🏷️ Basic Information Identification Make: EZ-GO Model: RXV, RXV Freedom, RXV Shuttle 2+2 Year: 2009 Vehicle Type: Golf Car / Personal Transportation Vehicle Powertrain Type: Gasoline Powered Product Name: 2009 EZ-GO RXV RXV Freedom RXV SHUTTLE 2+2 GASOLINE POWERED GOLF CARS & PERSONAL VEHICLES Service Repair Manual Codes Oem Manual Code Reference: Referenced as factory service information 👋 Introduction Market Position Market Segment: Premium golf cars and personal transportation vehicles for golf courses, resorts, and private communities. Competitive Analysis Key Competitors: Club Car (Precedent, DS), Yamaha (G-Series, Drive). Key Features Vehicle Distinguishing Features: The RXV (Revolutionary Experience Vehicle) platform offered advanced features for its time, including a sophisticated AC drive system (though this manual covers gasoline models), independent front suspension for superior ride quality, and the 'Possession' braking system. 📋 Manual Details Coverage Areas Primary Coverage: Complete service and repair for 2009 EZ-GO RXV, RXV Freedom, and RXV Shuttle 2+2 gasoline models. Page Count Estimated Page Count: Approximately 250-350 pages (typical for comprehensive factory service manuals). Manual Type Manual Type: Factory Service Repair Manual Language Language: English Format Format: Digital (PDF) / Print (Implied by sale of manual) 📖 Manual Coverage Systems Covered Engine And Fuel System: Engine overhaul, troubleshooting, fuel delivery, carburetor, ignition, exhaust systems, emission controls. Drivetrain And Transmission: Clutch, drive belt, transaxle service, lubrication, repair procedures. Brakes: Brake system diagnosis, component replacement (master cylinder, lines, calipers/drums), parking brake adjustment. Steering And Suspension: Steering column, tie rods, wheel alignment, suspension components, shock absorbers, bushings. Electrical System: Wiring diagrams, battery service, starter/generator, lighting, sensors, electronic control units (ECUs), fuses, relays. Chassis And Body: Frame inspection, body panel removal/installation, seat mounting, roof, windshield, trim components. Procedures Included Maintenance Procedures: Scheduled maintenance, oil changes, filter replacements, lubrication points, spark plug service. Troubleshooting Guides: Diagnostic flowcharts for common performance issues, starting problems, braking issues, and electrical faults. Repair And Overhaul: Detailed step-by-step instructions for component disassembly, cleaning, inspection, repair, and reassembly. Specifications And Tolerances: Torque specifications, clearances, fluid capacities, wear limits, and critical measurements. Technical Depth Depth Of Coverage: Comprehensive, covering everything from routine maintenance to complete engine and transaxle rebuilds, and advanced electrical diagnostics. 📊 Manual Specifications File Format Digital File Type: PDF (Portable Document Format), optimized for readability and searchability. Print Quality Digital Print Quality: High-resolution digital reproduction of original factory documentation, ensuring clear text and diagrams. Binding Type Physical Binding Type: N/A (for digital format) / Likely spiral-bound or saddle-stitched for physical copies. Paper Type Physical Paper Type: N/A (for digital format) / Typically heavy-duty, coated paper for durability in a workshop environment. ⚙️ Engine Specifications Primary Engine Engine Manufacturer: Robin (Subaru Industrial Power Products) / Kawasaki (common for this era). Engine Model Displacement: Likely a 4-stroke, overhead valve gasoline engine, typically around 240-300cc (e.g., Robin EX21, EX27, or Kawasaki FE290/FE350 variants). Engine Type: Naturally Aspirated, Single Cylinder (common configuration). Performance Horsepower Output: Typically in the range of 7-11 HP (gross) depending on specific engine model. Torque Output: Not typically published in readily available specs, but sufficient for golf course and light personal transport duty. Fuel System Fuel Delivery System: Carburetor (e.g., Mikuni or Keihin). Fuel Type: Unleaded Gasoline Fuel Tank Capacity: Approximately 2.5 - 3.0 gallons (9.5 - 11.4 liters). Ignition System Ignition Type: Transistor Controlled Ignition (TCI), electronic ignition. 🔧 Transmission Standard Transmission Type: Continuously Variable Transmission (CVT) with belt drive. Optional Optional Transmission: N/A (CVT is standard for gasoline models). Features Drive System: Rear-wheel drive. Gear Reduction: Internal reduction gears within the transaxle. Specific ratios documented in the manual. Transmission Fluid Type: Specific gear oil, as per manufacturer's recommendation (e.g., SAE 90 or specific synthetic blend). 📐 Dimensions Exterior Overall Length: Approximately 94-96 inches (239-244 cm). Overall Width: Approximately 47-48 inches (119-122 cm). Overall Height: Approximately 71-73 inches (180-185 cm) with roof. Interior Seating Capacity: 2 or 4 (depending on RXV, RXV Freedom, RXV Shuttle 2+2 designation). Weights Curb Weight: Approximately 600-700 lbs (272-318 kg). Payload Capacity: Typically around 800-1000 lbs (363-454 kg). 🛡️ Safety Features Ratings Safety Certification: Not rated by government agencies like NHTSA or IIHS as they are not road-legal vehicles in most jurisdictions without modification. Active Features Braking System: Hydraulic drum brakes, with mechanical parking brake. Lighting: Headlights, taillights, brake lights (standard on many configurations). Passive Features Seatbelts: Optional or standard depending on configuration/market. Windshield: Standard safety glass or polycarbonate windshield. 💡 Technology Features Infotainment Infotainment System: Basic; typically includes a horn, battery indicator (for electric variants), and potentially a simple hour meter or speedometer. Driver Assistance Driver Assistance Features: Limited; primary safety features are braking and steering. Some models may have optional diagnostic ports for system checks. Connectivity Connectivity Options: None typically offered on this model year. 🔧 Maintenance Service Intervals Engine Oil Change: Every 50-100 operating hours or annually, whichever comes first. Consult manual for specific interval based on usage....
