🏷️ Basic Information Identification Make: Harley-Davidson Model: FXSBSE CVO Breakout Generation Generation Code: Softail (2013-2017) Codes Model Codes: FXSB, FXSBSE 👋 Introduction Market Position Positioning: Essential technical documentation for owners and technicians of the Harley-Davidson FXSB Breakout and FXSBSE CVO Breakout models from 2013-2015. Competitive Analysis Value Proposition: Provides a cost-effective alternative to official Harley-Davidson service manuals, offering comprehensive DIY repair and maintenance capabilities. Empowers owners to perform tasks typically outsourced to dealerships. Key Features Features: Detailed illustrations, step-by-step instructions, pictorial guidance, comprehensive system coverage, troubleshooting assistance, and electrical diagrams. 📋 Manual Details Coverage Areas Applicable Years: 2013, 2014, 2015 Applicable Models: FXSB Breakout, FXSBSE CVO Breakout Page Count Estimated Page Count: Varies based on specific model year and detail; typically several hundred pages for comprehensive coverage. Manual Type Type: Workshop Service Repair Manual Language Language: English Format Format: PDF 📖 Manual Coverage Systems Covered Engine And Powertrain: Engine systems (top end, disassembly, assembly, crankcase, oil tank, pistons, connecting rods, flywheel), Fuel system (air cleaner, throttle position sensor, intake air system, induction module, oxygen sensor, fuel injection, fuel pump, tank), Exhaust system, Emission control, Clutch systems, Drive components, Transmission system (gearbox, drive gear, bearing, case). Chassis And Suspension: Front & rear wheel, Wheel bearings & tires, Vehicle alignment, Brake system, Fork & telescopic, Steering head, Shock absorbers, Jiffy stand & fork lock, Handlebars & fender, Foot board & rests. Electrical And Controls: Electrical control module, Body control module, H-DSSS actuation, Ignition & battery system, Starter system, Lighting system, Signal & crank position, Alternator & fuses, Wiring harness, Component control module, Instrumentation. Procedures Included Maintenance: Periodic maintenance, Fastener torque values, Fluid specifications (implied), Lubrication. Repair And Rebuild: Complete engine disassembly and assembly, Top-end service, Engine removal and installation, Transmission overhaul, Brake system service, Suspension component replacement, Electrical system diagnostics and repair, Fuel system diagnosis and service. Troubleshooting: General troubleshooting, Electrical diagnostics, Specific component troubleshooting. Technical Depth Depth: Comprehensive; covers everything from routine maintenance and adjustments to complete engine rebuilds and electrical system diagnostics. Suitable for both DIY enthusiasts and professional mechanics. 📊 Manual Specifications File Format Format: PDF Compatibility: All Windows versions, All Mac versions Required Software: Adobe Acrobat Reader Delivery Method: ZIP archive, requires extraction software (WinZip, WinRAR recommended) Print Quality Printability: All pages are printable Binding Type Binding: Digital (PDF format) Paper Type Paper Type: Not applicable (digital format) ⚙️ Engine Specifications Primary Engine Engine Type: 2-Cylinder V-Type, 4-Stroke, Air-Cooled, OHV Engine Displacement Fxsb: 1690 cc (103 cubic inches) Engine Displacement Fxsbse: 1800 cc (110 cubic inches) Performance Horsepower Fxsb: Typically around 70-75 HP (varies with model year and specific configuration) Torque Fxsb: Typically around 90-95 lb-ft (varies with model year and specific configuration) Horsepower Fxsbse: Typically around 75-80 HP (varies with model year and specific configuration) Torque Fxsbse: Typically around 100-105 lb-ft (varies with model year and specific configuration) Fuel System Fuel Delivery: Electronic Sequential Port Fuel Injection (ESPFI) Fuel Type: Unleaded gasoline, minimum 91 octane (R+M)/2 recommended 🔧 Transmission Standard Transmission Type: 6-Speed Cruise Drive Features Clutch Type: Clutch System: Wet, multi-plate, high-performance. Drive Type: Primary Drive: patented internal primary, 34/46 ratio. Final Drive: Belt, 32/66 ratio. 📐 Dimensions Exterior Length Fxsb: Approx. 96.3 inches (2446 mm) Length Fxsbse: Approx. 96.3 inches (2446 mm) Weights Dry Weight Fxsb: Approx. 692 lbs (313.9 kg) Dry Weight Fxsbse: Approx. 705 lbs (319.8 kg) Gvwr: Approx. 1160 lbs (526.2 kg) Capacities Fuel Capacity: 2.2 US gal (8.3 L) 🛡️ Safety Features Ratings ABS: Optional on FXSB, standard on FXSBSE (check specific model year) Active Features Braking System: Hydraulic disc brakes, dual front, single rear with standard or optional ABS. Passive Features Lighting: Halogen headlamp, LED tail lamp, incandescent front and rear turn signals (subject to regional variations). 💡 Technology Features Infotainment Instrumentation: Analog tachometer, digital speedometer, gear indicator, fuel gauge, clock, trip meters, diagnostic indicators. CVO models may feature additional instrumentation and features. Driver Assistance ABS: Anti-lock Braking System (ABS) available as an option or standard depending on the specific model and year, enhancing braking control. Connectivity Diagnostic System: On-board diagnostics (OBD-II) for engine management and fault detection, accessible through specific diagnostic tools and protocols. 🔧 Maintenance Service Intervals Initial Service: Typically at 1,000 miles (1,600 km) or 12 months, whichever comes first. Includes oil change, filter replacement, primary chain adjustment, and general inspection. Subsequent Service: Generally every 5,000 miles (8,000 km) or 12 months, covering oil changes, filter replacements, inspection of critical components, and adjustments as needed. Fluid Specifications Engine Oil: Harley-Davidson Genuine V-Twin 20W-50 Synthetic (or equivalent meeting Harley-Davidson specifications). Primary Chain Case Oil: Harley-Davidson Genuine Primary Formula + (or equivalent meeting specifications). Transmission Oil: Harley-Davidson Genuine Formula + (or equivalent meeting specifications). Brake Fluid: DOT 4 Synthetic brake fluid. Known Issues Common Wear Items: Tires (especially rear due to wide profile), brake pads, clutch plates, spark plugs,...
