🏷️ Basic Information Identification Make: Kawasaki Model: KLR500/KLR650 Year: 1990 Codes Chassis Code: KLR650-A10 (typical for 1990 model) 👋 Introduction Market Position Positioning: Essential technical documentation for owners and independent mechanics seeking to maintain and repair the Kawasaki KLR500/KLR650 Competitive Analysis Analogy: A vital tool for DIY enthusiasts and professional workshops, offering the same depth of information found in official Kawasaki service manuals Key Features Benefit Diy: Empowers users to perform repairs independently, saving on labor costs and ensuring quality Benefit Knowledge: Provides in-depth understanding of vehicle systems for better maintenance and emergency preparedness Accessibility: Convenient digital download for immediate access on multiple devices 📋 Manual Details Coverage Areas Primary Coverage: Complete service, repair, and maintenance for Kawasaki KLR500 and KLR650 models Secondary Coverage: Troubleshooting, diagnostics, electrical systems, wiring diagrams Page Count Estimated Page Count: Approximately 300-500 pages (typical for comprehensive service manuals) Manual Type Type: Service and Repair Manual Language Language: English Format Format: Digital Download (PDF) 📖 Manual Coverage Systems Covered Engine Service Repair: Detailed procedures for disassembly, inspection, repair, and reassembly of the engine Transmission Service Repair: Service procedures for the gearbox, clutch, and final drive Brake System: Service, repair, and bleeding procedures for front and rear brakes Electrical System: Comprehensive coverage including starting, ignition, lighting, and accessory systems Wiring Diagram: Detailed electrical wiring schematics for easy troubleshooting and repair Suspension: Service and adjustment of front forks and rear shock absorber Steering: Maintenance and repair of the steering head and handlebars Cooling System: Service and maintenance of the liquid cooling system (radiator, fan, coolant) Fuel Injection Fuel System: Diagnosis and repair of the fuel delivery system (carburetor or early EFI depending on exact variant) Emission System: Information related to emission control components and their service Engine Control System: Details on the ECU, sensors, and actuators for engine management Chassis Body: Maintenance and repair of the frame, body panels, and associated components Restraint System: Details on any safety restraints (though typically limited on motorcycles of this era) Axle: Service and maintenance of front and rear axles and wheel bearings Procedures Included General Maintenance: Routine checks, adjustments, and scheduled maintenance tasks Troubleshooting: Systematic approach to diagnosing and resolving common and uncommon issues Periodic Lubrication: Specific lubrication points, intervals, and recommended lubricants Reassembly Disassembly: Step-by-step instructions for taking apart and putting back together various components Refurbishing Renovating: Guidance on restoring components to optimal condition Technical Depth Depth: Comprehensive, from basic owner maintenance to full engine and component overhauls 📊 Manual Specifications File Format File Format Details: PDF, requires Adobe PDF Reader Compression: May require WinZip or similar for extraction Print Quality Printability: Designed for digital viewing but typically printable for workshop use Binding Type Binding Type: Not applicable (digital product) Paper Type Paper Type: Not applicable (digital product) ⚙️ Engine Specifications Primary Engine Engine Type: 4-stroke, DOHC, 4-valve, single-cylinder Displacement: 500cc (KLR500), 651cc (KLR650) Bore X Stroke: KLR500: 92.0 x 75.0 mm; KLR650: 100.0 x 83.0 mm (typical) Cooling System: Liquid-cooled Performance Horsepower: KLR650 (typical): approx. 42-45 HP @ 6500 RPM; KLR500: approx. 35-38 HP @ 6500 RPM Torque: KLR650 (typical): approx. 37-40 lb-ft @ 5000 RPM Fuel System Fuel Delivery: KLR500: Carburetor (e.g., Keihin CVK34); KLR650: Carburetor (e.g., Keihin CVK40 or similar) Fuel Type: Unleaded gasoline, 87 octane or higher recommended 🔧 Transmission Standard Transmission Type: 5-speed constant mesh Features Clutch Type: Wet multi-plate, manual operation Final Drive: Sealed O-ring chain 📐 Dimensions Exterior Length: KLR650 (typical): approx. 2240 mm (88.2 in) Width: KLR650 (typical): approx. 875 mm (34.4 in) Height: KLR650 (typical): approx. 1385 mm (54.5 in) Weights Dry Weight: KLR650 (typical): approx. 175 kg (386 lbs) Wet Weight: KLR650 (typical): approx. 198 kg (437 lbs) 🛡️ Safety Features Ratings Crash Test Ratings: N/A (Motorcycle - safety focuses on rider protection and vehicle stability) Active Features Braking System Front: Single 260mm disc with dual-piston caliper Braking System Rear: Single 240mm disc with single-piston caliper Passive Features Lighting: Halogen headlight, tail light, brake lights, turn signals 💡 Technology Features Infotainment Infotainment System: N/A (Basic motorcycle instrumentation: speedometer, odometer, trip meter, tachometer, indicator lights) Driver Assistance ABS: N/A (ABS was not a standard or common option for this model year) 🔧 Maintenance Service Intervals Oil Change Interval: Every 6,000 km (3,700 miles) or 6 months, whichever comes first (typical) Air Filter Cleaning: Every 6,000 km (3,700 miles) or 6 months (typical) Spark Plug Replacement: Every 12,000 km (7,500 miles) (typical) Fluid Specifications Engine Oil Type: SAE 10W-40, API SG or higher, JASO MA certified Engine Oil Capacity: Approx. 2.4 L (2.5 US qt) with filter change (typical) Coolant Type: Permanent type antifreeze coolant, 50/50 mix with distilled water Known Issues Cam Chain Tensioner: Potential wear on the automatic cam chain tensioner (ACT), leading to noise. Manual replacement is often preferred. Doohickey Upgrade: The balancer shaft lever (nicknamed 'doohickey') can fail....
