🏷️ Basic Information Identification Make: Harley-Davidson Model: FLHTCUTG TRIKE Tri Glide Ultra Classic Year: 2013 Codes Chassis Code: FLHTCUTG 👋 Introduction Market Position Target Audience: Mechanics and DIY individuals seeking comprehensive repair and maintenance information. Key Features Ease Of Use: Simple and precise explanations, supported by photographs, notes, drawings, schematics, and exploded diagrams. Comprehensiveness: Contains data, characteristics, instructions, and methodology for all repair interventions and maintenance operations. Value Proposition Benefit: Enables satisfactory after-services and efficient repair work, ensuring the vehicle is kept in optimum condition. 📋 Manual Details Coverage Areas General: Complete repair and service information for the 2013 Harley-Davidson FLHTCUTG TRIKE Tri Glide Ultra Classic. Page Count Total Pages: 2210 Manual Type Type: Workshop Service Manual Language Language: English Format File Format: PDF 📖 Manual Coverage Systems Covered Powertrain: Engine, transmission, clutch, drivetrain, exhaust system. Chassis: Frame, suspension (front and rear), steering, wheels, tires, brakes (front and rear), braking system. Electrical: Battery, charging system, ignition system, lighting system, instruments, gauges, wiring diagrams, ECM, security system. Bodywork And Trim: Body panels, fairings, seat, storage compartments, fenders, accessories, trim components. Procedures Included Maintenance: Periodic maintenance, lubrication, fluid checks and changes, filter replacements, inspections. Diagnostics: Troubleshooting procedures, fault diagnosis, diagnostic trouble codes (DTCs), testing methods. Repair: Component removal, installation, disassembly, assembly, adjustments, replacement procedures for all major systems. Technical Data: Specifications, tolerances, torque values, wear limits, measurement procedures, service data. Technical Depth Depth: Comprehensive, detailed step-by-step procedures with pictorial diagrams, including fundamental principles, basic interventions, and advanced diagnostics. 📊 Manual Specifications File Format Quality: High-resolution PDF, printable pages, searchable text. Print Quality Printability: All pages are printable. Binding Type Digital Format: Instant Download PDF. Paper Type Digital Requirement: Adobe Reader required for viewing. Compatibility Operating Systems: Compatible with Windows, Mac, and Linux OS. ⚙️ Engine Specifications Primary Engine Engine Type: Twin Cam 103 (1690cc) V-Twin engine. Performance Torque: Refer to manual for specific torque figures for engine components. Expected peak torque around 100-110 lb-ft. Fuel System Fuel Delivery: Electronic Sequential Port Fuel Injection (ESPFI). Cooling Cooling System: Air-cooled. 🔧 Transmission Standard Transmission Type: 6-speed Cruise Drive manual transmission. Features Drive Type: Belt final drive. Fluid Specifications Transmission Fluid Type: Harley-Davidson Formula Plus or equivalent SAE 90 API GL-5 gear oil. 📐 Dimensions Exterior Wheelbase: Approx. 101.2 inches (2570 mm) Weights Dry Weight: Approx. 1194 lbs (541 kg) Gross Vehicle Weight Rating Gvwr: Approx. 1578 lbs (716 kg) 🛡️ Safety Features Active Features Braking System: Linked front and rear braking system, hydraulic disc brakes front and rear. Passive Features Lighting: Halogen headlight, LED taillight and brake lights, turn signals. Precautions Tool Usage: Emphasis on using correct special service tools and equipment; avoidance of makeshift tools. Fastener Torque: Importance of adhering to specified torque values for all threaded connections. 💡 Technology Features Infotainment Audio System: Boom! Box 6.5 GT infotainment system with touchscreen, GPS, Bluetooth connectivity, CB/PA. Driver Assistance Cruise Control: Electronic cruise control. Connectivity Usb Port: Likely includes USB connectivity for audio devices and charging. Comfort Features Ergonomics: Designed for long-distance touring comfort with a comfortable seat, rider backrest, and passenger amenities. 🔧 Maintenance Service Intervals Oil Change Interval: Refer to the periodic maintenance chart within the manual. Typically 5,000 miles or 12 months for engine oil. Fluid Specifications Engine Oil Type: Harley-Davidson SYN3 Full Synthetic Motorcycle Oil (20W-50) or approved alternative. Primary Chain Case Fluid: Harley-Davidson Primary Chain Case Lubricant or approved Formula+ (refer to manual for specific type). Brake Fluid Type: DOT 4 brake fluid. Known Issues Common Wear Items: Brake pads, tires, clutch components, primary drive components. Manual details inspection and replacement procedures. Maintenance Schedule Chart Availability: Includes a periodic maintenance chart outlining recommended service intervals and tasks. 📚 Vehicle History Brand Heritage Manufacturer: Harley-Davidson Motor Company, an iconic American motorcycle manufacturer with a rich history dating back to 1903. Model Evolution Trike Development: The Tri Glide Ultra Classic represents Harley-Davidson's commitment to the three-wheeled touring segment, building upon their long-standing expertise in touring motorcycles. 🏆 Awards & Recognition Recognitions Touring Capabilities: Consistently recognized for its touring prowess and comfort, making it a leader in the premium trike market.
