🏷️ Basic Information Identification Make: Club Car Model: Caroche Electric Model Variant: Caroche Years Covered: 1970, 1971, 1972, 1973 👋 Introduction Market Position Historical Context: Club Car's early entry into the golf cart market with a focus on electric propulsion, targeting golf courses and recreational use. Competitive Analysis Niche Market: Caters to owners and maintainers of a specific vintage electric golf cart model, a niche but dedicated segment. Key Features Value Proposition: Provides essential part identification for maintenance, restoration, and sourcing of replacement components for a classic vehicle. Digital Access: Instant download availability facilitates immediate access for troubleshooting or ordering parts. 📋 Manual Details Coverage Areas Primary Coverage: Parts List Secondary Coverage: Parts identification, assembly diagrams, component listing Page Count Estimated Page Count: 150-250 Manual Type Type: Parts List Manual / Catalog Language Language: English Format Format: Electronic Downloadable PDF 📖 Manual Coverage Systems Covered Chassis And Frame: Frame components, suspension mounting, body attachment points Body And Trim: Body panels, seating, bumpers, dashboards, trim pieces Electrical System: Motor, controller, battery connections, wiring harnesses, switches, lights Powertrain: Electric motor, drive axle, reduction gears, wheel hubs Steering System: Steering wheel, column, tie rods, linkages, steering knuckles Braking System: Brake pedal, linkages, brake shoes, drums, cables Wheels And Tires: Wheels, hubs, lug nuts, tire specifications Accessories And Options: Canopy, windshield, rear-view mirrors, accessories mounting Procedures Included Part Identification: Identification of all original parts with associated diagrams and part numbers Assembly Sequence: Illustrative diagrams showing how components are assembled Disassembly Guidance: Implied guidance for disassembling for part replacement, focusing on component relationships Component Listing: Comprehensive list of all serviceable parts Technical Depth Depth: Parts identification and component-level visualization. Does not provide repair procedures or detailed diagnostics. 📊 Manual Specifications File Format File Type: PDF Searchable: Likely text-searchable if OCR was performed on original document Print Quality Print Readability: High, suitable for printing individual pages for workshop use Binding Type Binding: N/A (Digital Download) Paper Type Paper: N/A (Digital Download) ⚙️ Engine Specifications Primary Engine Type: Series DC Electric Motor Power Source: Deep Cycle Lead-Acid Batteries (typically 6V or 8V configurations) Performance Approximate Horsepower: 3-5 HP (estimated, as specific ratings were less common for early electric carts) Fuel System Fuel Type: N/A (Electric) Engine Components Motor Manufacturer: Likely an industrial DC motor manufacturer of the era 🔧 Transmission Standard Type: Direct Drive with Reduction Gearbox Optional Forward Reverse: Manual Forward/Reverse Selector Switch Features Drive Configuration: Rear-wheel drive via solid axle Gear Ratios: Specific reduction gear ratios will be detailed in the manual Fluid Requirements Gearbox Lubricant: GL-4 Gear Oil (likely SAE 90 or similar, specific grade in manual) 📐 Dimensions Exterior Length: Approximately 90-100 inches Width: Approximately 45-50 inches Height: Approximately 45-55 inches (to top of seat, without canopy) Weights Curb Weight: Approximately 400-500 lbs (excluding batteries) Battery Weight: Approximately 250-350 lbs (for a typical 36V or 48V system) Wheelbase Wheelbase Length: Approximately 65-70 inches 🛡️ Safety Features Ratings Safety Standards: Basic design for golf course operation, no formal crash ratings apply. Active Features Braking System: Mechanical drum brakes on rear wheels, parking brake mechanism. Steering: Mechanical steering system, typically no power assist. Passive Features Occupant Restraints: No seat belts standard on base models. Protection: Basic chassis and body protection. 💡 Technology Features Infotainment Features: Basic functionality, typically includes a forward/reverse switch and battery indicator (if present). Driver Assistance Features: None Connectivity Features: None 🔧 Maintenance Service Intervals Battery Maintenance: Regular water level checks and terminal cleaning (detailed in user manuals). Lubrication: Grease fittings on suspension and steering components (intervals vary, check specific sections). Fluid Specifications Gearbox Oil Spec: GL-4 SAE 90 Gear Oil (confirmation required from manual) Brake Fluid Spec: DOT 3 or DOT 4 Hydraulic Brake Fluid (for hydraulic systems, if equipped) Known Issues Electrical Wear: High resistance connections, worn brushes in the electric motor, controller issues common with age. Mechanical Wear: Worn suspension bushings, steering linkage wear, brake shoe wear, and cable stretch. Part Sourcing Obsolescence: Original parts may be difficult to find; aftermarket or universal replacements are often necessary. 📚 Vehicle History Brand Heritage Club Car Legacy: Club Car, founded in 1958, is a pioneering manufacturer of golf cars, known for innovation in electric vehicles. Model Evolution Caroche Era: The Caroche represents an early design philosophy for Club Car, focusing on simplicity and utility. Production Manufacturing Location: USA (Augusta, Georgia) 🏆 Awards & Recognition Recognitions Industry Standing: Club Car is a recognized leader in golf cart manufacturing, with early models like the Caroche contributing to its foundational reputation.
