🏷️ Basic Information Identification Make: Hyundai Model: Tucson Year: 2013 Generation Generation: Second Generation (LM) Codes Chassis Code: LM 👋 Introduction Market Position Positioning: Compact Crossover SUV Competitive Analysis Competitors: Honda CR-V, Toyota RAV4, Ford Escape, Nissan Rogue, Kia Sportage Key Features Design Philosophy: Fluidic Sculpture design language Licensing: Officially licensed, derived from OE (Original Equipment) materials by RepairSurge Access Duration: 1 Year of access, with discounts for extended access 📋 Manual Details Coverage Areas Primary Coverage: Factory Service and Repair Information Scope: Comprehensive diagnostics, repair, maintenance, and specifications Page Count Estimated Pages: Thousands (Digital Format) Manual Type Type: Service and Repair Manual (Software) Language Language: English Format Format: Online Digital Access (Web Browser Based) 📖 Manual Coverage Systems Covered Powertrain: Engine mechanical, engine management, fuel system, cooling system, exhaust system, drivetrain (FWD/AWD), transmission (automatic/manual) Chassis: Suspension, steering, brakes (hydraulic, ABS, ESC), wheels, tires Electrical: Body electrical systems, lighting, power accessories, instrument cluster, diagnostic connectors, wiring diagrams HVAC: Heating, ventilation, and air conditioning (HVAC) system Body And Interior: Body panels, doors, windows, seats, interior trim, airbags Procedures Included Maintenance: Scheduled maintenance, fluid changes, filter replacements, inspections Repair: Component removal and installation, system diagnosis and repair, troubleshooting guides Diagnostics: OBD-II diagnostics, diagnostic trouble code (DTC) interpretation, symptom-based troubleshooting Specifications: Torque specifications, clearances, fluid capacities, electrical specifications Technical Depth Depth: Factory-level detail, covering basic maintenance to complex component overhaul and electronic system diagnosis 📊 Manual Specifications File Format Accessibility: Web-based, accessible via PC, laptop, smartphone, tablet with internet connection Print Quality Print Capability: Printable pages available Binding Type Binding: N/A (Digital) Paper Type Paper Type: N/A (Digital) ⚙️ Engine Specifications Primary Engine Engine Code Gasoline 2.4L: Theta II G4KC Engine Type 2.4L: 2.4L Inline-4 DOHC MPI Engine Displacement 2.4L: 2359 cc (143.9 cu in) Horsepower 2.4L: 176 hp @ 6000 rpm (approx.) Torque 2.4L: 169 lb-ft @ 4000 rpm (approx.) Optional Engine Engine Code Gasoline 2.0L: Theta II G4KD Engine Type 2.0L: 2.0L Inline-4 DOHC MPI Engine Displacement 2.0L: 1998 cc (121.9 cu in) Horsepower 2.0L: 164 hp @ 6200 rpm (approx.) Torque 2.0L: 147 lb-ft @ 4600 rpm (approx.) Performance Compression Ratio 2.4L: 10.5:1 Bore X Stroke 2.4L: 88.0 mm x 97.0 mm Fuel System Fuel Delivery: Multi-Point Fuel Injection (MPI) Recommended Fuel: 87 Octane Unleaded Gasoline Engine Management ECU: ECM (Engine Control Module) with CAN bus communication 🔧 Transmission Standard Standard Transmission: 6-Speed Automatic (Optional on 2.0L, Standard on 2.4L) Optional Optional Transmission: 6-Speed Manual (Available on select 2.0L models) Features Automatic Features: Shiftronic manual mode, adaptive learning control Fluid Specs Automatic Transmission Fluid Type: Hyundai SPII ATF (or equivalent) - Refer to manual for specific part number Gear Ratios Automatic Gear Ratios: Refer to manual for detailed ratios by model/engine 📐 Dimensions Exterior Length: 174.0 in (4420 mm) Width: 72.7 in (1847 mm) Height: 65.2 in (1656 mm) Wheelbase: 104.7 in (2659 mm) Ground Clearance: 7.2 in (183 mm) Cargo Cargo Volume Behind 2Nd Row: 25.7 cu ft (728 L) Cargo Volume With 2Nd Row Folded: 54.8 cu ft (1552 L) Weights Curb Weight FWD 2.0L: 3331 lbs (1511 kg) Curb Weight AWD 2.4L: 3560 lbs (1615 kg) Towing Capacity: 1000-2000 lbs (450-900 kg) depending on configuration and region Wheels Tires Wheelbase Bolt Pattern: 5x114.3 mm (5x4.5 inches) Standard Wheel Size: 17-inch Alloy Optional Wheel Size: 18-inch Alloy Standard Tire Size: 225/65R17 Optional Tire Size: 235/55R18 🛡️ Safety Features Ratings NHTSA Overall Rating: 4 out of 5 stars (for AWD models tested in 2013) IIHS Top Safety Pick: Yes (for models built after a certain date in 2012/2013) Active Features Active Safety Systems: Electronic Stability Control (ESC), Traction Control System (TCS), Anti-lock Braking System (ABS), Electronic Brake-force Distribution (EBD), Brake Assist (BA) Passive Features Passive Safety Features: Advanced front airbags, front-seat side-impact airbags, roof-side curtain airbags (front and rear), active front head restraints 💡 Technology Features Infotainment Infotainment Options: Available touchscreen infotainment system with navigation, Bluetooth, USB/Aux inputs Driver Assistance Driver Assistance Features: Optional rearview camera, parking assist sensors Connectivity Connectivity Features: Bluetooth hands-free calling and audio streaming 🔧 Maintenance Service Intervals Oil Change Interval: 7,500 miles (12,000 km) or 6 months, whichever comes first (under normal driving conditions) Tire Rotation Interval: 7,500 miles (12,000 km) Engine Air Filter Replacement: Every 30,000 miles (48,000 km) or as needed Cabin Air Filter Replacement: Every 15,000 miles (24,000 km) or as needed Spark Plug Replacement 2.4L: 100,000 miles (160,000 km) with Iridium-tipped plugs Fluid Specifications Engine Oil Type 2.4L: SAE 0W-20 Synthetic Engine Oil Capacity 2.4L: 4.8 US quarts (4.5 liters) with filter change Coolant Type: Hyundai Long Life Coolant (Blue) - Ethylene Glycol Based Coolant Capacity: Approx. 7.7 US quarts (7.3 liters) Brake Fluid Type: DOT 3 or DOT 4 Known Issues Common Complaint 1: Potential for oil consumption on higher mileage 2.4L engines (check for piston ring issues) Common...
