🏷️ Basic Information Identification Make: Fiat Model: Idea Engine: 1.4 16V Generation Model Years Covered: 2003-2012 👋 Introduction Market Position Vehicle Segment: Compact MPV (Multi-Purpose Vehicle) Target Audience: Families, urban commuters seeking practicality and flexibility Competitive Analysis Key Competitors: Opel/Vauxhall Meriva, Renault Modus, Citroën C3 Picasso, Ford Fusion Key Features Vehicle Appeal: Chic Italian design, flexible interior packaging, compact footprint, good maneuverability Manual Value Proposition Benefits: Empowers DIY repairs, cost savings on maintenance and repair, detailed step-by-step instructions, clear diagrams 📋 Manual Details Coverage Areas Primary Regions: Europe Specific Regions: Likely covers all European market variants Page Count Estimated Pages: Extensive (specific count not provided, but typical for factory service manuals covering multiple systems) Manual Type Type: Service Repair Factory Manual Language Language: Likely English, with potential for other European languages depending on original publication Format File Format: .ISO (Disc Image File) Delivery Method: Digital Download 📖 Manual Coverage Systems Covered Powertrain: Engine (1.4 16V), Fuel System, Power Unit, Lower Unit, Bracket Unit Chassis: Suspension, Steering, Brakes Electrical: Electrical System, Wiring Diagrams Bodywork: Body Repair (implied by Rigging Information and general repair procedures) Procedures Included Maintenance: Scheduled Maintenance, Fluid Changes, Filter Replacements Repair: Engine Repair, Transmission Repair, Brake System Repair, Electrical Component Repair Diagnostics: Troubleshooting, Fault Diagnosis Assembly: Disassembly and Reassembly Procedures Suspension Alignment: Specifications for wheel alignment (camber, caster, toe) Brake System Overhaul: Detailed procedures for brake pad replacement, caliper service, brake fluid flushing Cooling System Service: Procedures for coolant replacement, radiator service, thermostat replacement Air Conditioning Service: Basic service procedures for the A/C system (refrigerant handling may require specialized knowledge not fully covered) Technical Depth Depth: Comprehensive (Factory Level) Engine Diagnostics: Detailed diagnostic procedures, fault code interpretation, sensor data analysis Transmission Repair: Procedures for manual and automated manual transmissions, including clutch adjustment and hydraulic system service Electrical Schematics: Comprehensive wiring diagrams for all electrical systems, component locations 📊 Manual Specifications File Format Image Format: .ISO Executable Format: .EXE Print Quality Printability: Printable without restriction Readability: High (zoomable on computer) Binding Type Binding: Digital (No physical binding) Paper Type Paper Type: Digital (Not applicable) Software Requirements Iso Mounting Software: DAEMON Tools, MagicISO, or similar Operating System Compatibility: Windows 32-bit ⚙️ Engine Specifications Primary Engine Engine Code: Likely FIRE (Fully Integrated Robotized Engine) family, e.g., 188A6.000 or similar Engine Type: Inline 4-cylinder, Naturally Aspirated Displacement: 1368 cc (83.5 cu in) Bore X Stroke: Approximately 72.0 mm x 84.0 mm Valve Configuration: DOHC (Double Overhead Camshaft), 16 valves Performance Horsepower: Approximately 95 PS (94 bhp; 70 kW) at 6000 rpm Torque: Approximately 128 Nm (94 lb-ft) at 4300 rpm Fuel System Fuel Delivery: Electronic Multi-Point Fuel Injection (MPI) Fuel Type: Unleaded gasoline (Petrol) Engine Management ECU Type: Bosch Motronic or Magneti Marelli (specific details in manual) 🔧 Transmission Standard Transmission Type: 5-speed Manual Transmission Optional Transmission Type: Dualogic (Automated Manual Transmission) - available on some models Features Clutch: Hydraulically actuated single dry plate clutch Fluid Specifications Manual Transmission Fluid: GL-4 SAE 75W/80 (e.g., Tutela Car Technyx JWS 3309 or equivalent) Automatied Manual Transmission Fluid: Specific Pentosin ATF or Tutela CS Speed (refer to manual for exact specification) 📐 Dimensions Exterior Length: Approximately 3959 mm (155.9 in) Width: Approximately 1700 mm (66.9 in) Height: Approximately 1601 mm (63.0 in) Wheelbase: Approximately 2510 mm (98.8 in) Weights Curb Weight: Approximately 1160-1250 kg (2557-2756 lbs) depending on configuration Gross Vehicle Weight Rating: Refer to vehicle VIN plate (typically around 1700 kg) Cargo Luggage Capacity Seats Up: Approximately 320-380 liters (11.3-13.4 cu ft) Luggage Capacity Seats Down: Approximately 1250-1300 liters (44.1-45.9 cu ft) with rear seats folded 🛡️ Safety Features Ratings Euro Ncap Rating: 4 Stars (tested in 2005) Active Features ABS: Standard on most models (Anti-lock Braking System) Esp: Optional on some models (Electronic Stability Program) Passive Features Airbags: Front airbags (driver and passenger), optional side and window airbags Seatbelts: 3-point seatbelts with pre-tensioners and load limiters Child Seat Anchors: ISOFIX mounting points 💡 Technology Features Infotainment Head Unit: Factory fitted CD player with radio, optional MP3 playback and steering wheel controls Driver Assistance Parking Sensors: Optional rear parking sensors Connectivity Auxiliary Input: Optional auxiliary input jack for external audio devices 🔧 Maintenance Service Intervals Oil Change Interval: Typically 15,000 km (9,300 miles) or 1 year, whichever comes first Air Filter Replacement: Approximately every 30,000 km (18,600 miles) or 2 years Spark Plug Replacement: Approximately every 60,000 km (37,200 miles) for standard plugs, or longer for iridium/platinum Timing Belt Replacement: Crucial for 1.4 16V FIRE engine. Typically 90,000 - 120,000 km (56,000 - 75,000 miles) or 5 years, whichever comes first. Failure causes catastrophic engine damage. Fluid Specifications Engine Oil Grade: 0W-30, 5W-30, or 5W-40 (API SN/SM/SL, ACEA C3/C2/A3/B4 - refer to manual for exact spec and Fiat approval) Engine Oil Capacity: Approximately 3.2 - 3.4 liters (3.4 - 3.6 US quarts) with filter...
