🏷️ Basic Information Identification Make: Tesla Model: Model X Year: 2017 Codes Product Code: Not Specified 👋 Introduction Market Position Segment: Luxury Electric SUV Competitive Analysis Competitors: Audi e-tron, Mercedes-Benz EQC, Porsche Cayenne (ICE and Hybrid), BMW X5 (ICE and Hybrid), Rivian R1S. Key Features Unique Selling Points: All-electric drivetrain, Falcon Wing Doors, spacious interior, advanced Autopilot features, large touchscreen interface, superior performance and range in its class at the time of release. Target Audience Audience: Tesla owners, independent repair shops, automotive technicians specializing in electric vehicles, and technical enthusiasts. 📋 Manual Details Coverage Areas Market Regions: Left-Hand Drive (LHD) and Right-Hand Drive (RHD) releases Page Count Estimated Page Count: Approximately 500-800 pages (estimated for comprehensive wiring diagrams) Manual Type Type: Electrical Wiring Diagram Manual / Service Manual Supplement Language Language: English Format Format: PDF 📖 Manual Coverage Systems Covered Electrical Systems: Comprehensive coverage of all electrical circuits including powertrain, chassis, body, infotainment, and safety systems. Body Electronics: Detailed diagrams for doors, windows, mirrors, lighting, wipers, and HVAC electrical components. Powertrain Electronics: Wiring for electric motors, battery management system (BMS), charging system, and inverter. (Specific to Model X electric drivetrain). Infotainment System: Diagrams for the central touchscreen, audio system, navigation, and connectivity modules. Driver Assistance Systems: Wiring related to Autopilot hardware (cameras, radar, ultrasonic sensors) and control modules. Safety Systems: Diagrams for airbags, seatbelt pretensioners, ABS, ESC, and other active/passive safety features. Procedures Included Diagnostic Procedures: Tracing of electrical circuits for troubleshooting and fault diagnosis. Component Identification: Identification of electrical components, connectors, pinouts, and wire colors. Fuse And Relay Identification: Location and function of fuses and relays within various electrical circuits. Ground Point Locations: Diagrams illustrating various chassis and body ground points. Wiring Schematics: Detailed wiring schematics for all major electrical systems, including component locations, connector pinouts, wire routing, and harness information. Troubleshooting Charts: System-specific troubleshooting charts and diagnostic flowcharts based on common electrical faults. Component Replacement: Information to support the removal and installation of electrical components, including connector removal and harness repair procedures where applicable. Technical Depth Depth: Advanced diagnostic and repair level, suitable for professional technicians and experienced DIYers. System Diagnostics: In-depth diagnostics for complex integrated systems like the thermal management, battery management, and Autopilot suite. Component Level Repair: Provides the detailed electrical information necessary for component-level troubleshooting and repair, rather than just module replacement. 📊 Manual Specifications File Format Format: PDF File Size: 36 MB Print Quality Quality: High-resolution diagrams, suitable for printing on A3 or larger format for clarity. Binding Type Binding Type: N/A (Digital PDF) Paper Type Paper Type: N/A (Digital PDF) ⚙️ Engine Specifications Primary Engine Configuration: Dual Motor All-Wheel Drive (AWD) - Permanent magnet synchronous reluctance motors front and rear. Performance Horsepower: Model X 75D: 325 hp (242 kW); Model X 90D: 417 hp (311 kW); Model X P90D: 514 hp (383 kW) with Ludicrous Mode. Torque: Significant instant torque due to electric motors, torque figures not directly comparable to ICE vehicles. Fuel System Type: All-Electric (Battery Electric Vehicle - BEV) Battery System Type: Lithium-ion battery pack (75 kWh, 90 kWh, 100 kWh variants). 🔧 Transmission Standard Type: Single-speed gear reduction (front and rear) Optional Options: N/A (All Model X are AWD with dual motors) Features Features: Regenerative braking, electronically controlled. 📐 Dimensions Exterior Length: Approx. 5,037 mm (198.3 in) Width: Approx. 2,070 mm (81.5 in) (excluding mirrors) Height: Approx. 1,684 mm (66.3 in) Weights Curb Weight: Approx. 2,350 - 2,460 kg (5,180 - 5,423 lbs) depending on battery size. Gross Vehicle Weight Rating: Approx. 3,000 kg (6,614 lbs) Cargo Cargo Volume Rear: Approx. 2,158 liters (76.2 cu ft) with rear seats folded. Cargo Volume Front: Approx. 187 liters (6.6 cu ft) (frunk). 🛡️ Safety Features Ratings NHTSA Rating: 5-Star Overall Safety Rating (NHTSA). IIHS Rating: Top Safety Pick (IIHS). Active Features Active Safety: Autopilot (Adaptive Cruise Control, Autosteer), Automatic Emergency Braking (AEB), Lane Departure Warning (LDW), Blind Spot Monitoring (BSM), Collision Avoidance Assist. Passive Features Airbags: Front airbags, side airbags, curtain airbags, knee airbags. Chassis Structure: Reinforced battery pack structure providing a low center of gravity and enhanced structural rigidity. 💡 Technology Features Infotainment Central Display: 17-inch capacitive touchscreen with integrated controls for vehicle functions, navigation, media, and climate. Software Updates: Over-the-air (OTA) software updates for continuous improvement and new features. Driver Assistance Autopilot Hardware: Includes forward-facing camera, radar, and 12 ultrasonic sensors for 360-degree awareness. Connectivity Connectivity Options: LTE connectivity for OTA updates and remote access via mobile app, Wi-Fi connectivity. Other Tech Keyless Entry Start: Key card or smartphone app for vehicle access and operation. Charging Port: Tesla proprietary Supercharger and mobile connector ports. 🔧 Maintenance Service Intervals Tire Rotation: Recommended every 10,000 km (6,250 miles) or as per tire wear. Cabin Air Filter: Recommended every 2 years or 30,000 km (18,750 miles). Brake Fluid: Recommended fluid check annually, replacement...
