Detailed electrical system schematics for all circuits
Technical Depth
Depth:
Factory-level diagnostic and repair procedures
📊 Manual Specifications
File Format
Digital Format:
PDF
Print Quality
Printability:
High-resolution for clear printing of diagrams and text
Binding Type
Binding:
N/A (Digital Download)
Paper Type
Paper Quality:
N/A (Digital Download)
Searchability
Text Search:
Searchable text content for quick information retrieval
⚙️ Engine Specifications
Primary Engine
Engine Type:
Inline 4-Cylinder, DOHC, 16-Valve
Displacement:
1.8 Liters (1798 cc)
Bore X Stroke:
80.5 mm x 88.3 mm
Compression Ratio:
9.8:1
Performance
Horsepower:
128 hp @ 6000 rpm
Torque:
125 lb-ft @ 4000 rpm
Fuel System
Injection Type:
Electronic Fuel Injection (EFI) with Sequential Port Injection
Fuel Type:
Unleaded gasoline, 87 octane (minimum)
Lubrication
Oil Capacity:
4.5 US quarts (4.3 Liters) with filter change
Cooling
Coolant Capacity:
6.5 US quarts (6.2 Liters)
🔧 Transmission
Standard
Type:
5-Speed Manual Transmission
Optional
Type:
4-Speed Automatic Transmission
Features
Automatic Features:
Electronically controlled, overdrive
Manual Fluid
Fluid Type:
API GL-4, SAE 75W-90
Automatic Fluid
Fluid Type:
Toyota Genuine ATF WS (World Standard)
📐 Dimensions
Exterior
Length:
161.8 inches (4110 mm)
Width:
66.7 inches (1695 mm)
Height:
60.2 inches (1530 mm)
Wheelbase:
97.2 inches (2470 mm)
Weights
Curb Weight Manual:
Approx. 2600 lbs (1180 kg)
Curb Weight Automatic:
Approx. 2650 lbs (1200 kg)
🛡️ Safety Features
Ratings
NHTSA Frontal Driver:
5-Star
NHTSA Frontal Passenger:
5-Star
IIHS Moderate Overlap Frontal:
Good
IIHS Side Impact:
Good
Active Features
ABS:
Standard Anti-lock Braking System
Ebs:
Standard Electronic Brake-force Distribution (EBD)
Bcs:
Standard Brake Assist
Passive Features
Airbags Front:
Standard Advanced Frontal Airbags
Airbags Side:
Standard Front Seat-Mounted Side Airbags
Airbags Curtain:
Standard Front and Rear Side Curtain Airbags
Tms:
Standard Tire Pressure Monitoring System (TPMS)
💡 Technology Features
Infotainment
Audio System:
Standard 160-watt Pioneer audio system with six speakers, AM/FM/CD player, MP3 capability, and auxiliary audio input jack.
Connectivity Options:
Auxiliary audio input jack standard.
Optional Audio:
Available upgraded audio systems with satellite radio compatibility and USB port on certain trims/packages.
🔧 Maintenance
Service Intervals Oil
Interval Description:
Inspect oil level every 5,000 miles (8,000 km) or 6 months. Change oil and filter every 10,000 miles (16,000 km) or 12 months, whichever comes first, using synthetic oil.
Service Intervals Filters
Air Filter Replacement:
Inspect every 15,000 miles (24,000 km), replace every 30,000 miles (48,000 km) or as needed.
Cabin Air Filter Replacement:
Replace every 15,000 miles (24,000 km) or annually.
Service Intervals Fluids
Coolant Replacement:
Replace Super Long Life Coolant at 100,000 miles (160,000 km) initially, then every 50,000 miles (80,000 km) thereafter.
Fluid Specifications
Engine Oil Specification:
SAE 0W-20 Synthetic (preferred), or SAE 5W-20 (if 0W-20 is unavailable)
Brake Fluid Specification:
DOT 3
Known Issues
Engine Mounts:
Premature wear or cracking of engine mounts can lead to vibration and noise.
Oil Consumption:
Some reports of increased oil consumption, especially at higher mileage; regular checks are recommended.
Evap System Leaks:
Issues with the evaporative emission control system (EVAP) can lead to Check Engine Light illumination.
📚 Vehicle History
Brand Heritage
Parent Company:
Toyota Motor Corporation
Model Evolution
First Generation Introduction:
Introduced for the 2004 model year in Japan as the Toyota bB (second generation); Rebadged and introduced as the Scion xD in North America for the 2008 model year.
Platform:
Based on the Toyota Yaris platform (XP90 chassis)
Production
Manufacturing Location:
Japan
🏆 Awards & Recognition
Recognitions
IIHS Top Safety Pick:
The 2008 Scion xD received IIHS Top Safety Pick recognition due to its strong performance in crash tests.
