA Frontal Impact: Not explicitly rated or data unavailable for this specific model year and market. IIHS Crash Test: Data for this specific model year and market may be limited or unavailable. Active Features ABS: Anti-lock Braking System (ABS) available as an option on some trims. Passive Features Airbags: Driver-side airbag standard; Passenger airbag typically optional or not available for 1994 model. Seatbelts: 3-point front and rear seatbelts. Crumple Zones: Designed with front and rear crumple zones for energy absorption. 💡 Technology Features Infotainment Audio System: Factory AM/FM cassette player, optional CD player. Speaker configurations varied by trim level. Driver Assistance Cruise Control: Standard on most higher trim levels. Power Windows Locks: Power windows and door locks were common options or standard on higher trims. Connectivity Phone Integration: N/A (No...
