🏷️ Basic Information Identification Make: Citroen Model: Xsara Picasso Year: 2002 Generation Generation: First Generation (Phase 1) Codes Chassis Code: N0 👋 Introduction Market Position Segment: Compact MPV (Multi-Purpose Vehicle) Competitive Analysis Competitors: Renault Scenic, Ford Focus C-Max, Volkswagen Touran Key Features Design Philosophy: Spacious interior, high seating position, flexible seating arrangements, distinctive Citroen styling. Target Audience: Families, individuals seeking practicality and comfort in a compact package. 📋 Manual Details Coverage Areas Coverage: Full Service, Repair, Maintenance, Diagnostics, Wiring Diagrams, Troubleshooting, Rebuilding, Refurbishing, Restoration Page Count Page Count: Not Specified (Implied comprehensive) Manual Type Type: Full Service Repair Manual Language Language: English Format File Format: PDF 📖 Manual Coverage Systems Covered Powertrain: Engine (various variants), Transmission (manual & automatic), Fuel System, Cooling System, Exhaust System, Ignition System Chassis: Suspension (front & rear), Steering System, Braking System (front & rear discs, ABS), Wheels and Tires Electrical: 12V Electrical System, Battery, Alternator, Starter Motor, Lighting System, Ignition System, Fuel Injection System, Engine Management System, Instrument Panel, Wiper System, Horn, Audio System, Power Windows, Central Locking Body: Body Structure, Exterior Panels, Doors, Hood, Tailgate, Interior Trim, Seats, Glass, Bumpers, Seals Procedures Included Maintenance: Scheduled Maintenance, Oil and Filter Changes, Fluid Level Checks and Replenishment, Spark Plug Replacement, Air Filter Replacement, Fuel Filter Replacement, Brake Pad and Rotor Replacement, Tire Rotation and Balancing Repair: Engine Overhaul, Transmission Repair, Clutch Replacement, Suspension Component Replacement (struts, shocks, bushings), Brake System Repair (calipers, master cylinder), Steering Rack Repair, Exhaust System Repair, Electrical Component Diagnosis and Replacement, Body Panel Repair and Replacement Diagnostics: On-Board Diagnostics (OBD-II), Engine Fault Diagnosis, Transmission Fault Diagnosis, Electrical System Troubleshooting, ABS System Diagnosis, Airbag System Diagnosis Technical Depth Depth: Comprehensive: Covers basic DIY maintenance to advanced professional-level diagnostics and full rebuilds. Includes detailed sub-steps, notes, cautions, and warnings. 📊 Manual Specifications File Format File Format: PDF Print Quality Printability: Full Printable Binding Type Binding: Digital (Downloadable PDF) Paper Type Paper Type: N/A (Digital) Requirements Software Requirements: Adobe PDF Reader, WinRAR Compatibility Operating Systems: All Versions of Windows & Mac ⚙️ Engine Specifications Primary Engine Engine Options: Likely includes 1.6L (8v/16v) petrol, 1.8L 16v petrol, 2.0L 16v petrol, 1.9L (DW8/DW10) Diesel (HDI) Performance Typical Horsepower Range: Petrol: 90-137 hp (approx.); Diesel: 90-110 hp (approx.) Typical Torque Range: Petrol: 135-187 Nm (approx.); Diesel: 200-250 Nm (approx.) Fuel System Fuel Delivery Petrol: Multi-point Fuel Injection (MPI) Fuel Delivery Diesel: Common Rail Direct Injection (CRDi) for HDI variants Cooling System Coolant Type: Antifreeze coolant (e.g., Citroen Total GLACELF AUTO SUPRA) - Specific type and ratio to be confirmed in manual. Ignition System Spark Plugs: Refer to manual for specific types (e.g., NGK, Champion) and gap specifications. 🔧 Transmission Standard Transmission Type: 5-speed Manual Optional Transmission Type: Likely AL4 4-speed Automatic Features Automatic Features: Tiptronic functionality (manual selection), often prone to specific valve body issues. Fluid Specifications Manual Gearbox Oil: Refer to manual for specific SAE grade and API classification (e.g., SAE 75W-80 API GL-4). Automatic Transmission Fluid: Likely LT71141 or equivalent (e.g., Mobil ATF LT 71141) - Critical for AL4. 📐 Dimensions Exterior Length: Approx. 4260 mm Width: Approx. 1750 mm Height: Approx. 1640 mm Cargo Boot Capacity: Approx. 550 liters (expandable with folded seats) Weights Kerb Weight: Approx. 1300 - 1450 kg (depending on engine and specification) 🛡️ Safety Features Ratings Euro Ncap Rating: 4 Stars (at launch) Active Features Braking System: Front ventilated discs, Rear solid discs, ABS (Anti-lock Braking System), EBD (Electronic Brakeforce Distribution) Stability Control: ESP (Electronic Stability Program) may be optional on some higher trims. Passive Features Airbags: Driver, Passenger, Front Side Airbags; potential for Curtain Airbags on higher trims. Seatbelts: Pre-tensioned seatbelts with force limiters 💡 Technology Features Infotainment Audio System: Factory fitted CD player or radio/cassette with speaker system. Steering wheel audio controls likely on higher trims. Navigation: Optional factory fitted GPS navigation system was available on some models. Driver Assistance Cruise Control: Available as an option on certain engine and trim levels. Connectivity Auxiliary Input: Unlikely to have standard AUX or USB input; aftermarket solutions may be required. 🔧 Maintenance Service Intervals Oil Change Interval: Typically every 12,500 miles or 1 year, whichever comes first. Consult manual for specific engine variants and oil types. Timing Belt Interval: For petrol and diesel engines with timing belts, typically 60,000-80,000 miles or 5 years. Crucial to replace as per manual. HDI engines often use a timing chain (maintenance-free). Fluid Specifications Engine Oil Type Petrol: Likely 5W-40 or 5W-30 (synthetic) meeting PSA B71 2294 or ACEA A3/B4 standards. Verify in manual. Engine Oil Type Diesel: Likely 5W-40 or 5W-30 (synthetic) meeting PSA B71 2294 or ACEA A3/B4 / C3 standards. Verify in manual for HDI. Brake Fluid Type: DOT 4 Power Steering Fluid: Citroen proprietary fluid (e.g., Citroen LHM PLUS or a compatible fluid). Critical to use correct fluid. Known Issues Common Faults:...
