This manual covers the YFM700RV Raptor 700 All-Terrain Vehicle (ATV) for production years 2005 through 2009, encompassing all styles. Renowned for its robust engineering and high-performance capabilities, the Raptor 700 is a benchmark in the sport ATV category, building on an extensive legacy in powersports. Its liquid-cooled, 686cc engine, equipped with Electronic Fuel Injection (EFI), delivers substantial power and torque, making it suitable for demanding off-road use. The vehicle features a sophisticated chassis, hydraulic disc brakes, and a 5-speed transmission with reverse, all contributing to its reputation for reliability and exhilarating performance. This comprehensive Workshop Service Repair Manual provides in-depth guidance for maintaining and repairing your YFM700RV Raptor 700. It covers all essential areas, including detailed procedures for engine mechanicals, fuel and cooling systems, electrical diagnostics, chassis components, and body repair. With step-by-step instructions, detailed illustrations, and troubleshooting guides, this manual is an invaluable resource for both DIY enthusiasts and professional technicians. It empowers users to perform everything from routine scheduled maintenance, such as oil changes and filter replacements, to complete engine and transmission rebuilds, ensuring optimal performance and longevity of the ATV. 🏷️ Basic Information Identification Make: Yamaha Model: YFM700RV Raptor 700 Vehicle Type: All-Terrain Vehicle (ATV) Production Years Covered By Manual: 2005, 2006, 2007, 2008, 2009 Trim Levels Covered: All styles covered 👋 Introduction Market Position Target Audience: DIY enthusiasts and experienced mechanics. Competitive Analysis Value Proposition: Provides dealer-level service information at a fraction of the cost, enabling owners to maintain and repair their ATVs effectively. Key Features Content Accuracy: Complete and intact, no missing or corrupt pages. Accessibility: iPad-ready format, compatible with all major operating systems. 📋 Manual Details Coverage Areas Primary Coverage: Workshop Service and Repair Secondary Coverage: Maintenance, Troubleshooting, Electrical Diagnostics, Body Repair Page Count Total Pages: > 400 pages Manual Type Type: Workshop Service Repair Manual Language Language: English Format File Format: PDF Compatibility: Windows, Mac, Linux Delivery Delivery Method: Instant Download Protection Digital Rights Management: DRM-free 📖 Manual Coverage Systems Covered Powertrain: Engine Mechanical, Engine Control System, Fuel System, Lubrication System, Cooling System, Ignition System, Starting System, Charging System, Transmission System (Manual Transaxle Assy) Chassis: Brake System, Steering System, Suspension System (Front and Rear), Wheel and Tire System, Drive Shaft, Drive Belt Electrical: Electrical System, Lighting System, Combination Meter, Wiring Diagrams, Combination Meter, Starter Assy, Alternator Body: Body Repair, Exterior Trim, Interior Components, Seat Systems, Handlebars, Fenders Procedures Included Maintenance: Scheduled Maintenance, Fluid Changes, Filter Replacements, Lubrication Points, Valve Clearance Adjustment Repair: Complete Disassembly and Reassembly, Component Overhaul, Part Replacement, Engine Rebuild, Transmission Repair, Brake System Overhaul, Suspension Component Replacement Diagnostics: Troubleshooting Guides, Symptom-Based Diagnostics, Electrical System Diagnosis, Engine Performance Diagnosis, Error Code Interpretation Technical Depth Depth Level: Comprehensive: From basic maintenance to complete engine and transmission rebuilds, including detailed electrical troubleshooting and wiring diagrams. Instruction Style: Step-by-step instructions with detailed illustrations, drawings, and photos. 📊 Manual Specifications File Format Quality: High Quality PDF, Searchable, Printable Print Quality Printability: All pages are printable Binding Type Binding: N/A (Digital Download) Paper Type Paper Type: N/A (Digital Download) Features Navigability: Bookmarked Table of Contents, Bold Figure Numbers for quick illustration matching. ⚙️ Engine Specifications Primary Engine Engine Type: Liquid-cooled, 4-stroke, DOHC, 5-valve, Single Cylinder Displacement: 686cc Bore X Stroke: 100.0 mm x 83.9 mm Compression Ratio: 9.2:1 Performance Horsepower: Approx. 53 HP @ 6000 RPM (spec varies by market and tuning) Torque: Approx. 54 lb-ft @ 5500 RPM (spec varies by market and tuning) Fuel System Fuel Delivery: Electronic Fuel Injection (EFI) Fuel Type: Unleaded gasoline (91 octane or higher recommended) Ignition System Ignition Type: TCI (Transistor Controlled Ignition) 🔧 Transmission Standard Transmission Type: Constant-mesh 5-speed, Reverse Clutch Type: Wet, multi-plate Drive System Final Drive: O-ring sealed chain Fluid Specifications Transmission Fluid: Yamalube 4 (or equivalent) 10W-40 API SG or higher (refer to manual for exact spec and capacity) 📐 Dimensions Exterior Length: Approx. 72.1 inches (1830 mm) Width: Approx. 46.1 inches (1170 mm) Height: Approx. 45.1 inches (1145 mm) Weights Dry Weight: Approx. 427 lbs (194 kg) Fuel Capacity: 3.4 gal (12.8 L) Dimensions Wheelbase: Approx. 50.4 inches (1280 mm) Ground Clearance: Approx. 11.2 inches (285 mm) 🛡️ Safety Features Ratings Crash Test Results: N/A (ATVs are not subjected to the same crash testing as passenger vehicles.) Active Features Braking System: Hydraulic disc brakes front and rear. Passive Features Rollover Protection: N/A (Riders are responsible for proper riding techniques.) 💡 Technology Features Infotainment Infotainment System: N/A (Performance-focused ATV with minimal creature comforts). Driver Assistance ABS: N/A Connectivity Smartphone Integration: N/A Lighting Headlights: Dual Halogen headlights. 🔧 Maintenance Service Intervals Oil Change Interval: Refer to manual: typically every 3,000-5,000 km or annually. Severe use may require more frequent changes. Air Filter Cleaning: Refer to manual: typically every 1,000-2,000 km or as needed based on operating conditions. Valve Clearance Check: Refer to manual: typically every 5,000-10,000...
