The Yamaha Rhino YXR700 700 Fi, produced for the 2008 and 2009 model years, stands as a capable Utility Side-by-Side (SxS) or Recreational Off-Highway Vehicle (ROV). Engineered for demanding tasks such as work, hunting, and recreational trail riding, it distinguishes itself with a robust design philosophy emphasizing reliable, off-road performance and rider comfort. Key features include a fuel-injected 686cc parallel-twin engine for enhanced throttle response and efficiency, coupled with an independent suspension system that ensures an excellent ride quality. These attributes position the Rhino YXR700 Fi as a strong contender in its segment, offering a blend of utility and capability. This comprehensive factory service manual provides essential guidance for the maintenance, repair, and troubleshooting of your Yamaha Rhino YXR700 700 Fi. It covers all major systems, including the engine, drivetrain, chassis, suspension, and electrical systems, detailing procedures from routine maintenance like oil changes and filter replacements to complete component overhauls and advanced diagnostics. With detailed technical specifications, wiring diagrams, and fault-finding charts, this manual is an indispensable resource for owners, mechanics, and technicians aiming to preserve the performance, reliability, and longevity of their vehicle. 🏷️ Basic Information Identification Make: Yamaha Model: Rhino YXR700 Model Variant: 700 Fi Years Covered: 2008, 2009 Codes Chassis Code: YXR700 👋 Introduction Market Position Segment: Utility Side-by-Side (SxS) / Recreational Off-Highway Vehicle (ROV) Purpose: Designed for work, hunting, and recreational trail riding. Competitive Analysis Competitors: Kawasaki Mule, Polaris Ranger, Arctic Cat Prowler Key Features Design Philosophy: Robust, reliable, capable off-road performance with a focus on utility and rider comfort. Differentiators: Fuel-injected engine for improved throttle response and efficiency, independent suspension for excellent ride quality. 📋 Manual Details Coverage Areas Primary Coverage: Service, Repair, Workshop, Troubleshooting Secondary Coverage: Maintenance, Diagnostics, Technical Specifications, Wiring Diagrams Page Count Estimated Pages: Hundreds (as described in product information) Manual Type Type: Factory Service Manual / Workshop Manual Language Language: English Format Format: PDF (Digital Download) 📖 Manual Coverage Systems Covered Engine: Complete engine overhaul, tuning, fuel injection system (EFI), ignition system, lubrication system, cooling system, starting system, exhaust system Drivetrain: Transmission (gearbox), clutch, drive shafts, differential, final drive, CVT (if applicable) Chassis And Suspension: Frame, front suspension, rear suspension, steering system, wheels, tires, braking system Electrical System: Battery, charging system, lighting, instrumentation, ECU, sensors, wiring diagrams, troubleshooting electrical faults Bodywork And Trim: Body panels, seats, fenders, bumpers, guards, storage compartments Procedures Included Maintenance: Scheduled maintenance, oil changes, filter replacements, lubrication, inspections, adjustments Repair: Component disassembly, assembly, replacement, rebuilding procedures for all major systems Troubleshooting: Diagnostic procedures for common and uncommon problems, fault finding charts, error code interpretation Technical Data: Torque specifications, tolerances, measurements, service limits, diagnostic data Technical Depth Depth: Comprehensive: Covers basic maintenance to complete engine and transmission overhauls, advanced diagnostics and electrical troubleshooting. 📊 Manual Specifications File Format Compatibility: Windows and macOS compatible Accessibility: Instant download, usable on multiple devices Print Quality Print Option: Printable (single pages or entire manual) Binding Type Binding: N/A (Digital PDF) Paper Type Paper Quality: N/A (Digital PDF) Licensing Usage Rights: Lifetime usage, no expiry dates or renewal fees ⚙️ Engine Specifications Primary Engine Engine Type: Liquid-cooled, 4-stroke, DOHC, 4-valve, parallel-twin Displacement: 686cc Bore X Stroke: 102.0 mm x 84.0 mm Compression Ratio: 8.1:1 Performance Horsepower: Approx. 45-50 hp (estimated, factory figures often unstated for off-road vehicles) Torque: Approx. 40-45 lb-ft (estimated) Fuel System Fuel Delivery: Electronic Fuel Injection (EFI) with Mikuni throttle body Fuel Type: Unleaded gasoline, 87 octane minimum Ignition Ignition System: Digital TCI (Transistor Controlled Ignition) 🔧 Transmission Standard Transmission Type: Wet centrifugal automatic clutch with constant velocity (CVT) transmission Drive Modes: 2WD/4WD shaft drive with selectable 4WD Features Gear Selection: High, Low, Neutral, Reverse, Park Differential Lock: Front differential lock (on-demand) Fluid Type Cvt Fluid: Yamaha recommends specific CVT fluid or equivalent meeting specified requirements (consult manual for exact P/N and type). 📐 Dimensions Exterior Overall Length: Approx. 2,570 mm (101.2 in) Overall Width: Approx. 1,490 mm (58.7 in) Overall Height: Approx. 1,760 mm (69.3 in) Weights Dry Weight: Approx. 257 kg (567 lbs) Curb Weight: Approx. 275 kg (606 lbs) Payload Capacity: Approx. 363 kg (800 lbs) Towing Capacity: Not specified for this model typically, designed for hauling not towing. Cargo Cargo Bed Capacity: Approx. 120 kg (264 lbs) 🛡️ Safety Features Ratings Rollover Protection: ROPS (Roll-Over Protective Structure) compliant for operator protection. Active Features Braking System: Hydraulic disc brakes, front and rear Parking Brake: Mechanical, disc brake type Passive Features Seatbelts: Standard 3-point seatbelts for driver and passenger 💡 Technology Features Infotainment Audio System: Typically basic, often no integrated audio system; aftermarket options available. Driver Assistance Assistance Features: Limited; focus is on mechanical capability. Features include selectable 4WD and differential lock. Instrumentation Dashboard Features: Digital LCD display with speedometer, odometer, trip meter, fuel gauge, clock, 4WD indicator, oil pressure warning, engine check light, neutral/reverse lights. 🔧 Maintenance...
