🏷️ Basic Information Identification Make: GMC Model: C1500 Suburban Year: 1996 Product Type: Service & Repair Manual Software Codes Platform Code: GMT400 👋 Introduction Market Position Positioning: A digital service and repair manual for the DIY enthusiast and professional mechanic, providing factory-derived information. Competitive Analysis Comparison: Offers a modern, convenient, and often more affordable alternative to traditional printed service manuals. Provides instant access and searchability. Key Features Licensing: Officially licensed, derived from OE (Original Equipment) materials. Software Provider: RepairSurge Access Duration: 1 Year included, with discounts for renewal. 📋 Manual Details Coverage Areas Primary Coverage: 1996 GMC C1500 Suburban Secondary Coverage: May include general diagnostic procedures applicable to other GMT400 platform vehicles of similar vintage. Page Count Estimated Pages: N/A (Software based, dynamic content) Manual Type Type: Service and Repair Manual (Software) Language Language: English Format Format: Online access via web browser; PC, laptop, smartphone, tablet compatible 📖 Manual Coverage Systems Covered Engine: All Gasoline Engine Variants (e.g., 5.0L V8, 5.7L V8) Drivetrain: Transmission (Automatic), Transfer Case (4WD), Axles, Driveshafts, Differentials Brakes: Front Disc, Rear Drum/Disc (depending on configuration), ABS System Steering: Power Steering System, Steering Column Suspension: Front Independent Suspension (Torsion Bar), Rear Leaf Spring Suspension Electrical: Full Electrical Schematics, Lighting, Ignition System, Starting System, Charging System, Body Control Modules, Accessories Climate Control: Heating, Ventilation, and Air Conditioning (HVAC) Body: Body and Chassis Repair, Doors, Windows, Seats, Interior Trim Procedures Included Maintenance: Scheduled Maintenance, Fluid Changes, Filter Replacements, Lubrication Diagnostics: Troubleshooting Guides, Symptom-Based Diagnostics, Diagnostic Trouble Codes (DTCs) interpretation Repair: Component Removal and Installation, System Overhauls, Component Rebuilding Specifications: Torque Specifications, Clearances, Adjustments, Dimensional Data Technical Depth Depth: Comprehensive, from basic maintenance to complex engine and transmission repairs, electrical system troubleshooting. 📊 Manual Specifications File Format Accessibility: Web-based, accessible via internet connection and web browser Print Quality Printability: Likely printable pages via browser's print function, quality dependent on user's printer. Binding Type Binding: N/A (Digital Format) Paper Type Paper: N/A (Digital Format) ⚙️ Engine Specifications Primary Engine Engine 1: 5.0L (305 cu. in.) Vortec V8 (L31) Engine 2: 5.7L (350 cu. in.) Vortec V8 (L31) Performance Horsepower 5.0L: Approx. 205 hp @ 4400 RPM Torque 5.0L: Approx. 275 lb-ft @ 3200 RPM Horsepower 5.7L: Approx. 255 hp @ 4600 RPM Torque 5.7L: Approx. 330 lb-ft @ 3200 RPM Fuel System Injection: Multi-port Fuel Injection (MPFI) Fuel Type: Unleaded Gasoline 🔧 Transmission Standard Transmission Type: 4-Speed Automatic (4L60-E) Optional Transmission Type: None specified for this software, but manual may cover different builds. Features Control System: Electronic Control Unit (ECU) controlled. 📐 Dimensions Exterior Wheelbase: 130 inches (approx.) Length: 219.5 inches (approx.) Width: 79.1 inches (approx.) Height: 72.0 inches (approx.) Weights Curb Weight: Approx. 4,800 - 5,300 lbs (varies by configuration) Gvwr: Approx. 6,400 - 7,200 lbs (varies by configuration) 🛡️ Safety Features Ratings NHTSA Ratings 1996: While specific NHTSA ratings for 1996 models are not readily available in a standardized format from that era, GM implemented passive safety features typical for the time. Active Features ABS: Anti-lock Braking System (ABS) available/standard on certain trims. Passive Features Airbags: Driver and Passenger Airbags (standard) Seatbelts: Three-point front seat belts, lap belts in rear. 💡 Technology Features Infotainment Audio System: Factory AM/FM stereo with cassette and optional CD player. Speaker configurations varied by trim level. Driver Assistance Cruise Control: Standard or optional cruise control. Connectivity Diagnostics Interface: OBD-II (On-Board Diagnostics II) compliant, allowing for scan tool diagnostics. 🔧 Maintenance Service Intervals Oil Change: Every 3,000 - 7,500 miles or 6-12 months, depending on oil type and driving conditions (refer to manual for exact OE recommendations). Air Filter Replacement: Every 15,000 - 30,000 miles or as needed based on visual inspection. Spark Plugs Replacement: Typically around 100,000 miles for dedicated platinum or iridium plugs, but check manual for specific recommendations. Fluid Specifications Engine Oil: SAE 5W-30 or 10W-30 (depending on climate), API Service SG or SH classification. Check manual for precise viscosity and API requirements. Coolant: GM Pre-mixed 50/50 Ethylene Glycol Coolant (Green) Transmission Fluid: Dexron III Automatic Transmission Fluid Brake Fluid: DOT 3 (or higher rated) Brake Fluid Known Issues Intake Manifold Gaskets: Leaking intake manifold gaskets, particularly on the 5.0L and 5.7L Vortec engines, causing coolant leaks and potential misfires. Heater Core: Heater core leaks are a common failure, often requiring dashboard removal for replacement. Rear Main Seal: Rear main crankshaft seal leaks can occur over time. 📚 Vehicle History Brand Heritage Heritage: GMC (General Motors Truck Company) has a long history of producing robust trucks and utility vehicles, including the Suburban, one of the longest-running nameplates in automotive history. Model Evolution Generation: This 1996 model is part of the GMT400 platform (1992-1999), representing a significant redesign with more rounded styling and updated powertrains compared to previous generations. Production Manufacturing Location: Primarily Janesville, Wisconsin, USA. 🏆 Awards & Recognition Recognitions Truck Of...
