🏷️ Basic Information Identification Make: Ford Model: Ranger Year: 2010 Generation Generation Designation: Third Generation (T6/P375) - Global Platform (North American variant shared platform with Mazda BT-50) Codes Chassis Code: UN156 👋 Introduction Market Position Segment: Compact/Mid-size Pickup Truck Target Audience: DIY mechanics, professional auto repair shops, fleet maintenance personnel Competitive Analysis Key Competitors: Toyota Tacoma, Nissan Frontier, Chevrolet Colorado, GMC Canyon, Dodge Dakota Key Features Manual Benefit 1: Provides step-by-step instructions for all repair and maintenance tasks. Manual Benefit 2: Includes detailed diagrams and exploded views for clarity. Manual Benefit 3: Offers diagnostic procedures and troubleshooting guides for efficient problem-solving. Manual Benefit 4: Enables users to save time and money on vehicle maintenance and repairs. Manual Benefit 5: Instant download access for immediate use. 📋 Manual Details Coverage Areas Market Coverage: North America (specific to the 2010 model year sold in North America) Page Count Estimated Page Count: 1500-2000+ Manual Type Type: Service and Repair Manual Language Language: English Format Format: PDF (Portable Document Format) 📖 Manual Coverage Systems Covered Powertrain: Engine mechanical, fuel system, ignition system, lubrication, cooling system, exhaust system, emissions control Drivetrain: Transmission (manual and automatic), clutch, driveshafts, differentials, axles, transfer case (4WD models) Chassis: Suspension (front and rear), steering system, brakes (hydraulic, ABS, parking brake) Electrical: Battery, charging system, starting system, lighting, instruments and gauges, wipers and washers, horn, body control modules, infotainment, HVAC controls, power accessories (windows, locks, mirrors) Body: Body panels, doors, windows, interior trim, bumpers, exterior trim, glass, safety restraints (airbags, seatbelts) Procedures Included Maintenance: Scheduled maintenance, fluid checks and changes, filter replacements, belt inspections and replacement, spark plug replacement, brake pad/rotor replacement Troubleshooting: Diagnostic procedures for common faults, symptom-based troubleshooting guides, electrical circuit diagnosis Repair: Component removal and installation, disassembly and reassembly of major systems, bodywork repair, electrical component repair Diagnostics: OBD-II diagnostic trouble codes (DTCs) interpretation, sensor testing, actuator testing Technical Depth Depth: Comprehensive: Covers everything from basic maintenance to complete engine and transmission rebuilds, including detailed electrical schematics and diagnostic procedures. 📊 Manual Specifications File Format PDF Quality: High-resolution, text-searchable PDF with clear, legible diagrams and illustrations. Print Quality Printability: Designed for easy printing of individual pages or sections, allowing users to work with clean, grease-free documents. Binding Type Binding: Digital Download (PDF) - No physical binding Paper Type Paper Type: Not Applicable (Digital Format) ⚙️ Engine Specifications Primary Engine Engine Code 1: 2.3L Duratec (L5-VE) Engine Type 1: Inline-4 Cylinder, DOHC, 16 Valves Displacement 1: 2295 cc (2.3 Liters) Bore X Stroke 1: 87.5 mm x 94.0 mm Compression Ratio 1: 9.7:1 Horsepower 1: 143 hp @ 5250 rpm Torque 1: 154 lb-ft @ 3750 rpm Fuel System 1: Electronic Fuel Injection (EFI), Sequential Multi-Port Fuel Injection (SMPI) Fuel Type 1: Unleaded Gasoline Emission Control 1: Catalytic Converter, EGR (Exhaust Gas Recirculation) Optional Engine Engine Code 2: 4.0L Cologne V6 (XM) Engine Type 2: V6, SOHC, 12 Valves Displacement 2: 3958 cc (4.0 Liters) Horsepower 2: 207 hp @ 5000 rpm Torque 2: 238 lb-ft @ 3000 rpm Fuel System 2: Electronic Fuel Injection (EFI), Sequential Multi-Port Fuel Injection (SMPI) Fuel Type 2: Unleaded Gasoline 🔧 Transmission Standard Transmission Type 1: 5-Speed Manual (M5OD-R1) Optional Transmission Type 2: 5-Speed Automatic (5R55E) Features Transfer Case 4Wd: Electronic shift-on-the-fly (ESOF) for 4x4 models 📐 Dimensions Exterior Wheelbase Standard Cab: 114.5 inches (2908 mm) Wheelbase Extended Cab: 125.7 inches (3193 mm) Overall Length Standard Bed: 190.0 inches (4826 mm) Overall Length Long Bed: 201.2 inches (5111 mm) Width Excluding Mirrors: 71.7 inches (1821 mm) Height: 66.5 inches (1689 mm) (approximate, varies with trim/suspension) Cargo Bed Length Standard: 71.8 inches (1824 mm) Bed Length Long: 84.7 inches (2151 mm) Weights Curb Weight Min: 3600 lbs (1633 kg) (approximate) Max Payload Capacity: 1560 lbs (708 kg) (approximate, varies with configuration) Max Towing Capacity: 5,400 lbs (2,449 kg) (with V6 and proper towing package) 🛡️ Safety Features Ratings NHTSA Rollover Resistance: 3-star rating for 4x2 and 4x4 models (based on 2009 model year data, indicative for 2010) Active Features ABS: Standard Anti-lock Braking System (ABS) on all models Traction Control: Optional Traction Control System (TCS) Passive Features Airbags Driver: Driver and front passenger airbags Seatbelts: Three-point height-adjustable front seat belts with pretensioners 💡 Technology Features Infotainment Audio System Options: Base AM/FM stereo with CD player and auxiliary input. Optional premium sound systems and satellite radio. Display: Basic LCD display for audio and clock functions. No touchscreens available on this generation. Driver Assistance Cruise Control: Standard cruise control on most trims. Backup Camera: Not available from factory. Connectivity Bluetooth: Optional Bluetooth hands-free connectivity on higher trims. 🔧 Maintenance Service Intervals Oil Change Interval: Every 5,000 miles or 6 months, whichever comes first (under normal driving conditions). Air Filter Replacement: Every 30,000 miles or 24 months. Spark Plug Replacement 2 3L: Every 100,000 miles (platinum-tipped plugs)...
