🏷️ Basic Information Identification Make: Mercedes-Benz Model: 560SL Chassis Code: R107 Codes Model Code: 107.048 👋 Introduction Market Position Vehicle Class: Luxury Grand Tourer / Sports Car Competitive Analysis Competitors: Porsche 911, Jaguar XJ-S, Chevrolet Corvette C4, BMW 6 Series (E24) Key Features Vehicle Appeal: Elegant styling, powerful V8 engine, comfortable ride, high-quality interior, convertible experience. Manual Value Proposition Target Audience: DIY enthusiasts, independent repair shops, Mercedes-Benz owners seeking authentic factory repair information. 📋 Manual Details Coverage Areas Applicable Years: 1986, 1987, 1988, 1989 Manual Type Type: Factory Service Manual / Workshop Manual Language Language: English Format Format: HTML/Flash menu with PDF Compatibility Operating Systems: Windows 95, 98, ME, XP, Vista, 7 📖 Manual Coverage Systems Covered Powertrain: Engine, Fuel System, Exhaust System, Transmission, Drivetrain Chassis: Suspension (Front & Rear), Steering, Brakes (Hydraulic, Parking), Wheels & Tires Body And Interior: Body Panels, Doors, Windows, Seats, Trim (Exterior & Interior), Convertible Top System Electrical: Ignition System, Lighting, Instrumentation, HVAC Controls, Power Accessories, Wiring Diagrams Procedures Included Maintenance: Scheduled maintenance, Oil changes, Fluid checks and replacements, Filter replacements, Tune-ups Repair: Engine overhaul, Transmission rebuild, Brake system repairs, Suspension component replacement, Electrical component diagnosis and repair, Bodywork and cosmetic repairs Diagnostics: Troubleshooting guides, Diagnostic procedures, Fault code interpretation (where applicable) Technical Depth Depth: Comprehensive; covers basic maintenance to complete component rebuilds and diagnostics. 📊 Manual Specifications File Format Digital Format: HTML/Flash menu for navigation, PDF for document content. Print Quality Quality: High-resolution, suitable for printing. Assumes original factory documentation quality. Binding Type Binding: N/A (Digital Format) Paper Type Paper: N/A (Digital Format) ⚙️ Engine Specifications Primary Engine Engine Code: M117 (E56) Engine Type: 4.2L SOHC V8 (32-valve in some earlier 5.6L variants, but 560SL is 2-valve per cylinder) Bore X Stroke: 94.5 mm x 98.9 mm Displacement: 5547 cc (5.6 Liters) Performance Horsepower: Approx. 227-238 hp (SAE net) depending on market and year Torque: Approx. 284-295 lb-ft (SAE net) depending on market and year Fuel System Fuel Delivery: Bosch K-Jetronic (CIS-E) Fuel Injection Fuel Type Fuel Recommendation: Unleaded premium gasoline (91 octane or higher) Lubrication Oil Capacity: Approx. 8 US quarts (7.5 Liters) with filter change Cooling System Coolant Capacity: Approx. 12.5 US quarts (11.8 Liters) 🔧 Transmission Standard Transmission Type: 4-speed Automatic (4G-TRONIC) Optional Optional Transmission: None for R107 560SL model. Features Gear Ratios: Specific gear ratios detailed in manual, typical for a torque-converter automatic of the era. Fluid Requirements Transmission Fluid Type: Mercedes-Benz Specification 236.1 (e.g., Dexron III equivalent) 📐 Dimensions Exterior Length: Approx. 187.0 inches (4750 mm) Width: Approx. 70.5 inches (1790 mm) Height: Approx. 51.0 inches (1295 mm) Wheelbase: Approx. 96.7 inches (2455 mm) Weights Curb Weight: Approx. 3640 lbs (1650 kg) Gross Vehicle Weight Rating: Approx. 4542 lbs (2060 kg) Interior Seating Capacity: 2+2 (two front seats, two small rear seats) 🛡️ Safety Features Ratings Crash Testing: Era-specific safety standards; detailed crashworthiness data usually found in separate technical bulletins, but manual covers safety system components. Active Features Braking System: 4-wheel Anti-lock Braking System (ABS) Steering System: Power-assisted recirculating ball steering Passive Features Airbags: Driver's side airbag (standard from mid-80s onwards, included in this range) Seatbelts: 3-point front seatbelts with pretensioners, lap belts for rear seats Body Structure: Reinforced A-pillars and side impact protection (typical for Mercedes-Benz of the era). 💡 Technology Features Infotainment Audio System: Factory premium sound system (e.g., Becker or Blaupunkt), often with cassette player and optional CD changer. Climate Control: Automatic Climate Control (ACC) with manual override and defrost functions. Driver Assistance Cruise Control: Standard cruise control system. Connectivity Connectivity Features: N/A (No modern connectivity features like Bluetooth or USB). Convenience Features Power Accessories: Power windows, power locks, power mirrors, power antenna, power adjustable seats, cruise control. 🔧 Maintenance Service Intervals Oil Change Interval: Typically 7,500-10,000 miles or 12-18 months (refer to manual for exact recommendation based on driving conditions). Major Service Interval: Details for major services (e.g., spark plugs, fuel filter, transmission fluid) will be outlined in the manual, often around 30,000-60,000 miles. Fluid Specifications Engine Oil Spec: SAE 15W-40 or 20W-50 API SG rated oil (check manual for specific viscosity based on ambient temperature). Coolant Type: Ethylene glycol-based coolant with corrosion inhibitors, mixed 50/50 with distilled water. Brake Fluid Type: DOT 3 or DOT 4 brake fluid. Known Issues Common Wear Items: Fuel distributor seals (K-Jetronic), climate control system (vacuum leaks), power window regulators, transmission cooling lines (corrosion), differential mounts. Rust Prone Areas: Wheel arches, rocker panels, undercarriage, convertible top frame seals. 📚 Vehicle History Brand Heritage Brand Legacy: Mercedes-Benz, founded in 1926, renowned for engineering excellence, luxury, and safety innovations. Model Evolution R107 Platform: The R107 chassis replaced the W113 'Pagoda' SL and was produced from 1971 to 1989. The 560SL was the ultimate expression of this platform. 560Sl Introduction: Introduced in 1986 as a model year update to the 500SL, featuring...
