🏷️ Basic Information Identification Make: Toyota Model: Matrix Year: 2006 Generation Generation Designation: First Generation (E130) Codes Chassis Code: E130 👋 Introduction Market Position Market Position: The 2006 Toyota Matrix is a compact hatchback known for its practicality, versatility, and Toyota's reputation for reliability. It competes with vehicles like the Honda Civic Hatchback, Mazda3, and Volkswagen Golf. Competitive Analysis Competitive Analysis: Positioned as a more practical and spacious alternative to traditional sedans in its class, the Matrix offered a flexible interior and a choice of efficient powertrains. Key Features Key Features: Versatile interior with fold-flat rear seats, available all-wheel drive (AWD) on certain trims, Toyota's reputation for reliability and low ownership costs. 📋 Manual Details Coverage Areas Coverage Areas: Engine, Transmission, Drivetrain, Brakes, Suspension, Steering, Electrical System, HVAC, Body, Chassis Page Count Page Count Estimated: Over 2000 pages (estimated based on typical factory service manuals for this era) Manual Type Manual Type: Factory Service and Repair Manual Software Language Language: English Format Format: PDF Download (Digital Access) 📖 Manual Coverage Systems Covered Engine Systems: 1.8L 1ZZ-FE, 2.4L 2AZ-FE: Engine Mechanical, Engine Control System (ECM), Fuel System, Ignition System, Lubrication System, Cooling System, Emission Control System Transmission Drivetrain: Manual Transmission (5-speed), Automatic Transmission (4-speed), Clutch System, Drive Shafts, Axles, Differential Brakes Suspension Steering: Front/Rear Brakes (Disc/Drum), ABS, Power Steering System, Suspension Components (Struts, Springs, Control Arms), Wheel Alignment Electrical HVAC Body: Wiring Diagrams, Lighting System, Audio System, Instrument Panel, Body Control Module (BCM), HVAC System (A/C, Heating), Door Locks, Power Windows, Exterior/Interior Trim, Chassis Electrical Procedures Included Maintenance Procedures: Oil Change, Filter Replacement, Spark Plug Replacement, Fluid Checks and Replenishment, Belt Inspection and Replacement, Tire Rotation Repair Procedures: Engine Overhaul, Transmission Overhaul, Brake Pad/Rotor Replacement, Suspension Component Replacement, Steering Rack Replacement, Electrical Component Diagnosis and Replacement, HVAC Component Service Troubleshooting Diagnostics: Diagnostic Trouble Codes (DTCs), Symptom-Based Troubleshooting Charts, Electrical System Diagnostics, Engine Performance Issues, Transmission Shifting Problems Technical Depth Technical Depth: Comprehensive: Covers basic maintenance to complete engine and transmission overhauls, including detailed diagnostic procedures and component testing. 📊 Manual Specifications File Format File Format: PDF Print Quality Print Quality: High Resolution (suitable for printing) Binding Type Binding Type: N/A (Digital Download) Paper Type Paper Type: N/A (Digital Download) ⚙️ Engine Specifications Primary Engine Engine 1 Displacement: 1.8 Liters (1798 cc) Engine 1 Type: DOHC 16-Valve Inline-4 (1ZZ-FE) Engine 1 Horsepower: 126 hp @ 6000 RPM Engine 1 Torque: 122 lb-ft @ 4200 RPM Optional Engine Engine 2 Displacement: 2.4 Liters (2362 cc) Engine 2 Type: DOHC 16-Valve Inline-4 (2AZ-FE, VVTi) Engine 2 Horsepower: 164 hp @ 6000 RPM Engine 2 Torque: 165 lb-ft @ 4000 RPM Fuel System Fuel System: Electronic Fuel Injection (EFI) with Sequential Port Injection Fuel Requirements Fuel Type: Unleaded Regular Gasoline (87 Octane) 🔧 Transmission Standard Standard Transmission: 5-Speed Manual Transmission Optional Optional Transmission: 4-Speed Electronically Controlled Automatic Transmission (ECT) Features AWD Availability: Available with 2.4L engine and Automatic Transmission 📐 Dimensions Exterior Wheelbase: 102.4 inches (2601 mm) Length: 174.0 inches (4420 mm) Width: 69.5 inches (1765 mm) Height: 60.4 inches (1534 mm) Weights Curb Weight Min: 2790 lbs (1266 kg) Curb Weight Max: 3140 lbs (1424 kg) Cargo Cargo Volume Seats Up: 18.4 cu ft Cargo Volume Seats Down: 36.8 cu ft 🛡️ Safety Features Ratings NHTSA Frontal Driver: Good NHTSA Frontal Passenger: Good NHTSA Side Driver: Good NHTSA Side Rear Passenger: Good IIHS Frontal Offset: Good Active Features Active Safety Features: Anti-lock Braking System (ABS), Electronic Brake-force Distribution (EBD), Brake Assist (BA), Traction Control (TRAC - often bundled with VSC) Passive Features Passive Safety Features: Driver and Front Passenger Airbags, Front Side-Impact Airbags, Front and Rear Side Curtain Airbags (optional/standard on certain trims), Active Head Restraints (front seats) 💡 Technology Features Infotainment Infotainment Features: Factory-installed AM/FM/CD audio system, optional satellite radio capability, steering wheel audio controls (on higher trims). Driver Assistance Driver Assistance Features: Cruise Control, Anti-lock Braking System (ABS), optional Vehicle Stability Control (VSC) and Traction Control (TRAC) on specific models. Connectivity Connectivity Features: Power windows, power door locks, remote keyless entry, optional auxiliary audio input jack. 🔧 Maintenance Service Intervals Oil Change Interval: Every 5,000 miles (8,000 km) or 6 months, whichever comes first. Check manual for specific synthetic oil recommendations. Engine Air Filter Replacement: Every 30,000 miles (48,000 km) or as needed based on driving conditions. Spark Plug Replacement: 1ZZ-FE: Iridium spark plugs - 100,000 miles (160,000 km). 2AZ-FE: Iridium spark plugs - 100,000 miles (160,000 km). Fluid Specifications Engine Oil Type: API Certified SAE 5W-30 (Check manual for specific viscosity recommendations based on temperature) Engine Oil Capacity: 1ZZ-FE: 4.4 US qt (4.2 L) with filter. 2AZ-FE: 4.8 US qt (4.5 L) with filter. Coolant Type: Toyota Super Long Life Coolant (Pink) or equivalent Asian vehicle coolant. Transmission Fluid Type Auto: Toyota Genuine ATF WS (World Standard) Transmission Fluid Type Manual:...
