The Kodiak 700 is a robust All-Terrain Vehicle (ATV) designed for both demanding work and recreational trail riding. Produced for the 2016, 2017, and 2018 model years, this utility ATV is renowned for its powerful 686cc liquid-cooled engine, durable chassis, and signature Ultramatic® Constantly Variable Transmission (CVT). Key features include selectable 4WD, impressive suspension travel, substantial towing capacity of 2000 lbs, and comfortable ergonomics, making it a reliable and capable machine in various off-road conditions. The long-standing reputation for engineering quality and reliability underpins the Kodiak 700's appeal in a competitive market. This comprehensive Workshop Service Repair Manual provides detailed guidance for the maintenance, repair, and troubleshooting of the Kodiak 700 ATV. It covers all major systems, including the powertrain, chassis, and electrical components, with specific sections dedicated to engine, fuel, cooling, transmission, drivetrain, suspension, steering, brakes, and electrical systems. The manual offers step-by-step procedures for routine maintenance tasks, component disassembly and reassembly, diagnostic procedures, and includes essential technical specifications such as torque values and fluid capacities. This resource is invaluable for owners, technicians, and mechanics seeking to ensure the optimal performance, longevity, and safe operation of their Kodiak 700. 🏷️ Basic Information Identification Make: Yamaha Model: Kodiak 700 Vehicle Type: All-Terrain Vehicle (ATV) Product Name: Yamaha Kodiak 700 ATV Complete Workshop Service Repair Manual Generation Covered Years: 2016, 2017, 2018 Codes Product Identifier: Workshop Service Repair Manual 👋 Introduction Market Position Segment: Utility ATV, positioned for serious work and recreational trail riding. Competitive Analysis Competitors: Honda Foreman/Rancher, Polaris Sportsman, Can-Am Outlander/Defender, Kawasaki Brute Force. Key Features Vehicle Highlights: Robust chassis, powerful engine, selectable 4WD, excellent suspension travel, high towing capacity, comfortable ergonomics. Manual Value Proposition Benefit To Owner: Empowers owners to perform routine maintenance, diagnose issues, and tackle complex repairs, saving time and money while ensuring optimal performance and longevity. 📋 Manual Details Coverage Areas Regions Covered: Global (assuming standard service procedures) Page Count Estimated Pages: Extensive (typically 500+ pages for a complete workshop manual) Manual Type Type: Complete Workshop Service Repair Manual Language Language: English Format Format: PDF Download 📖 Manual Coverage Systems Covered Powertrain: Engine, Fuel System, Cooling System, Exhaust System, Transmission, Drivetrain (including differentials, driveshafts, CV joints) Chassis: Frame, Suspension (front and rear), Steering, Brakes, Wheels, Tires Electrical: Ignition System, Charging System (stator, regulator/rectifier, battery), Starting System, Lighting, Instrumentation, Wiring Diagrams, ECU Functions Bodywork And Controls: Body Panels, Seats, Handlebars, Levers, Footpegs, Plastics, Decals Procedures Included Maintenance: Scheduled maintenance checks, oil changes, filter replacements, lubrication, adjustments, spark plug service, valve clearance checks/adjustments Diagnostics: Troubleshooting guides, symptom-based diagnostics, fault code interpretation (if applicable) Repair Overhaul: Component disassembly, inspection, repair, and reassembly for all major systems (e.g., engine rebuild, transmission overhaul, brake caliper service, suspension component replacement) Technical Specifications: Torque specifications, clearances, fluid capacities, electrical specifications, diagnostic parameters Technical Depth Depth: Comprehensive from basic maintenance to complete engine and transmission rebuilds, including detailed troubleshooting and electrical schematics. 📊 Manual Specifications File Format Format: PDF Searchability: Likely text-searchable (common for professionally produced PDFs) Print Quality Quality: High-resolution scans/digital creation, optimized for screen viewing and printing. Binding Type Binding: N/A (Digital Download) Paper Type Paper: N/A (Digital Download) ⚙️ Engine Specifications Primary Engine Type: Liquid-cooled, 4-stroke, SOHC, 4-valve Displacement: 686cc (for the 2016-2018 models) Bore X Stroke: 102.0 mm x 84.0 mm Compression Ratio: 10.1:1 Performance Horsepower: Approx. 45-50 HP (specific figures vary slightly by year/tuning) Torque: Approx. 42-45 lb-ft (specific figures vary slightly by year/tuning) Fuel System Induction: Mikuni 44mm throttle body, EFI (Electronic Fuel Injection) Fuel Type: Unleaded gasoline (87 octane or higher recommended) Cooling System Type: Forced liquid cooling, with fan Lubrication System Type: Wet sump 🔧 Transmission Standard Type: Yamaha Ultramatic® Constantly Variable Transmission (CVT) Drive Modes: H (High), L (Low), N (Neutral), R (Reverse), P (Park) Features Drive System: 2WD/4WD with differential lock (on select models) Final Drive: Shaft drive Fluid Specifications Cvt Fluid: Yamalube® High-Performance UCF Gear Oil or equivalent SAE 10W-40 API SG, SH, SJ, SL or SM engine oil (consult manual for exact specification and change intervals). 📐 Dimensions Exterior Length: Approx. 81.3 inches (2065 mm) Width: Approx. 45.3 inches (1150 mm) Height: Approx. 49.2 inches (1250 mm) Wheelbase: Approx. 50.4 inches (1280 mm) Weights Curb Weight: Approx. 610 lbs (277 kg) (May vary slightly by trim/options) Towing Capacity: 2000 lbs (907 kg) Cargo Capacity Front Rack: 99 lbs (45 kg) Cargo Capacity Rear Rack: 198 lbs (90 kg) Cargo Cargo Storage: Water-resistant storage compartment 🛡️ Safety Features Ratings Atv Safety Standards: Compliant with ANSI standards (ATV safety guidelines) Active Features Braking System: Hydraulic disc brakes (front and rear), often with parking brake mechanism. Engine Braking: Utilizes engine braking via the Ultramatic® CVT for downhill control. Passive Features Roll Over Protection: N/A (ATVs by design require rider skill and awareness; no integrated ROPS) Lighting: Dual halogen headlights, LED taillight/brake light. 💡 Technology...
