🏷️ Basic Information Identification Make: Honda Model: Pilot Year: 2007 Generation Generation: First Generation (2003-2008) Codes Chassis Code: YF1 👋 Introduction Market Position Market Segment: Mid-size SUV, Family Utility Vehicle Competitive Analysis Competitors 2007: Toyota Highlander, Ford Explorer, Chevrolet TrailBlazer, Nissan Pathfinder Key Features Vehicle Selling Points: Spacious interior, comfortable ride, reliable V6 engine, available AWD, three rows of seating. Manual Value Proposition Diy Benefit: Empowers DIY mechanics to perform repairs and maintenance, saving significant costs compared to professional service. Manual Advantage Digital Vs Print: Offers superior convenience, searchability, and up-to-date information compared to traditional printed manuals. 📋 Manual Details Coverage Areas Primary Coverage: Complete Service and Repair Secondary Coverage: Maintenance, Diagnostics, Troubleshooting Page Count Estimated Page Count: Extensive (Digital Format, No Fixed Page Count) Manual Type Type: Online Service and Repair Manual Software Language Language: English Format Format: Web-based Application / Digital Access 📖 Manual Coverage Systems Covered Engine: 3.5L V6 VTEC (J35A7) Drivetrain: 5-Speed Automatic Transmission (5AT), All-Wheel Drive (VTM-4) Suspension: Front Independent MacPherson Strut, Rear Independent Multi-Link Steering: Power Rack and Pinion Brakes: Front Ventilated Discs, Rear Solid Discs, ABS, EBD, Brake Assist Electrical: Full Electrical System, Wiring Diagrams, ECM/PCM, Lighting, Power Accessories HVAC: Heating, Ventilation, Air Conditioning System Components and Operation Body: Exterior Body Panels, Interior Trim, Doors, Windows, Seats Safety Systems: Airbag System, Seat Belt Systems Procedures Included Maintenance: Oil Changes, Filter Replacements, Fluid Checks and Replacements, Spark Plugs, Belts Repair: Engine Overhaul, Transmission Repair, Suspension Component Replacement, Brake System Service, Electrical Component Diagnosis and Repair Diagnostics: Troubleshooting Flowcharts, DTC Code Explanations, Component Testing Procedures Installation: Component Installation and Removal Procedures Technical Depth Depth: Comprehensive: From basic maintenance to advanced diagnostics and full component overhauls. 📊 Manual Specifications File Format Accessibility: Accessible via web browser on PC, Laptop, Smartphone, Tablet Print Quality Printability: Digital content designed for on-screen viewing; print functionality dependent on user's device and browser. Binding Type Binding: N/A (Digital Format) Paper Type Paper: N/A (Digital Format) Licensing Licensing Status: Officially Licensed, Derived from OE Materials Access Duration Subscription Period: 1 Year Access Included (Discounted renewals available) ⚙️ Engine Specifications Primary Engine Engine Code: J35A7 Engine Type: 3.5 Liter SOHC VTEC V6 Bore X Stroke: 90.0 mm x 93.0 mm (3.54 in x 3.66 in) Compression Ratio: 9.9:1 Performance Horsepower: 244 hp @ 5600 rpm Torque: 240 lb-ft @ 4500 rpm Fuel System Fuel Delivery: Programmed Fuel Injection (PGM-FI) Fuel Type: Unleaded Regular 87 Octane Engine Management Ignition System: Distributorless Ignition System (DIS) with Coil-on-Plug ECU Type: ECM/PCM with OBD-II Diagnostics 🔧 Transmission Standard Transmission Type: 5-Speed Automatic Transmission (5AT) Optional Drive Type: All-Wheel Drive (VTM-4 - Variable Torque Management 4-Wheel Drive) Features Vtm4 System: Includes lock-up feature for enhanced traction in slippery conditions. Fluid Specs Atf Type: Honda Genuine ATF-DW1 (formerly ATF-Z1) Fluid Capacity Atf Capacity Drain Refill: Approximately 3.3 US quarts (3.1 Liters) 📐 Dimensions Exterior Length: 192.4 inches (4887 mm) Width: 77.5 inches (1969 mm) Height: 72.9 inches (1852 mm) Wheelbase: 110.2 inches (2799 mm) Ground Clearance: 8.0 inches (203 mm) Weights Curb Weight FWD: 4,200 lbs (1905 kg) Curb Weight AWD: 4,387 lbs (1990 kg) Gross Vehicle Weight Rating: 5,750 lbs (2608 kg) Cargo Cargo Volume Behind 3Rd Row: 16.7 cu ft (473 L) Cargo Volume Behind 2Nd Row: 47.6 cu ft (1348 L) Cargo Volume Behind 1St Row: 96.5 cu ft (2733 L) 🛡️ Safety Features Ratings NHTSA Frontal Crash Driver: 5 Stars NHTSA Frontal Crash Passenger: 5 Stars NHTSA Side Crash Driver: 5 Stars NHTSA Side Crash Rear Passenger: 5 Stars IIHS Roof Strength: Good IIHS Side Impact: Good Active Features ABS: Standard Anti-lock Braking System Ebd: Standard Electronic Brake-force Distribution Brake Assist: Standard Brake Assist Traction Control: Standard Traction Control System (VSA) Stability Control: Standard Vehicle Stability Assist (VSA) Passive Features Airbags: Front, Front Side, and Three-Row Side Curtain Airbags Seat Belts: 3-Point Seat Belts with Pretensioners and Load Limiters Child Seat Anchors: LATCH (Lower Anchors and Tethers for CHildren) System 💡 Technology Features Infotainment Audio System: Available premium audio system with AM/FM stereo, CD player, MP3 capability, and auxiliary input jack. Optional DVD Entertainment System. Navigation: Optional factory navigation system available on higher trim levels. Driver Assistance Rearview Camera: Available rearview camera system integrated with navigation display. Connectivity Power Outlets: Multiple 12V accessory power outlets. 🔧 Maintenance Service Intervals Oil Change Interval: Every 7,500 miles (12,000 km) or 1 year, whichever comes first (using synthetic oil recommended by Honda). Atf Change Interval: Every 60,000 miles (96,000 km) or 4 years for normal driving conditions. Severe conditions may require more frequent changes. Spark Plug Replacement: iridium-tipped spark plugs: 100,000 miles (160,000 km) Fluid Specifications Engine Oil Spec: SAE 5W-20, API Certified (Honda recommends Genuine Honda Synthetic Motor Oil) Engine Oil Capacity: 4.5 US quarts (4.3 Liters) with filter change Coolant Type: Honda Genuine All Season Antifreeze/Coolant...
