🏷️ Basic Information Identification Make: Kawasaki Model: KLR600 Years Covered: 1984, 1985, 1986 Vehicle Type: Dual-Sport Motorcycle Codes Chassis Code General: KL600-A 👋 Introduction Market Position Segment: Mid-size dual-sport motorcycle Target Audience: Owners, mechanics, and enthusiasts seeking in-depth maintenance and repair information Competitive Analysis Competitors Era: Honda XR series, Yamaha XT series, Suzuki DR series Key Features Versatility: Designed for both on-road and off-road riding, contributing to its dual-sport classification Durability: Known for robust construction and reliability, making it a popular choice for adventure and commuting. 📋 Manual Details Coverage Areas Primary Focus: Repair and Service Market Segment: Factory Repair Manual Page Count Total Pages: 171 Manual Type Type: Service Manual / Repair Manual Language Language: English Format Format: PDF (Downloadable) 📖 Manual Coverage Systems Covered Engine: Complete overhaul, top-end, bottom-end, valve adjustment, timing, lubrication, cooling system Fuel System: Carburetor (cleaning, adjustment, rebuilding, jetting, mixture screw, pilot jet, main jet), fuel tank, fuel pump, fuel lines Drivetrain: Clutch operation and adjustment, transmission gears, shift mechanism, primary reduction gear, drive shaft Suspension: Front forks (oil change, seal replacement, spring replacement), rear shock absorber, linkage, swingarm Brakes: Front and rear brake system inspection, maintenance, caliper overhaul, pad replacement, fluid flush, hydraulic system troubleshooting Electrical System: Ignition system (spark plug, coil, magneto), charging system (stator, rectifier, battery), lighting system, starter motor, switches Bodywork And Frame: Frame inspection, plastic panel removal and installation, fenders, seat, handlebars, triple tree Procedures Included Maintenance: Scheduled maintenance, oil changes, filter replacements, chain adjustment, lubrication points, tire pressure checks Troubleshooting: Diagnosing common problems (no spark, starting issues, poor performance), error code interpretation (if applicable to the era, though EFI not typical for 84-86 KLR600) Repair: Complete tear-down and rebuild procedures for all major components, component-specific repair instructions Installation: Instructions for installing specific parts or accessories (though primary focus is on factory configuration) Technical Depth Depth: Comprehensive (from basic maintenance to full engine rebuild) Visual Aids: Includes pictures and part diagrams Data Tables: Includes torque specifications, fluid specifications, and general data 📊 Manual Specifications File Format File Type: PDF Print Quality Printing Restriction: No restrictions on printing Binding Type Binding: Digital (N/A - printable) Paper Type Paper Quality: Digital (N/A - printable) Features Searchability: Searchable PDF text Navigation: Clickable chapters Saving: No restrictions on saving/burning to disc ⚙️ Engine Specifications Primary Engine Type: Four-stroke, single-cylinder, DOHC Displacement: 564 cc (34.4 cubic inches) Bore X Stroke: 90.0 mm x 44.0 mm (3.54 in x 1.73 in) Compression Ratio: 9.0:1 Performance Horsepower Estimate: Approximately 38-40 hp (at crank, estimates vary by source) Torque Estimate: Approximately 32-34 lb-ft (at crank, estimates vary by source) Fuel System Carburetor: Keihin CVK36 (Constant Velocity Carburetor) Fuel Type: Unleaded gasoline Cooling System Cooling Method: Liquid-cooled 🔧 Transmission Standard Type: 5-speed constant mesh Features Clutch Type: Wet multi-disc Final Drive: O-ring sealed chain 📐 Dimensions Exterior Length Overall: Approximately 2225 mm (87.6 in) Width Overall: Approximately 845 mm (33.3 in) Height Overall: Approximately 1235 mm (48.6 in) Weights Dry Weight: Approximately 151 kg (333 lbs) Wet Weight: Approximately 170 kg (375 lbs) Wheels Tires Front Tire Size: 3.00-21 4PR Rear Tire Size: 4.60-17 4PR Front Wheel Size: 21 inch Rear Wheel Size: 17 inch 🛡️ Safety Features Ratings Safety Features: Dual disc front brakes for enhanced stopping power (compared to single disc) and a rear drum brake. Active Features Braking System: Hydraulic disc front brake, mechanical drum rear brake Passive Features Frame Construction: Strong steel frame designed for off-road durability and on-road stability. 💡 Technology Features Infotainment Infotainment System: Not applicable (vintage motorcycle) Driver Assistance Driver Assistance Features: Not applicable (vintage motorcycle) Connectivity Connectivity Options: Not applicable (vintage motorcycle) 🔧 Maintenance Service Intervals Engine Oil Change: Every 3,000 km (1,860 miles) or 6 months, whichever comes first Air Filter Cleaning: Every 1,500 km (930 miles) or 3 months Valve Clearance Check: Every 6,000 km (3,730 miles) or 12 months Spark Plug Replacement: Every 6,000 km (3,730 miles) or 12 months Fluid Specifications Engine Oil Type: API SE, SF, SG or SH; SAE 10W-40 (recommended) Engine Oil Capacity: 2.0 L (2.1 US qt) without filter change; 2.2 L (2.3 US qt) with filter change Coolant Type: Permanent type antifreeze (ethylene glycol based) mixed with distilled water, 50/50 ratio Coolant Capacity: Approximately 1.8 L (1.9 US qt) Brake Fluid Type: DOT 3 or DOT 4 hydraulic brake fluid Known Issues Carburetor Idling: Can sometimes develop an unstable idle or require frequent adjustment due to wear on the throttle shaft or mixture screw. Stator Reliability: While generally reliable, stators can fail over time, impacting charging system performance. Fork Seals: Fork seal leaks are common with age and use, requiring periodic replacement. 📚 Vehicle History Brand Heritage Kawasaki Motorcycles: Kawasaki Heavy Industries has a long history of producing reliable and performance-oriented motorcycles across various categories. Model Evolution Klr Lineage: The KLR600 was...
