2005 Scion XB Car Service & Repair Manual Software

Normal fiyat: $142.00
İndirimli fiyat: $142.00
Normal fiyat
Birim fiyat: /

🏷️ Basic Information Identification Make: Scion Model: xB Year: 2005 Platform: First Generation (XP10) Codes Chassis Code: XP10 👋 Introduction Market Position Market Segment: Compact hatchback, economy car, urban utility...

Type: Car

Satıcı:

Sku: 47279

Tags:

Ürün varyasyonları

Description

🏷️ Basic Information

Identification

Make:

Scion

Model:

Year:

Platform:

First Generation (XP10)

Codes

Chassis Code:

👋 Introduction

Market Position

Market Segment:

Compact hatchback, economy car, urban utility vehicle.

Target Audience:

Young drivers, urban dwellers, budget-conscious consumers, DIY enthusiasts.

Competitive Analysis

Key Competitors 2005:

Honda Fit (Japan), Nissan Cube, Kia Rio, Hyundai Accent, Ford Focus.

Key Features

Unique Selling Proposition:

Distinctive boxy styling, surprisingly spacious interior for its size, fuel efficiency, affordability, Toyota reliability reputation.

Manual Value Proposition:

Provides professional-level repair and maintenance guidance for a wide range of tasks, enabling cost savings on labor.

📋 Manual Details

Coverage Areas

Manual Type:

Service and Repair Manual Software

Language:

English

Format:

PDF Download (via web browser access)

Access Duration:

1 Year (with option for renewal)

Manual Origin:

Licensed OE (Original Equipment) Materials by RepairSurge

📖 Manual Coverage

Systems Covered

Engine Mechanical:

Complete overhaul, diagnostics, timing belt replacement, cooling system, lubrication system, fuel system, emissions control.

Engine Electrical:

Ignition system, starter system, charging system, engine control module (ECM) diagnostics, sensors, actuators.

Transmission Manual:

Clutch system, gearbox overhaul, shift linkage, differential service, fluid specifications.

Transmission Automatic:

Transmission fluid change and level check, internal component diagnostics, valve body testing, torque converter service (where applicable for this generation).

Drivetrain:

Front-wheel drive axle shafts, CV joints, differential service.

Suspension:

Front struts, rear shock absorbers, coil springs, control arms, ball joints, bushings, sway bars, alignment specifications.

Steering:

Power steering system (pump, rack and pinion), steering column, tie rods, steering wheel removal and installation.

Brakes:

Front disc brakes (pads, rotors), rear drum brakes (shoes, drums), brake fluid replacement, bleeding procedures, parking brake system.

Electrical System:

Battery, charging system, starter, lighting systems (headlights, taillights, interior), fuses, relays, body control module (BCM) functions, power windows, locks, mirrors.

HVAC:

Air conditioning system (compressor, refrigerant, evaporator, condenser), heater core, blower motor, climate control unit, cabin air filter replacement.

Body And Trim:

Exterior panels, interior trim components, door panel removal, bumper removal, weatherstripping, glass replacement.

Wiring Diagrams:

Comprehensive electrical schematics for all major systems.

Procedures Included

Maintenance:

Oil changes, filter replacements, fluid top-offs, tire rotations, spark plug replacement, brake pad inspection.

Diagnostics:

Troubleshooting guides for common problems, diagnostic trouble codes (DTCs), sensor testing, component testing.

Repair:

Component replacement, system adjustments, system overhauls.

Installation:

Component installation (e.g., suspension parts, brake components), accessory installation guidance.

Specifications:

Torque specifications, fluid capacities, diagnostic parameters, alignment angles.

Technical Depth

Depth Level:

Comprehensive: Covers routine maintenance, troubleshooting, component repair, and system diagnostics from a professional technician's perspective.

📊 Manual Specifications

File Format

File Type:

Searchability:

Searchable text for quick information retrieval.

Printability:

Printable pages for on-site use.

Compatibility:

Compatible with PC, laptop, smartphone, tablet via web browser.

Print Quality

Image Resolution:

High-resolution diagrams and illustrations.

Binding Type

Binding:

N/A (Digital Download)

Paper Type

Paper Quality:

N/A (Digital Download)

⚙️ Engine Specifications

Primary Engine

Engine Code:

1NZ-FE

Engine Type:

Inline 4-cylinder, DOHC, 16-valve, VVT-i (Variable Valve Timing with intelligence)

Displacement:

1.5 liters (1497 cc)

Performance

Horsepower:

108 hp @ 6000 rpm

Torque:

105 lb-ft @ 4200 rpm

Fuel System

Fuel Delivery:

Electronic Fuel Injection (EFI)

Recommended Fuel:

87 Octane Unleaded Gasoline

Cooling System

Coolant Type:

Toyota Super Long Life Coolant (SLLC) - Pink

Coolant Capacity:

Approx. 5.2 quarts (4.9 liters)

Lubrication System

Engine Oil Type:

SAE 5W-30

Engine Oil Capacity:

Approx. 3.9 quarts (3.7 liters) with filter change

🔧 Transmission

Standard

Transmission Type Std:

4-speed automatic overdrive (ECT)

Optional

Transmission Type Opt:

5-speed manual transmission

Features

Automatic Transmission Fluid:

Toyota ATF WS (World Standard) or equivalent

Automatic Transmission Fluid Capacity:

Approx. 3.0 quarts (2.8 liters) for drain and refill

Manual Transmission Fluid Type:

API GL-4, SAE 75W-90

Manual Transmission Fluid Capacity:

Approx. 2.3 quarts (2.2 liters)

📐 Dimensions

Exterior

Length:

161.4 inches (4100 mm)

Width:

66.7 inches (1695 mm)

Height:

61.6 inches (1565 mm)

Wheelbase:

97.2 inches (2470 mm)

Ground Clearance:

Approx. 5.1 inches (130 mm)

Interior

Passenger Volume:

Approx. 91.1 cubic feet (2579 liters)

Cargo

Cargo Volume Rear Seats Up:

Approx. 17.1 cubic feet (484 liters)

Cargo Volume Rear Seats Down:

Approx. 37.7 cubic feet (1068 liters)

Weights

Curb Weight Manual:

Approx. 2425 lbs (1100 kg)

Curb Weight Automatic:

Approx. 2490 lbs (1130 kg)

Gross Vehicle Weight Rating Gvwr:

Approx. 3530 lbs (1600 kg)

🛡️ Safety Features

Ratings

NHTSA Front Driver Side:

5-Star

NHTSA Front Passenger Side:

5-Star

NHTSA Side Driver Seat:

4-Star

NHTSA Side Rear Seat:

4-Star

IIHS Front Small Overlap Crashtest:

Good (for its class at the time, though testing protocols evolved)

IIHS Side Impact Crashtest:

Good (for its class at the time)

Active Features

Standard Anti-lock Braking System

E Brake:

Rear drum parking brake

Passive Features

Airbags Front:

Driver and front passenger airbags

Airbags Side:

Optional front side-impact airbags

Seatbelts:

Three-point seatbelts with pretensioners and force limiters

Child Anchors:

LATCH (Lower Anchors and Tethers for Children) system

💡 Technology Features

Infotainment

Head Unit:

Standard AM/FM/CD player, optional MP3 compatibility or premium JBL sound system.

Speakers:

Typically 4 or 6 speakers.

Driver Assistance

Traction Control:

Optional Traction Control (TRAC) system.

Stability Control:

Electronic Stability Control (VSC - Vehicle Stability Control) was not standard or widely available on this specific model year.

Connectivity

Aux Input:

Not standard, some aftermarket head units might have it.

🔧 Maintenance

Service Intervals

Oil And Filter Change:

Every 5,000 miles (8,000 km) or 6 months, whichever comes first.

Engine Air Filter Replacement:

Every 30,000 miles (48,000 km).

Cabin Air Filter Replacement:

Every 15,000 miles (24,000 km) or 12 months.

Spark Plug Replacement:

Every 100,000 miles (160,000 km) (Iridium-tipped plugs).

Coolant Replacement:

First replacement at 100,000 miles (160,000 km), then every 50,000 miles (80,000 km) thereafter.

Transmission Fluid Change Auto:

Check at 60,000 miles (96,000 km), replace as needed (under normal driving conditions, Toyota often lists it as 'lifetime' but periodic checks/changes are recommended).

Brake Fluid Replacement:

Every 30,000 miles (48,000 km) or 24 months.

Fluid Specifications

Power Steering Fluid:

Toyota Genuine Power Steering Fluid or equivalent DEXRON II/III

Known Issues

Common Complaints Early Models:

Occasional oil consumption (especially on higher mileage units), minor interior rattles, potential for worn suspension bushings over time.

Timing Belt Or Chain:

Timing chain driven (no periodic replacement required, but monitor for noise).

📚 Vehicle History

Brand Heritage

Parent Company:

Toyota Motor Corporation

Brand Philosophy:

Focus on reliability, quality, and value.

Model Evolution

First Generation Launch Year:

2003 (Japan), 2004 (North America)

Model Cycle Position:

Early in the first generation's lifecycle (MY 2005).

Production

Assembly Location:

Toyota Auto Body Co., Ltd. (Japan)

Production Period Xp10:

2003-2007

🏆 Awards & Recognition

Recognitions

Consumer Reports Reliability:

Consistently ranked as a reliable vehicle by automotive consumer organizations.

Edmunds Best Fuel Economy:

Praised for its fuel efficiency in its class.
