🏷️ Basic Information Identification Make: Suzuki Model: Grand Vitara Product Name: 98-2005 Suzuki Grand Vitara Workshop/Service/Repair Manual Generation Generation Covered: First Generation (SQ416, SQ420, SQ625) Codes Chassis Codes: SQ416, SQ420, SQ625 👋 Introduction Market Position Segment: Compact SUV / Crossover Target Audience: DIY mechanics, independent repair shops, Suzuki enthusiasts. Competitive Analysis Key Competitors Era: Honda CR-V, Toyota RAV4, Ford Escape, Nissan Xterra, Jeep Cherokee (XJ/Liberty) Key Features Vehicle Strengths: Available V6 engine, genuine 4WD system (selectable or full-time depending on spec), body-on-frame construction for durability, compact dimensions for maneuverability. Manual Utility Manual Benefit: Empowers owners and technicians with the knowledge to perform comprehensive maintenance, diagnostics, and repairs, reducing reliance on dealerships and external repair services. 📋 Manual Details Coverage Areas Coverage Scope: Complete vehicle systems and repair procedures Page Count Estimated Page Count: Extensive (specific number not provided, typical for comprehensive service manuals) Manual Type Manual Category: Workshop/Service/Repair Manual Language Language: English Format File Format: PDF 📖 Manual Coverage Systems Covered Engine Systems: Engine mechanical, engine control, fuel system, cooling system, exhaust system, lubrication system Drivetrain Systems: Transmission (manual/automatic), transfer case, driveshafts, differentials (front/rear/center), axles, hubs Chassis Systems: Suspension (front/rear), steering system, braking system (including ABS), wheels and tires Electrical Systems: Battery, charging system, starting system, ignition system, lighting, instrumentation, power accessories, body control modules, chassis wiring diagrams Body And Interior: Body panels, doors, windows, seats, interior trim, climate control system (HVAC), safety restraint systems (airbags, seatbelts) Procedures Included Maintenance Procedures: Scheduled maintenance, fluid changes (oil, coolant, brake fluid, transmission fluid, differential fluid), filter replacements, spark plug replacement, belt inspections/replacement Diagnostic Procedures: Troubleshooting guides, symptom-based diagnostics, diagnostic trouble codes (DTCs), electrical system testing, component testing Repair Procedures: Component removal and installation, disassembly and assembly of major systems (engine, transmission, suspension, brakes), body repair, interior component repair Technical Specifications: Torque specifications, clearances, tolerances, diagnostic data, wiring diagrams, component data Technical Depth Depth Of Coverage: Comprehensive, covering everything from basic fluid checks and filter changes to complete engine and transmission rebuilds, including detailed diagnostic procedures for all major systems. 📊 Manual Specifications File Format Digital Format: PDF Print Quality Printability: Yes Binding Type Binding Method: Digital (Printable) Paper Type Digital Paper Simulation: N/A (Digital PDF) Compatibility Operating Systems: All Versions of Windows, Mac, and Linux Requirements Software Requirements: Adobe PDF Reader Delivery Method Download Type: Instant High Speed Download ⚙️ Engine Specifications Primary Engine Engine Codes And Types: G16A (1.6L I4), G20A (2.0L I4), H20A (2.0L V6), H25A (2.5L V6) Performance Horsepower Range: Approx. 95 HP (1.6L) to 155 HP (2.5L V6) Torque Range: Approx. 95 lb-ft (1.6L) to 150 lb-ft (2.5L V6) Fuel System Fuel Delivery: Multi-point Fuel Injection (MPI) Engine Management Ignition System: Distributorless Ignition System (DIS) on some models, Distributor ignition on others. Cooling System Coolant Type Specification: Ethyl Glycol based, Japanese standard (e.g., NPG type coolant often recommended for Japanese vehicles) Lubrication System Engine Oil Spec: API SG or SH, SAE 5W-30 or 10W-30 (refer to manual for specific climate/engine recommendation) 🔧 Transmission Standard Transmission Transmission Types: 5-speed Manual Transmission, 4-speed Automatic Transmission Optional Transmission Transfer Case Options: Selectable 4WD (Part-time), Full-time 4WD with viscous coupling center differential Features Transmission Fluid Spec: ATF Dexron III (for automatic transmission) Manual Transmission Fluid Spec: API GL-4 or GL-5, SAE 75W-90 (for manual transmission and transfer case) 📐 Dimensions Exterior Wheelbase: Approx. 2480 mm (97.6 in) for LWB, 2480 mm (97.6 in) for SWB Length: Approx. 4010 mm (157.9 in) for SWB, 4500 mm (177.2 in) for LWB Width: Approx. 1780 mm (70.1 in) Height: Approx. 1680 mm (66.1 in) Weights Curb Weight Range: Approx. 1300 kg - 1500 kg (2866 lbs - 3307 lbs) 🛡️ Safety Features Ratings NHTSA Ratings Era: NHTSA ratings from this era can be inconsistent; refer to specific year and model testing if available. Typically performed well for its class. Active Features Braking System: Front Ventilated Discs, Rear Drums (standard), Rear Discs (optional on some trims/engines). Anti-lock Braking System (ABS) optional on some models. Traction Control: Not commonly available on this generation. Passive Features Airbags: Driver and Passenger front airbags Seat Belts: 3-point height-adjustable front seat belts with pretensioners, 3-point rear seat belts. 💡 Technology Features Infotainment Audio System: AM/FM stereo with CD player, optional cassette player. Limited auxiliary inputs typical for the era. Navigation: Rarely available, typically as an aftermarket or dealer-installed option. Driver Assistance Cruise Control: Available on higher trim levels. Parking Assistance: Not available. Connectivity Bluetooth: Not available. Comfort Features Climate Control: Manual HVAC (heating, ventilation, and air conditioning) with optional automatic climate control on some models. 🔧 Maintenance Service Intervals Oil Change Interval: Typically every 5,000 miles or 6 months, whichever comes first (check manual for exact recommendation). Air Filter Replacement: Inspect every 15,000 miles, replace as needed or every 30,000 miles. Spark Plug Replacement: Copper plugs: 30,000 miles. Platinum plugs: 60,000...
