🏷️ Basic Information Identification Make: CASE IH Model: CVX Series Tractors Product Name: CASE Tractor CVX 120 CVX 130 CVX 150 CVX 170 WSM .zip Codes Wsm Code Inferred: Workshop Service Manual 👋 Introduction Market Position Positioning: The CASE IH CVX series represents a significant advancement in tractor technology, particularly with its Continuously Variable Transmission (CVT), offering enhanced fuel efficiency, operator comfort, and productivity for a wide range of agricultural applications. Competitive Analysis Competitors: This series competed directly with other major manufacturers' CVT offerings, such as the John Deere 7030/7020 Series (AutoPowr/IVT), New Holland T7000 Series (CVT), Fendt Vario, and Claas transmissions. Key Features Cv Transmission: The signature feature is the continuously variable transmission, allowing seamless acceleration and deceleration without discrete gear shifts, optimizing engine RPM for load and fuel economy. Engine Performance: Equipped with powerful, efficient diesel engines designed for demanding agricultural work, offering high torque at low RPM. Operator Comfort: Designed with a focus on operator ergonomics, advanced cab suspension, and intuitive controls for extended working periods. 📋 Manual Details Coverage Areas Covered Models: CASE IH CVX120, CVX130, CVX150, CVX170 Inferred Production Years: 2003-2006 (approximate, based on CVX generation and common WSM distribution) Page Count Total Pages Inferred: High Volume (Likely 1000+ pages across all models/sections) Manual Type Type: Workshop Service Manual (WSM) Language Language: English (highly probable for WSM of this era and region) Format Format: Digital (ZIP archive containing PDF documents) 📖 Manual Coverage Systems Covered Powertrain: Engine overhaul, fuel system, cooling system, lubrication system, exhaust system, engine management (ECU, sensors, actuators), CVT transmission (drive components, hydraulics, control systems) Chassis And Drivetrain: Hydraulic systems (lift, PTO, auxiliary functions), drivetrain components (axles, differentials, driveshafts), PTO (Power Take-Off) system, steering system, braking system (service and parking brakes), hydraulic power steering Electrical And Electronics: Wiring diagrams, electrical component testing and troubleshooting, lighting systems, control modules (e.g., PTO, hitch control), diagnostic connectors and procedures, battery and charging systems Operator Station And Bodywork: Cab systems, HVAC (heating, ventilation, and air conditioning), operator controls, operator station layout, body panel removal and installation, safety features, lighting and signals Procedures Included Maintenance: Routine maintenance checks, lubrication points and schedules, filter replacement intervals, fluid level checks and top-offs Repair And Overhaul: Engine disassembly and reassembly, transmission component replacement, hydraulic pump and valve troubleshooting, axle and PTO repair, steering and brake system overhaul Diagnostics: Troubleshooting guides based on symptoms, diagnostic code interpretation, electrical system testing using multimeters and oscilloscopes, hydraulic system pressure testing Special Tools And Equipment: Identification and usage of specialized tools required for specific repair and maintenance procedures Technical Depth Depth: Comprehensive: Covers routine maintenance, troubleshooting, component-level repair, and full system overhauls. Includes detailed diagrams, specifications, and procedures for professional technicians. 📊 Manual Specifications File Format Format Type: ZIP Archive Document Format: Portable Document Format (PDF) Searchability: Likely text-searchable PDFs if scanned with OCR or natively digital Print Quality Quality Inferred: High-resolution digital images and text, suitable for on-screen viewing and printing. Binding Type Binding: Not Applicable (Digital Format) Paper Type Paper Type: Not Applicable (Digital Format) ⚙️ Engine Specifications Primary Engine Manufacturer: CASE IH (likely sourced from FPT Industrial/IVECO) Engine Family: Likely NEF (New Engine Family) or similar robust diesel engine Performance Cvx120 Rated Power: Approx. 120 HP (rated engine power), up to 130 HP with EPM (Engine Power Management) Cvx130 Rated Power: Approx. 130 HP (rated engine power), up to 140 HP with EPM Cvx150 Rated Power: Approx. 150 HP (rated engine power), up to 160 HP with EPM Cvx170 Rated Power: Approx. 170 HP (rated engine power), up to 180 HP with EPM Torque Curve: Designed for high torque at low engine speeds to maximize pulling power and fuel efficiency. Fuel System Injection Type: Common Rail Direct Injection (CRDI) or similar advanced diesel injection system. Emissions Standard: Likely Tier 2 or early Tier 3 emissions compliance depending on exact year and market. 🔧 Transmission Standard Type: Continuously Variable Transmission (CVT) - CASE IH's proprietary CVXDrive system. Optional Options: No conventional gearbox options; CVT is the defining feature. Features Speed Range: Infinitely variable speeds, typically from crawling pace (e.g., 0.03 mph / 0.05 km/h) up to road transport speeds (e.g., 31 mph / 50 km/h). Control Modes: Multiple operating modes (e.g., automatic, manual, PTO speed priority) allowing the operator to tailor performance to the task. Transmission Fluid: Specific hydraulic fluid required for the CVX transmission; refer to manual for exact specifications (e.g., CASE IH MS-1317, or equivalent ISO VG 46 transmission/hydraulic fluid). 📐 Dimensions Exterior Length Approx: Varies by configuration, but typically around 17-18 ft (5.2-5.5 m). Width Approx: Varies by tire and fender configuration, but typically around 8 ft (2.4 m) for road transport. Height Approx: Cab height typically around 9-10 ft (2.7-3.0 m). Weights Operating Weight Approx: Range from approximately 13,000 - 17,000 lbs (5,900 - 7,700 kg) depending on...
