🏷️ Basic Information Identification Make: Jaguar Model: E-Type Series: Series 3 Body Style: 2+2 Fixed Head Coupe Model Years Covered: 1971-1975 👋 Introduction Market Position Vehicle Class: Luxury Grand Tourer / Sports Car Target Audience: Affluent buyers seeking performance and style Competitive Analysis Key Competitors: Ferrari Daytona, Aston Martin DBS, Chevrolet Corvette C3 (later models) Key Features Design Language: Iconic Sir Alec Issigonis and Malcolm Sayer styling Engine Introduction: First Jaguar with the V12 engine, a significant engineering feat Body Configuration: Long-wheelbase 2+2 coupe, offering practicality alongside performance 📋 Manual Details Coverage Areas Manual Type: Parts Catalog Language: English Format: Printed Page Count: Approx. 400+ Typical Sections: Chassis, Engine, Transmission, Electrical, Body, Accessories 📖 Manual Coverage Systems Covered Engine Components: V12 Engine (5.3L), Carburetors, Ignition System, Cooling System, Lubrication System Transmission Components: Manual Transmission (Moss Gearbox), Automatic Transmission (TorqueFlite A727) Drivetrain Components: Rear Axle, Driveshafts, Half-Shafts Suspension Components: Front Suspension (Indep.), Rear Suspension (Indep., IRS) Braking Components: Front Disc Brakes, Rear Disc Brakes, Master Cylinder, Servo Unit Steering Components: Power Steering System Electrical Components: Wiring Harnesses, Lighting, Gauges, Starter Motor, Alternator Body And Trim: Body Panels, Doors, Hood, Trunk, Bumpers, Interior Trim, Seats, Glass Fuel System Components: Fuel Tank, Fuel Pump, Fuel Lines, Carburetors Exhaust System Components: Exhaust Manifolds, Mufflers, Pipes Procedures Included Part Identification: Detailed diagrams and part numbers for every component Assembly Disassembly: Visual guidance on how major assemblies are put together and taken apart Component Replacement: Illustrates specific parts for replacement during service or restoration Interchangeability: May indicate superseded or interchangeable parts where applicable Technical Depth Depth Level: Comprehensive Parts Identification Diagnostic Focus: Not a diagnostic manual, focuses on component identification and part numbers Restoration Utility: Essential for accurate restoration, sourcing correct parts Maintenance Focus: Supports identification of maintenance-related parts 📊 Manual Specifications File Format Print Quality: Typically printed on durable paper, often with black and white diagrams Binding Type: Often bound in a sturdy cover for workshop use Paper Type: Durable paper stock, suitable for workshop environments Searchability: Physical index by section, not digitally searchable like a PDF Diagrams: Detailed exploded-view diagrams ⚙️ Engine Specifications Primary Engine Engine Type: Jaguar V12 (V12 E Type) Displacement: 5343 cc (5.3 Litres) Bore X Stroke: 85.6 mm x 77.0 mm Compression Ratio: 8.8:1 Performance Horsepower Gross: Approx. 272 bhp (DIN) @ 5850 rpm Torque Gross: Approx. 326 lb-ft (DIN) @ 3600 rpm Fuel System Carburetor Type: Four Zenith-Stromberg 1.75" CDSE twin-choke carburetors (early models had Weber 2bbl carburetors) Fuel Type: Premium Unleaded Gasoline (95 RON or higher recommended) Ignition System Ignition Type: Electronic Ignition (Lucas) Cooling System Cooling Type: Water-cooled Lubrication System Oil Capacity: Approx. 11.3 Litres (10 Imp. Quarts) Oil Filter Part Number: Cross Reference often needed, e.g., Fram PH8A, Wix 51515 (verify for exact fitment) 🔧 Transmission Standard Transmission Type: 4-speed Manual (Moss Gearbox) Optional Transmission Type: 3-speed Automatic (Chrysler TorqueFlite A727) Features Gear Ratios Manual: Typically: 1st: 2.878, 2nd: 1.775, 3rd: 1.235, 4th: 1.00 (Final Drive: 3.31:1) Gear Ratios Automatic: Typically: 1st: 2.45, 2nd: 1.45, 3rd: 1.00 (Final Drive: 2.88:1 or 3.07:1) Fluid Type Manual Fluid Specification: GL-4 Hypoid Gear Oil (SAE 90) Fluid Type Automatic Fluid Specification: Dexron-III (or equivalent ATF) 📐 Dimensions Exterior Wheelbase: 2591 mm (102 inches) Length: 4717 mm (185.7 inches) Width: 1734 mm (68.3 inches) Height: 1265 mm (49.8 inches) Front Track: 1308 mm (51.5 inches) Rear Track: 1270 mm (50 inches) Weights Curb Weight: Approx. 1728 kg (3809 lbs) Gross Vehicle Weight: Approx. 2000 kg (4400 lbs) Wheels And Tires Wheel Size: 15 x 6J Wheel Bolt Pattern: 5 x 120.65 mm Tire Size Standard: 205 VR 15 🛡️ Safety Features Ratings Crash Test Data: No formal modern crash test ratings available for this era Active Features Braking System: Four-wheel Dunlop hydraulic disc brakes with servo assistance Passive Features Seatbelts: Lap belts standard, shoulder belts optional/later fitment Chassis Construction: Body-on-frame construction with monocoque elements 💡 Technology Features Infotainment Audio System: Optional AM/FM Radio, often with a single speaker Gauges: Comprehensive dashboard with tachometer, speedometer, oil pressure, water temperature, voltmeter, fuel gauge Driver Assistance Power Steering: Standard power-assisted steering Air Conditioning: Optional Air Conditioning system Connectivity Connectivity Features: None (designed prior to modern connectivity standards) 🔧 Maintenance Service Intervals Oil Change Interval: Every 3,000 miles or 6 months (recommended, especially for older engines) Tune Up Interval: Every 12,000 miles or 12 months (includes ignition, carb adjustment) Coolant Flush: Every 24,000 miles or 24 months Fluid Specifications Engine Oil Specification: 20W-50 or 20W-50 HD (Castrol GTX recommended by some specialists) Coolant Specification: Ethylene Glycol based coolant, 50/50 mix with distilled water Brake Fluid Specification: DOT 4 Power Steering Fluid: Automatic Transmission Fluid (ATF) Known Issues Engine Reliability: V12 can be complex, prone to overheating if cooling system is neglected. Carburetor tuning is critical. Suspension Wear: IRS (Independent Rear Suspension) bushings and universal...
