🏷️ Basic Information Identification Make: Lexus Model: IS F Year: 2009 Codes Chassis Code: XE20 👋 Introduction Market Position Market Position: High-performance luxury sedan targeted at enthusiasts seeking a blend of comfort and potent V8 power. Competitive Analysis Competitive Analysis: Competed against models like the BMW M3 (E90/E92), Audi S4 (B7/B8), and Mercedes-Benz C63 AMG (W204), differentiating with its naturally aspirated V8 and Lexus reliability. Key Features Key Features: High-revving 5.0L V8 engine, advanced 8-speed automatic transmission with paddle shifters, performance-tuned suspension, Brembo brakes, distinct exterior styling cues, exclusive interior appointments. 📋 Manual Details Coverage Areas Coverage Areas: Comprehensive service and repair for 2009 Lexus IS F Page Count Page Count: Not specified (digital software, content-rich) Manual Type Manual Type: Service and Repair Manual Software Language Language: English Format Format: Online Software/Web-based Access 📖 Manual Coverage Systems Covered Systems Covered: Engine (2UR-GSE), Transmission (8-speed SPDS), Drivetrain, Brakes, Suspension, Steering, Electrical System, HVAC, Bodywork, Diagnostics, Maintenance Electrical System Coverage: Detailed wiring diagrams, component location charts, diagnostic trouble codes (DTCs), troubleshooting procedures for all electrical systems including lighting, power accessories, infotainment, and control modules. Drivetrain Coverage: Rear-wheel drive system, differential, axle shafts, driveshaft, maintenance and repair of the transmission and torque converter. Brake System Coverage: Disc brake systems (front and rear), ABS components, EBD, Brake Assist, parking brake system, brake caliper and rotor replacement, brake fluid bleeding procedures. Suspension And Steering Coverage: Front and rear suspension components (double wishbone front, multi-link rear), shock absorbers, springs, control arms, bushings, steering gear, power steering system, wheel alignment specifications. HVAC Coverage: Air conditioning system, heater core, blower motor, climate control unit, refrigerant charging, diagnosis of cooling and heating issues. Procedures Included Procedures Included: Scheduled maintenance, troubleshooting, component repair, system diagnostics, wiring diagrams, torque specifications, fluid capacities, removal and installation procedures Engine Overhaul Procedures: Detailed instructions for engine disassembly, inspection, repair, and reassembly, including piston and ring replacement, bearing inspection, cylinder head service, and timing component replacement. Diagnostic Procedures: Step-by-step diagnostic guides for common and uncommon problems, utilizing OBD-II scan tools, live data interpretation, and specialized Lexus diagnostic equipment information. Suspension Alignment Specs: Complete front and rear suspension alignment angles, camber, caster, toe specifications for optimal handling and tire wear. Torque Specifications: Comprehensive list of all critical torque specifications for engine, transmission, chassis, brake, and suspension components. Technical Depth Technical Depth: Factory-level, detailed diagnostics, repair procedures, and technical specifications suitable for both professional technicians and advanced DIY enthusiasts Body And Interior Coverage Body And Interior Coverage: Body panel removal and installation, door mechanisms, interior trim, seats, airbags (safety precautions), glass replacement, chassis and frame specifications. 📊 Manual Specifications File Format File Format: Web-based access, compatible with PC, laptop, smartphone, tablet via web browser Print Quality Print Quality: N/A (Digital content, high resolution graphics and diagrams) Binding Type Binding Type: N/A (Digital) Paper Type Paper Type: N/A (Digital) ⚙️ Engine Specifications Primary Engine Primary Engine: 2UR-GSE Performance Horsepower: 416 hp @ 6,600 rpm Torque: 371 lb-ft @ 5,200 rpm Fuel System Fuel System: Direct and Port Fuel Injection (D-4S) Engine Layout Engine Layout: 5.0L V8, Naturally Aspirated Bore X Stroke Bore X Stroke: 94.0 mm x 90.0 mm Compression Ratio Compression Ratio: 12.3:1 Valvetrain Valvetrain: Dual Overhead Camshafts (DOHC), 32 Valves, Variable Valve Timing with intelligence (VVT-i) 🔧 Transmission Standard Standard Transmission: 8-Speed SPDS (Sport Direct Shift) Automatic Transmission Features Transmission Features: Paddle Shifters, Sport Mode, Manual Shift Mode (M mode) Gear Ratios Gear Ratios: 1st: 3.194, 2nd: 2.034, 3rd: 1.304, 4th: 1.000, 5th: 0.776, 6th: 0.640, 7th: 0.521, 8th: 0.428, Reverse: 3.220 Fluid Type Transmission Fluid Type: Toyota Genuine ATF WS (World Standard) Fluid Capacity Transmission Fluid Capacity: Approx. 9.9 Liters (check manual for precise capacity under various conditions) 📐 Dimensions Exterior Length: 185.2 in (4,705 mm) Width: 70.9 in (1,800 mm) Height: 56.7 in (1,440 mm) Wheelbase: 107.5 in (2,730 mm) Front Track: 60.2 in (1,530 mm) Rear Track: 59.4 in (1,510 mm) Weights Curb Weight: 3,836 lbs (1,740 kg) Gross Vehicle Weight Rating: 4,827 lbs (2,190 kg) Payload Capacity: 991 lbs (450 kg) Cargo Trunk Volume: 10.4 cu ft (294 L) Wheels And Tires Front Tire Size: P225/40R19 Rear Tire Size: P245/35R19 Wheel Bolt Pattern: 5x114.3 mm Wheel Size: 19 x 8.0 (front), 19 x 9.0 (rear) 🛡️ Safety Features Ratings NHTSA Frontal Crash Rating: 4/5 Stars (Driver), 4/5 Stars (Passenger) NHTSA Side Crash Rating: 5/5 Stars (Front), 5/5 Stars (Rear) IIHS Small Overlap Front Rating: Good Active Features Active Features: Vehicle Stability Control (VSC), Traction Control (TRAC), Anti-lock Braking System (ABS), Electronic Brake-force Distribution (EBD), Brake Assist (BA), Tire Pressure Monitoring System (TPMS), Bi-Xenon High-Intensity Discharge (HID) Headlights with Adaptive Front-lighting System (AFS) Passive Features Passive Features: Dual-stage front airbags, front-side airbags, front and rear side-curtain airbags, front knee airbags, active front headrests. 💡 Technology Features Infotainment Infotainment System: Optional navigation system with...
