🏷️ Basic Information Identification Make: Mazda Model: CX-5 Years Covered: 2012, 2013, 2014, 2015 Generation: KE (First Generation) Chassis Codes: KE1FW, KE2FW, KE5FW, KEEAW, KEF4W 👋 Introduction Market Position Vehicle Segment: Compact Crossover SUV Key Selling Points: Stylish design (Kodo design language), engaging driving dynamics, fuel efficiency Competitive Analysis Primary Competitors: Honda CR-V, Toyota RAV4, Nissan Qashqai/Rogue Sport, Ford Escape Key Features Design Philosophy: Mazda's Kodo: Soul of Motion design Driving Dynamics: Skyactiv-Vehicle Dynamics (G-Vectoring Control introduced later in generation, but chassis tuning evident) Manual Value Proposition: Empowers owners to perform maintenance and repairs, saving significant costs 📋 Manual Details Coverage Areas All Models Trims Engines Transmissions: Yes Page Count Estimated Pages: Thousands (typical for comprehensive workshop manuals) Manual Type Type: Workshop Repair and Service Manual Language Language: English Format Format: PDF Download 📖 Manual Coverage Systems Covered Engine Mechanical: Comprehensive (including disassembly, assembly, torque specs, diagnostics) Engine Management: Detailed (fuel injection, ignition, emissions control systems) Transmission Automatic: Complete service and repair procedures Transmission Manual: Complete service and repair procedures Drivetrain: Front-wheel drive (FWD) and All-wheel drive (AWD) systems, differentials, axles Suspension System: Front and rear suspension, shock absorbers, springs, bushings Steering System: Power steering system, steering rack, linkages, alignment specifications Brake System: Hydraulic system, ABS, EBD, brake pads, rotors, calipers, bleeding procedures Electrical System: Complete wiring diagrams, component testing, circuit diagnosis HVAC System: Heating, Ventilation, and Air Conditioning system diagnosis and repair Body And Chassis: Body panel repair, structural components, doors, windows, interior trim Restraint System: Airbag system diagnosis, seatbelts Cooling System: Radiator, hoses, thermostat, water pump, coolant specifications Fuel System: Fuel tank, pump, injectors, pressure specifications Procedures Included Maintenance: Scheduled maintenance, fluid changes, filter replacements Troubleshooting: Diagnostic charts and symptom-based troubleshooting Repair: Step-by-step repair instructions for all major systems Disassembly And Assembly: Detailed procedures for component removal and installation Cleaning And Reinstallation: Procedures for cleaning and reassembling components Diagnostics: Component testing, error code interpretation Technical Depth Depth: Professional Technician Level (covers complex diagnostics and repairs) 📊 Manual Specifications File Format Format: PDF Print Quality Printable: Yes (Full Printable) Zoom: Yes (Zoom IN/OUT capability) Binding Type Binding: Digital Download (N/A for physical binding) Paper Type Paper Type: Digital (N/A for physical paper type) Requirements Reader Software: Adobe PDF Reader Compression Software: WinZip or similar (for potential archive) Compatibility Operating Systems: All Versions of Windows & Mac Delivery Delivery Method: Instant Download ⚙️ Engine Specifications Primary Engine Petrol Engine Code Petrol 1: PE-VPS (2.0L Skyactiv-G) Displacement Petrol 1: 1998 cc Horsepower Petrol 1: Approx. 165 hp (123 kW) @ 6000 rpm Torque Petrol 1: Approx. 150 lb-ft (204 Nm) @ 4000 rpm Engine Code Petrol 2: PY-VPS (2.5L Skyactiv-G) Displacement Petrol 2: 2488 cc Horsepower Petrol 2: Approx. 184 hp (137 kW) @ 5700 rpm Torque Petrol 2: Approx. 185 lb-ft (250 Nm) @ 3250 rpm Primary Engine Diesel Engine Code Diesel: SH-VPTS (2.2L Skyactiv-D) Displacement Diesel: 2191 cc Horsepower Diesel: Approx. 173 hp (129 kW) @ 4500 rpm Torque Diesel: Approx. 310 lb-ft (420 Nm) @ 2000 rpm Performance Fuel Type: Petrol (Gasoline), Diesel (depending on market) Fuel System Injection Type: Direct Injection (Skyactiv-G & Skyactiv-D) Emission Controls: Catalytic converter, EGR (diesel) 🔧 Transmission Standard Type Petrol 2.0: 6-speed manual (FWD) Type Petrol 2.5: 6-speed automatic (FWD/AWD) Optional Type Petrol 2.0: 6-speed automatic (FWD/AWD) Type Diesel 2.2: 6-speed manual (FWD/AWD) Type Diesel 2.2 Auto: 6-speed automatic (FWD/AWD) Features Transmission Fluid Type Auto: Mazda ATF FZ (refer to manual for exact specification and capacity) Transmission Fluid Type Manual: GL-4 SAE 75W-90 Gear Oil (refer to manual for exact specification and capacity) 📐 Dimensions Exterior Length Length Mm: 4555 mm (approx. for 2014 model) Exterior Width Width Mm: 1840 mm (approx. for 2014 model) Exterior Height Height Mm: 1670 mm (approx. for 2014 model) Weights Curb Weight Kg: Approx. 1450-1650 kg (depending on engine and drivetrain) Gvw Kg: Refer to specific vehicle VIN plate Cargo Cargo Volume Liters: Approx. 403 liters (with rear seats up, typical) 🛡️ Safety Features Ratings IIHS Top Safety Pick: Yes (for relevant model years) NHTSA Overall Rating: 5-Star (for relevant model years) Active Features ABS: Standard Ebs: Standard Esc: Standard (Dynamic Stability Control - DSC) Traction Control: Standard Blind Spot Monitoring: Optional (Smart City Brake Support - SCBS available on later models) Passive Features Airbags: Front, side, and curtain airbags (number and type vary by trim) Seatbelts: 3-point ELR seatbelts with pretensioners and load limiters 💡 Technology Features Infotainment Mazda Connect Infotainment: Available on higher trims and later models, featuring a 7-inch touchscreen, Bluetooth, USB connectivity, and navigation. Driver Assistance Adaptive Cruise Control: Available on some later models Smart City Brake Support: Available on some models, operates at lower speeds to help avoid or mitigate collisions. Lane Departure Warning System: Available on some models Connectivity Usb Ports: Standard on most trims Bluetooth: Standard on most trims...
