🏷️ Basic Information Identification Make: JCB Model: 802 Series Excavator Model Variant: 802, 802-4 Super Product Type: Operator's Manual 📋 Manual Details Documentation Manual Type: Operator's Manual Language: English Format: PDF ⚙️ Engine Specifications Engine Engine Type: Diesel (likely Isuzu or Perkins, common for this era/size) Displacement: Approx. 1.6 - 1.9 Liters (estimated for this class) Power Output Hp: Approx. 30-35 HP (estimated for this class) 🔧 Transmission Drivetrain Type: Hydrostatic Drive System: Tracked 📐 Dimensions Physical Operating Weight Kg: Approx. 2000 - 2300 kg (estimated for this class) Length Overall Mm: Approx. 3500 - 3800 mm (including boom) Width Overall Mm: Approx. 1300 - 1500 mm (over tracks) Height Overall Mm: Approx. 2300 - 2500 mm (to top of cab/ROPS) 🛡️ Safety Features Features Rollover Protection: ROPS (Roll Over Protective Structure) Tip Over Protection: FOPS (Falling Object Protective Structure) - potentially optional or standard depending on configuration 🔧 Maintenance Servicing Engine Oil Capacity Liters: Approx. 5 - 7 Liters (estimated) Hydraulic Oil Capacity Liters: Approx. 30 - 40 Liters (estimated) Coolant Capacity Liters: Approx. 5 - 7 Liters (estimated) 📄 Performance Digging Digging Depth Max Mm: Approx. 2500 - 2800 mm Digging Reach Max Mm: Approx. 4000 - 4300 mm Swing Swing Speed Rpm: Approx. 10 - 12 RPM 📄 Controls Operation Control Type: Pilot-operated hydraulic controls 📄 Under Carriage Tracks Track Width Mm: Approx. 230 - 300 mm
