🏷️ Basic Information Identification Make: Aprilia Model: RS50 Year: 2004-2005 Codes Engine Code: AM6 (Minarelli) 👋 Introduction Market Position Segment: Entry-level sport motorcycle, popular among younger riders and for light urban commuting. Competitive Analysis Competitors: Honda RS50, Yamaha TZR50, Gilera SMT/RCR 50, Derbi Senda R/SM 50. Key Features Design: Aggressive sportbike styling inspired by larger Aprilia RS models, lightweight chassis, responsive 50cc engine. Performance Characteristics: Nimble handling, quick acceleration for its class, capable of achieving legal speed limits for 50cc mopeds/motorcycles. 📋 Manual Details Coverage Areas Primary Coverage: Comprehensive service and repair for Aprilia RS50 (2004-2005) Page Count Estimated Pages: 300+ Manual Type Type: Service and Repair Manual Language Language: English Format Format: Digital (PDF) 📖 Manual Coverage Systems Covered Engine System: Detailed disassembly, assembly, inspection, and repair of the 50cc 2-stroke Minarelli AM6 engine, including cooling system, lubrication, fuel and ignition systems. Transmission System: Complete coverage of the 6-speed gearbox, clutch assembly, and shifting mechanisms. Chassis And Suspension: Front fork (upside-down), rear shock absorber, swingarm, wheel bearings, steering system, and frame inspection. Brake System: Front and rear hydraulic disc brake systems, including caliper overhaul, bleeding procedures, and pad replacement. Electrical System: Wiring diagrams, ignition system (CDI), lighting, charging system (stator/rotor), battery, and starter motor troubleshooting. Fuel System: Carburetor (Dell'Orto PHBN 14) specifications, adjustment, and overhaul; fuel tank, petcock, and lines. Cooling System: Liquid cooling system maintenance, radiator, water pump, and coolant specifications. Bodywork And Trim: Fairing removal, seat, fuel tank, and other body panel components. Procedures Included Routine Maintenance: Oil changes, spark plug replacement, air filter cleaning/replacement, chain adjustment, brake pad checks. Engine Repair: Top-end rebuild (piston, cylinder, head), crankshaft and bearing replacement, cylinder head gasket replacement. Transmission Repair: Gearbox disassembly and reassembly, clutch inspection and replacement. Suspension Service: Front fork oil change and seal replacement, rear shock absorber inspection. Brake Service: Brake fluid flush and bleed, caliper servicing, disc and pad replacement. Electrical Troubleshooting: Diagnostic steps for starting issues, charging system failures, lighting malfunctions. Carburetor Tuning: Jetting recommendations, idle speed adjustment, mixture control. Technical Depth Depth: In-depth technical repair and overhaul procedures, including detailed torque specifications and tolerances. 📊 Manual Specifications File Format Digital Format: PDF Print Quality Resolution: High-resolution scans with clear diagrams and legible text. Binding Type Digital Binding: N/A (Digital) Paper Type Digital Paper Type: N/A (Digital) ⚙️ Engine Specifications Primary Engine Engine Type: 2-stroke, single-cylinder Displacement: 49.7 cc Bore X Stroke: 39.5 x 40.3 mm Cooling System: Liquid-cooled Power Output: Approx. 8-10 HP (depending on regulations and specific tuning) Torque: N/A (typically not a primary spec for this class, but available in manual) Performance Top Speed: Limited by regulations, typically around 45-50 mph (70-80 km/h) Fuel System Carburetor Model: Dell'Orto PHBN 14 HS Fuel Type: Unleaded gasoline (95 RON recommended) mixed with 2-stroke oil Lubrication Oil Mixture: Automatic oil injection or pre-mix (refer to manual for specific ratios if pre-mixing). 🔧 Transmission Standard Type: 6-speed constant mesh manual transmission Features Clutch Type: Wet multi-plate clutch Final Drive: Chain drive 📐 Dimensions Exterior Length: Approx. 1950 mm Width: Approx. 730 mm Height: Approx. 1150 mm Wheelbase: Approx. 1340 mm Weights Dry Weight: Approx. 102 kg Fuel Tank Capacity: 13 Liters 🛡️ Safety Features Ratings Safety Ratings: Not applicable in the same way as cars; refers to adherence to regional moped/light motorcycle regulations. Active Features Braking System: Hydraulic disc brakes front and rear, typically with braided lines for improved feel. Suspension Features: Upside-down telescopic front fork, monoshock rear suspension for agile handling and stability. Passive Features Lighting: Halogen headlight, LED taillight, turn signals. Frame Construction: Deltabox-style perimeter frame (often aluminum or steel alloy) for rigidity. 💡 Technology Features Infotainment Instrument Cluster: Analog tachometer, speedometer, odometer, and indicator lights. Driver Assistance Assistance Systems: N/A (basic motorcycle) Connectivity Connectivity Features: N/A (basic motorcycle) 🔧 Maintenance Service Intervals Oil Change Interval: Refer to manual; typically every 5,000-10,000 km or annually for gearbox oil. Spark Plug Interval: Refer to manual; typically every 5,000-8,000 km. Air Filter Maintenance: Clean every 3,000-5,000 km, replace as needed. Fluid Specifications Engine Oil Type: High-quality 2-stroke synthetic oil for automatic injection systems or pre-mix (specific brands and JASO FD standard recommended). Gearbox Oil Type: API GL-4 or GL-5, SAE 75W/90 or 80W/90 gear oil (refer to manual for exact specification). Coolant Type: Ethylene glycol-based antifreeze with corrosion inhibitors, mixed 50/50 with distilled water. Brake Fluid Type: DOT 4 hydraulic brake fluid. Known Issues Carburetor Fouling: Common in 2-strokes if not properly maintained or if using incorrect oil ratios, leading to starting issues or poor running. Exhaust Carbon Buildup: Can lead to reduced performance; requires occasional cleaning or decoking. Voltage Regulator Failure: Can cause charging system issues; a common point of failure in many small motorcycles. 📚 Vehicle History Brand Heritage Manufacturer: Aprilia is an Italian manufacturer known for its sporting motorcycles, particularly in smaller displacement...
