🏷️ Basic Information Identification Make: Kia Model: Sportage Model Generation: SL (Third Generation) Model Years Covered: 2011, 2012 Engine Code: G 2.4 DOHC (Theta II GDI/MPI) Codes Chassis Code: SL 👋 Introduction Market Position Segment: Compact SUV / Crossover Target Audience: DIY enthusiasts, independent repair shops, fleet maintenance Competitive Analysis Competitors 2011 2012: Honda CR-V, Toyota RAV4, Ford Escape, Chevrolet Equinox, Hyundai Tucson Key Features Vehicle Styling: Distinctive 'tiger nose' grille, aerodynamic profile Powertrain Options: Available with 2.4L GDI/MPI engine and 6-speed manual or automatic transaxles Drivetrain: Front-Wheel Drive (FWD) standard, All-Wheel Drive (AWD) optional Key Features Manual Value Proposition: Empowers users to perform their own repairs, saving time and money Accuracy Source: Derived from original factory documentation 📋 Manual Details Coverage Areas All Systems: Yes Engine Mechanical: Yes Engine Electrical: Yes Fuel System: Yes Emission Control System: Yes Manual Transaxle: Yes (M6GF2) Automatic Transaxle: Yes Driveshaft Axle: Yes 4 Wheel Drive System: Yes Brake System: Yes Clutch System: Yes Body Interior Exterior: Yes HVAC System: Yes Restraint System: Yes Page Count Estimated Page Count: Varies (Factory Manuals are extensive, likely over 1500 pages digitally) Manual Type Type: Factory Service Manual (FSM) / Repair Manual Language Language: English Format Format: PDF Download Method: Instant Download 📖 Manual Coverage Systems Covered All Major Automotive Systems: Yes Procedures Included Maintenance Procedures: Yes (Oil changes, fluid checks, filter replacements, etc.) Diagnostic Procedures: Yes (Troubleshooting flowcharts, DTC explanations) Repair Procedures: Yes (Component removal, installation, and adjustment) Overhaul Procedures: Yes (Engine, transmission, axle rebuilds) Electrical Troubleshooting: Yes (Wiring diagrams, circuit testing) Specifications And Tolerances: Yes Technical Depth Depth: Comprehensive (From basic maintenance to complete vehicle disassembly and reassembly) Detail Level: Step-by-step instructions with detailed diagrams and illustrations 📊 Manual Specifications File Format Compatibility: Windows & Mac Required Software: Adobe PDF Reader, WinZip Print Quality Digital Zoom: High (Allows for clear viewing of details) Binding Type Digital Format Advantage: Zoomable, searchable, easy to navigate Paper Type Digital Format Description: Electronic version, no physical paper ⚙️ Engine Specifications Primary Engine Engine Code: Theta II G 2.4 DOHC Displacement: 2359 cc (2.4 Liters) Configuration: Inline-4 (I4) Valvetrain: DOHC (Dual Overhead Camshafts), 16 Valves Performance Horsepower Approx: 175-182 hp @ 6000 rpm (varies slightly by specific market/calibration) Torque Approx: 169-178 lb-ft @ 4000 rpm (varies slightly by specific market/calibration) Fuel System Induction: Multi-Port Fuel Injection (MPI) or Gasoline Direct Injection (GDI) depending on specific variant Fuel Type: Unleaded Gasoline Technical Details Bore X Stroke: 86.7 mm x 97.0 mm (typical for Theta II 2.4) Compression Ratio: 10.5:1 (typical for Theta II 2.4 MPI) 🔧 Transmission Standard Manual Transaxle: M6GF2 (6-Speed Manual) Optional Automatic Transaxle: 6-Speed Automatic (e.g., A6GF1 or similar) Features Automatic Transmission Modes: Includes manual shifting mode (Sport mode) on some trims Fluid Type Automatic Transaxle Fluid Spec: Refer to manual for specific ATF type (e.g., SPIII, SP-IV or equivalent) Manual Transaxle Fluid Spec: Refer to manual for specific gear oil type and viscosity (e.g., GL-4, 75W-90) 📐 Dimensions Exterior Length: Approx. 4,440 mm (174.8 inches) Width: Approx. 1,800 mm (70.9 inches) Height: Approx. 1,645 mm (64.8 inches) Wheelbase: Approx. 2,640 mm (103.9 inches) Weights Curb Weight: Approx. 1,500-1,600 kg (3,300-3,500 lbs), depending on drivetrain and options Cargo Cargo Volume Seats Up: Approx. 340-370 Liters (12-13 cu ft), depending on market configuration Cargo Volume Seats Down: Approx. 1,500-1,600 Liters (53-56 cu ft), depending on market configuration 🛡️ Safety Features Ratings NHTSA Front Crash Test: 5-Star (for 2011-2012 models tested) IIHS Top Safety Pick: Yes (for models equipped with specific safety features) Active Features ABS: Standard Esc: Electronic Stability Control (Standard) Traction Control: Standard Brake Assist: Standard Passive Features Airbags: Front, Side, and Curtain Airbags (standard on most trims) 💡 Technology Features Infotainment Audio System: Standard AM/FM/CD/MP3 with SiriusXM capability, optional premium audio systems. Connectivity Options: Auxiliary audio input, USB port, Bluetooth hands-free connectivity available on higher trims. Driver Assistance Parking Assist: Rearview camera and parking sensors available on higher trims. Keyless Entry Start: Available with push-button start on higher trims. 🔧 Maintenance Service Intervals Oil Change Interval: Typically every 5,000-7,500 miles (8,000-12,000 km) or 6-12 months, depending on driving conditions (refer to manual). Air Filter Replacement: Typically every 15,000-30,000 miles (24,000-48,000 km). Cabin Air Filter Replacement: Typically every 12,000-15,000 miles (19,000-24,000 km). Coolant Flush Interval: First at 60,000 miles (96,000 km), then every 30,000 miles (48,000 km) or 2-3 years. Transmission Fluid Change Interval: Automatic: typically 60,000-100,000 miles (96,000-160,000 km) under normal conditions (check manual). Manual: inspect regularly, fluid change as needed. Fluid Specifications Engine Oil Viscosity: 0W-20 is common for the Theta II engine (API SN or higher). Engine Oil Capacity: Approx. 4.6-4.8 Liters (4.8-5.1 US Quarts) with filter change. Coolant Type: Paraflu-type coolant, typically an Asian vehicle blue or green antifreeze. Known Issues Engine Oil Consumption: Some Theta II engines have been known to consume oil;...
