🏷️ Basic Information Identification Make: Polaris Model: Sportsman 400 / 500 Sub Model: Xplorer Model Years Covered: 1996, 1997, 1998, 1999, 2000, 2001, 2002, 2003 👋 Introduction Market Position Target Audience: Owners, technicians, and repair shops seeking detailed information for the Polaris Sportsman 400/500 Xplorer. Competitive Analysis Value Proposition: Provides dealer-level repair information at a fraction of the cost of dealership services or physical manuals. Key Features Digital Access: Instant PDF download for immediate access, eliminating shipping delays and costs. 📋 Manual Details Coverage Areas General Coverage: Complete mechanical and electrical service, repair, and maintenance for the specified Polaris Sportsman models. Page Count Total Pages: 504 Manual Type Manual Type: Service Repair Workshop Manual Language Language: English Format File Format: Adobe Acrobat (PDF) 📖 Manual Coverage Systems Covered Engine: Engine overhaul, disassembly, inspection, assembly, specifications, tuning, and troubleshooting. Transmission: Automatic transmission operation, maintenance, repair, and troubleshooting. Drivetrain: Driveshaft, differential, axle repairs, and maintenance. Suspension: Front and rear suspension systems, shock absorbers, control arms, and pivot points. Steering: Steering column, tie rods, steering linkage, and maintenance. Brakes: Hydraulic brake system, calipers, brake lines, master cylinder, and bleeding procedures. Electrical System: Wiring diagrams, ignition system, charging system, starter, lighting, and accessory circuits. Fuel System: Fuel tank, fuel pump, carburetor (or fuel injection for specific models/years), and fuel lines. Cooling System: Radiator, fan, coolant, and thermostat maintenance and repair. Exhaust System: Muffler, exhaust pipes, and catalytic converter (if applicable). Bodywork: Body panel removal and installation, seat, handlebars, and fender repairs. Procedures Included Maintenance: Routine service, oil changes, filter replacements, lubrication, and general upkeep. Troubleshooting: Diagnostic charts and procedures for identifying and resolving common and uncommon issues. Repair: Step-by-step instructions for component replacement and repair across all systems. Rebuild: Complete engine and transmission rebuild procedures with detailed specifications. Diagnostics: Advanced diagnostic techniques for electrical and mechanical problems. Technical Depth Depth Level: Comprehensive, covering everything from basic maintenance to complete engine overhauls and complex electrical diagnostics. 📊 Manual Specifications File Format Searchable: Yes, PDF format allows for text searching of keywords and topics. Print Quality Printability: High-quality, designed to be printed for workshop use. Binding Type Binding Type: N/A (Digital Download) Paper Type Paper Type: N/A (Digital Download) ⚙️ Engine Specifications Primary Engine 400 Engine Type: 4-stroke, Liquid-Cooled, SOHC, 2-Valve Displacement Cc: 375 Bore X Stroke: 83 x 71.4 mm Horsepower Approx: 25-28 HP Torque Approx: 27-29 lb-ft Primary Engine 500 Engine Type: 4-stroke, Liquid-Cooled, SOHC, 2-Valve Displacement Cc: 498 Bore X Stroke: 92.3 x 71.4 mm Horsepower Approx: 33-36 HP Torque Approx: 35-38 lb-ft Fuel System Carburetion: Mikuni BSR (specific model/year variants may exist, covered in manual) Ignition System Type: Electronic Ignition (CDI) 🔧 Transmission Drive System Type: Automatic PVT (Polaris Variable Transmission) with Hi/Lo range and Reverse Engagement: Shaft Drive (AWD/2WD selectable on some models, check manual for specifics) Features Clutch Type: Primary and Secondary CVT clutches Maintenance Belt Inspection Interval: Recommended at 100-hour or 1,200-mile intervals (refer to manual for exact spec) 📐 Dimensions Exterior Length In: Approx. 83 inches (varies slightly by model year) Width In: Approx. 46 inches (varies slightly by model year) Height In: Approx. 49 inches (varies slightly by model year) Weights Dry Weight Lbs: Approx. 550-600 lbs (varies by model/trim) Ground Clearance In: Approx. 8-10 inches (varies by model/trim) Cargo Rack Capacity Front Lbs: Approx. 90 lbs Rack Capacity Rear Lbs: Approx. 170 lbs Wheels Tires Front Tire Size: 25x8-12 (common) Rear Tire Size: 25x10-12 (common) Wheel Bolt Pattern: 4x110 mm (typical for Polaris ATVs of this era) 🛡️ Safety Features Ratings Atv Safety Standards: Meets ANSI and SFI safety standards for ATVs (as applicable per production year). Active Features Braking System: Hydraulic disc brakes front and rear with parking brake. Passive Features Rollover Protection: N/A (ATV design does not include integrated rollover protection structures like ROPS). 💡 Technology Features Infotainment Display Features: Basic digital/analog instrument cluster with speedometer, odometer, fuel gauge, and indicator lights. Driver Assistance Traction Control: N/A (No advanced electronic driver-assistance systems like traction control in this generation). Connectivity Connectivity Features: N/A (No modern connectivity features like Bluetooth or USB ports). 🔧 Maintenance Service Intervals Engine Oil Change: Every 100 hours or annually, whichever comes first. Gearcase Oil Change: Annually or every 100 hours. Spark Plug Check Replace: Check every 100 hours, replace as needed. Air Filter Cleaning: Inspect and clean every 20-30 hours, replace as needed. Fluid Specifications Engine Oil Type: SAE 10W-40, API SG or higher (e.g., Polaris Premium 4 Synthetic 10W-40). Engine Oil Capacity Qts: Approx. 2.1 quarts (refer to manual for exact capacity with filter change). Gearcase Oil Type: SAE 80W-90 GL-5 Gear Lube (e.g., Polaris Gearcase Lube). Gearcase Oil Capacity Ml: Approx. 355 ml (Front & Rear Differentials). Brake Fluid Type: DOT 3 Brake Fluid. Known Issues Cv Joint Wear: CV joint boots can tear, leading to premature wear....
