GMC Canyon 2007 Service Repair Workshop Manual

Normale prijs: $142.00
Aanbiedingsprijs: $142.00
Normale prijs
Eenheidsprijs: per

🏷️ Basic Information Identification Make: GMC Model: Canyon Year: 2007 Codes Chassis Code: GMT355 👋 Introduction Market Position Segment: Compact Pickup Truck Competitive Analysis Key Competitors: Ford Ranger, Toyota Tacoma, Nissan Frontier, Mazda B-Series Key Features Vehicle Selling Points: Off-road capability (Z71 package), powerful V8 option (5.3L), rugged styling, versatile utility. Model History Context Generation Context: This manual covers the first generation (GMT355) of the GMC Canyon, which was produced from 2004 to 2012. 📋 Manual Details Coverage Areas Primary Markets: North America (USA, Canada, Mexico) Vehicle Variants: All trims including SL, SLE, and Z71 Off-Road Package variants. Page Count Estimated Pages: 1500+ Manual Type Type: Factory Service and Repair Workshop Manual Language Language: English Format Format: PDF Download 📖 Manual Coverage Systems Covered Powertrain: Engine (3.7L Vortec LLR, 5.3L Vortec LH8), Transmission (4L60-E, NV1500, NV3500, NV3550), Drivetrain (RWD, 4WD), Transfer Case Chassis: Suspension (Front: Torsion Bar Independent, Rear: Leaf Spring Solid Axle), Steering (Hydraulic Power), Brakes (Front: Disc, Rear: Disc/Drum), Frame and Body Electrical: Wiring Diagrams, Lighting, Power Accessories, HVAC Controls, Powertrain Control Module (PCM), Body Control Module (BCM), Instrument Cluster, Safety Systems Body And Interior: Interior Trim, Seats, Headliner, Door Panels, Exterior Body Panels, Bumpers, Grille, Bed Liner, Towing Features Comfort And Convenience: HVAC system, power windows/locks, remote keyless entry, interior lighting, seat adjustments. Procedures Included Maintenance: Scheduled Maintenance, Oil Changes, Fluid Checks and Replacements, Filter Replacements, Tune-Ups Repair: Engine Mechanical Repair, Transmission Overhaul, Drivetrain Component Replacement, Suspension and Steering Component Repair, Brake System Service, Electrical Component Diagnosis and Repair, Body Panel Replacement, HVAC System Service Troubleshooting: Diagnostic Trouble Codes (DTCs), Symptom-Based Troubleshooting, Electrical System Diagnostics, Engine Performance Issues, Transmission Shifting Problems Diagnostics: On-Board Diagnostics (OBD-II) system interpretation, diagnostic tools and procedures, fault tracing for all major systems. Installation: Optional accessory installation guidance where applicable within the scope...

28 people are viewing this right now

Type: Truck

Verkoper:

Sku: 534431

Collecties: ALL GMC

Beschikbaarheid: Op voorraad

Labels: 2007 Canyon Cars GMC Truck

Productvarianten

Description

🏷️ Basic Information

Identification

Make:

Model:

Canyon

Year:

Codes

Chassis Code:

GMT355

👋 Introduction

Market Position

Segment:

Compact Pickup Truck

Competitive Analysis

Key Competitors:

Ford Ranger, Toyota Tacoma, Nissan Frontier, Mazda B-Series

Key Features

Vehicle Selling Points:

Off-road capability (Z71 package), powerful V8 option (5.3L), rugged styling, versatile utility.

Model History Context

Generation Context:

This manual covers the first generation (GMT355) of the GMC Canyon, which was produced from 2004 to 2012.

📋 Manual Details

Coverage Areas

Primary Markets:

North America (USA, Canada, Mexico)

Vehicle Variants:

All trims including SL, SLE, and Z71 Off-Road Package variants.

Page Count

Estimated Pages:

1500+

Manual Type

Type:

Factory Service and Repair Workshop Manual

Language

Language:

English

Format

Format:

PDF Download

📖 Manual Coverage

Systems Covered

Powertrain:

Engine (3.7L Vortec LLR, 5.3L Vortec LH8), Transmission (4L60-E, NV1500, NV3500, NV3550), Drivetrain (RWD, 4WD), Transfer Case

Chassis:

Suspension (Front: Torsion Bar Independent, Rear: Leaf Spring Solid Axle), Steering (Hydraulic Power), Brakes (Front: Disc, Rear: Disc/Drum), Frame and Body

Electrical:

Wiring Diagrams, Lighting, Power Accessories, HVAC Controls, Powertrain Control Module (PCM), Body Control Module (BCM), Instrument Cluster, Safety Systems

Body And Interior:

Interior Trim, Seats, Headliner, Door Panels, Exterior Body Panels, Bumpers, Grille, Bed Liner, Towing Features

Comfort And Convenience:

HVAC system, power windows/locks, remote keyless entry, interior lighting, seat adjustments.

Procedures Included

Maintenance:

Scheduled Maintenance, Oil Changes, Fluid Checks and Replacements, Filter Replacements, Tune-Ups

Repair:

Engine Mechanical Repair, Transmission Overhaul, Drivetrain Component Replacement, Suspension and Steering Component Repair, Brake System Service, Electrical Component Diagnosis and Repair, Body Panel Replacement, HVAC System Service

Troubleshooting:

Diagnostic Trouble Codes (DTCs), Symptom-Based Troubleshooting, Electrical System Diagnostics, Engine Performance Issues, Transmission Shifting Problems

Diagnostics:

On-Board Diagnostics (OBD-II) system interpretation, diagnostic tools and procedures, fault tracing for all major systems.

Installation:

Optional accessory installation guidance where applicable within the scope of factory service.

Technical Depth

Depth:

Comprehensive: From basic maintenance to complete engine and transmission rebuilds, including diagnostic procedures.

Diagnostic Tools:

Covers the use of GM's official diagnostic software (e.g., Tech 2) and procedures for accessing real-time data and performing component tests.

📊 Manual Specifications

File Format

PDF Features:

Searchable text, Bookmarked chapters, High-resolution images and diagrams

Compatibility:

Compatible with Windows and macOS operating systems.

Print Quality

Printability:

Full print capability of single pages or the entire manual.

Binding Type

Digital Binding:

N/A (Digital Download)

Paper Type

Digital Paper Type:

N/A (Digital Download)

⚙️ Engine Specifications

Primary Engine

Engine 1 Displacement:

3.7L (3700 cc)

Engine 1 Configuration:

Inline-5 (Vortec LLR)

Engine 1 Horsepower:

242 hp @ 5600 rpm

Engine 1 Torque:

242 lb-ft @ 4600 rpm

Optional Engine

Engine 2 Displacement:

5.3L (5328 cc)

Engine 2 Configuration:

V8 (Vortec LH8 OHV)

Engine 2 Horsepower:

305 hp @ 5200 rpm

Engine 2 Torque:

338 lb-ft @ 4000 rpm

Fuel System

Fuel Delivery:

Multi-Port Fuel Injection (MPFI)

Recommended Fuel:

87 Octane Unleaded Gasoline

Engine 1 Engine Code

Engine 1 Code:

Engine 2 Engine Code

Engine 2 Code:

🔧 Transmission

Standard Transmission

Transmission 1 Type:

5-Speed Manual (NV1500/NV3500)

Optional Transmission

Transmission 2 Type:

4-Speed Automatic (4L60-E)

Features

Drivetrain Options:

Rear-Wheel Drive (RWD), Four-Wheel Drive (4WD)

📐 Dimensions

Exterior

Wheelbase:

111.3 inches (Standard Cab/Extended Cab)

Overall Length:

192.4 inches (Standard Box)

Body Style:

Regular Cab, Extended Cab

Wheelbase Options:

111.3 in (short box), 126.0 in (long box for extended/crew cab)

Cargo

Bed Length:

72.9 inches (Standard Box)

Weights

Curb Weight Range:

Approx. 3,700 - 4,400 lbs

Gross Vehicle Weight Rating Gvwr Range:

5,300 - 5,600 lbs

🛡️ Safety Features

Ratings

NHTSA Rollover Resistance:

4/5 stars (for most configurations)

Active Features

Standard Safety:

Anti-lock Braking System (ABS), Traction Control System (TCS), StabiliTrak Electronic Stability Control (on some models)

Braking System:

Front: Vented Disc, Rear: Disc (4WD) or Drum (2WD)

Passive Features

Airbags:

Driver and Front Passenger Airbags, Available Side Curtain Airbags

💡 Technology Features

Infotainment

Audio System:

AM/FM Stereo with CD player, available MP3 capability, and auxiliary input jack.

Driver Assistance

Assist Systems:

Cruise Control, available Parking Assist Sensors (rear).

Connectivity

Connectivity Features:

OnStar communications system (subscription-based), available Bluetooth for hands-free calling.

🔧 Maintenance

Service Intervals

Oil Change Interval:

Every 7,500 miles or 6 months (whichever comes first) under normal driving conditions.

Tire Rotation Interval:

Every 7,500 miles

Coolant Flush Interval:

Every 5 years or 100,000 miles (initially)

Fluid Specifications

Engine Oil Specification:

SAE 5W-30 Synthetic Blend (LLR), SAE 5W-30 Synthetic (LH8)

Transmission Fluid Specification Automatic:

Dexron VI

Transmission Fluid Specification Manual:

GM Synchromesh (specific part number will be detailed in manual)

Coolant Specification:

GM Delco-GM Radiant Solution (Blue)

Power Steering Fluid:

GM Power Steering Fluid (refer to manual for specific part number or specification)

Known Issues

Common Complaints:

Minor oil leaks (valve cover gaskets, oil pan gaskets), potential for wheel bearing issues, transmission shift quality concerns (especially on early models), some reports of catalytic converter failure.

Recall Information:

The manual will detail any applicable Technical Service Bulletins (TSBs) and recalls for the 2007 model year, aiding in diagnosing and rectifying common faults.

Fluid Capacities

Engine Oil Capacity 3.7L:

6.0 US quarts (5.7 L)

Engine Oil Capacity 5.3L:

6.0 US quarts (5.7 L)

Coolant Capacity 3.7L:

11.4 US quarts (10.8 L)

Coolant Capacity 5.3L:

12.0 US quarts (11.4 L)

Automatic Transmission Fluid Capacity:

10.0 US quarts (9.5 L) for a fluid change

Rear Axle Fluid Capacity:

Approx. 2.0 - 3.0 US quarts (depending on axle ratio and differential type, GL-5 gear oil)

📚 Vehicle History

Brand Heritage

Gmc Legacy:

GMC (General Motors Truck Company) has a long history of producing commercial and recreational trucks.

Model Evolution

Canyon Introduction:

The Canyon was introduced for the 2004 model year as a successor to the GMC Sonoma, sharing its platform with the Chevrolet Colorado.

Production

Manufacturing Location:

Shreveport, Louisiana, USA; Wentzville, Missouri, USA

🏆 Awards & Recognition

Recognitions

Industry Recognition:

While specific awards for the 2007 GMC Canyon are not prominently documented, it was part of a generation that was generally well-regarded for its ruggedness and utility in the compact truck segment.
