🏷️ Basic Information Identification Make: Ford Model: F-150 Model Years Covered: 2009, 2010 Codes Platform: P2 (12th Generation) 👋 Introduction Market Position Vehicle Segment: Full-size Pickup Truck Segment Leadership: Consistently a best-selling vehicle in its class Competitive Analysis Key Competitors 2009 2010: Ram 1500, Chevrolet Silverado 1500, GMC Sierra 1500, Toyota Tundra Key Features Manual Usability Features: Detailed sub-steps, notes/cautions/warnings, numbered instructions, bold figure numbers, detailed illustrations/drawings/photos, enlarged insets, numbered table of contents, combined troubleshooting and wiring diagrams Manual Benefit: Empowers users with professional-level repair and maintenance information for significant cost savings 📋 Manual Details Coverage Areas Manual Type: Full Service Repair Manual Primary Coverage: Repair, Maintenance, Rebuilding, Refurbishing, Restoration Page Count Estimated Page Count: Extensive (often exceeding 2000 pages for such comprehensive manuals) Manual Type Language: English Format File Format: PDF Delivery Method: Instant Download Compatibility: All Windows Versions, macOS 📖 Manual Coverage Systems Covered Powertrain: Engine mechanical, fuel system, ignition system, exhaust system, cooling system, lubrication system Drivetrain: Transmission (automatic and manual), transfer case (if applicable), driveshafts, axles, differentials Chassis: Suspension (front and rear), steering system, braking system (hydraulic, ABS, parking brake) Electrical: Wiring diagrams, charging system, starting system, lighting, instrumentation, body electrical controls, audio system, HVAC controls Body: Exterior body panels, interior trim, doors, glass, seats, bumpers, frame and chassis components Procedures Included Diagnostic Procedures: Troubleshooting guides, symptom-based diagnostics, fault code interpretation Maintenance Procedures: Scheduled maintenance, fluid changes, filter replacements, inspections Repair Procedures: Step-by-step instructions for component removal, installation, and overhaul Rebuild Procedures: Detailed guidance for major component overhauls (engine, transmission) Electrical Service: Component testing, wiring harness repair, module diagnostics Technical Depth Depth Level: Comprehensive (from basic maintenance to advanced diagnostics and component rebuilds) Target Audience: Professional Technicians, Do-It-Yourself Mechanics 📊 Manual Specifications File Format Quality: High-resolution, Full Printable Searchability: Likely searchable text within PDF Print Quality Printability: All pages printable Binding Type Binding: N/A (Digital PDF format) Paper Type Paper: N/A (Digital PDF format) Requirements Software Requirements: Adobe PDF Reader, WinRAR (for potential compressed files) ⚙️ Engine Specifications Primary Engine Engine Options: 4.6L Triton V8, 5.4L Triton V8, 6.2L V8 (introduced later in this generation) Performance 4.6L V8 (2V): Approx. 248 hp @ 4500 rpm, 290 lb-ft @ 4000 rpm 4.6L V8 (3V): Approx. 310 hp @ 5000 rpm, 365 lb-ft @ 3500 rpm 5.4L V8: Approx. 310 hp @ 5000 rpm, 365 lb-ft @ 3500 rpm 6.2L V8: Approx. 400 hp @ 5500 rpm, 410 lb-ft @ 4250 rpm Fuel System Fuel Delivery: Electronic Fuel Injection (EFI) Fuel Type: Unleaded Gasoline (Flex Fuel capability on some engines) Engine Codes 4.6L V8 (2V): 2V SOHC (e.g., VIN U) 4.6L V8 (3V): 3V SOHC (e.g., VIN 8) 5.4L V8: 3V SOHC (e.g., VIN V) 6.2L V8: 2V SOHC (e.g., VIN P) 🔧 Transmission Standard Transmission Options: 4-speed Automatic (4R75E/W), 6-speed Automatic (6R80), 6-speed Manual (ZF Friedrichshafen Tremec TR-6060, rare) Optional Transfer Case: Electronic Shift-On-Demand (4x4 models) Features Transmission Fluid Spec 4R75E/W: Mercon V (e.g., Motorcraft XT-5QSM) Transmission Fluid Spec 6R80: Mercon LV (e.g., Motorcraft XT-10-QLVC) 📐 Dimensions Exterior Wheelbase Options: 133.0" (Regular Cab, SuperCab), 145.0" (SuperCab, SuperCrew), 157.0" (SuperCrew) Bed Length Options: 5.5 ft (Short Box), 6.5 ft (Styleside Box), 8.0 ft (Long Bed) Weights Curb Weight Range: Approx. 4,600 - 5,300 lbs (depending on configuration) Max Payload Capacity: Up to approx. 3,000 lbs (configuration dependent) Max Towing Capacity: Up to approx. 11,300 lbs (configuration dependent) 🛡️ Safety Features Ratings NHTSA Front Driver Side Impact: 5-Star (2009 Model Year) NHTSA Front Passenger Side Impact: 5-Star (2009 Model Year) NHTSA Side Driver Door Impact: 5-Star (2009 Model Year) NHTSA Side Rear Passenger Impact: 5-Star (2009 Model Year) NHTSA Rollover Resistance: 4-Star (2009 Model Year) Active Features Active Safety Systems: Anti-lock Braking System (ABS), Electronic Stability Control (AdvanceTrac with Roll Stability Control) Passive Features Airbags: Frontal airbags, front side-impact airbags, side curtain airbags (optional on some trims) 💡 Technology Features Infotainment Available Infotainment Systems: Ford SYNC (hands-free calling, music streaming), SiriusXM Satellite Radio, premium audio systems (Sony, etc.) Driver Assistance Driver Assistance Features: Rear parking assist, integrated trailer brake controller, rearview camera (optional) Connectivity Connectivity Options: USB port for media devices (with SYNC), auxiliary audio input 🔧 Maintenance Service Intervals Oil Change Interval: Typically every 5,000 to 7,500 miles or 6 months, depending on engine and driving conditions (refer to manual for specific recommendations) Tire Rotation Interval: Every 5,000 to 7,500 miles Transmission Fluid Change: Varies by transmission type and driving conditions; typically around 30,000 to 100,000 miles (refer to manual) Fluid Specifications Engine Oil Viscosity: 5W-20 (recommended for most engines) Engine Oil Capacity: Varies by engine (e.g., 4.6L approx. 6 quarts, 5.4L approx. 7 quarts) Coolant Type: Ford Gold Coolant (Premium Engine Coolant, P-HOAT, Orange) Brake Fluid Type: DOT 3 Known Issues Common Problems 2009 2010: Spark plug ejection (on 3V Triton engines, particularly the 5.4L, requires specific...
