Basic Information Identification Make: Arctic Cat Model: 650 H1 TRV LE Year: 2007 Trim Level: LE (Limited Edition) Color: Black Vehicle Type: ATV (All-Terrain Vehicle) Codes Transmission Type Code: Automatic Drivetrain Code: 4x4 Chassis Variant Code: TRV (Tandem/Two-Rider Vehicle) Introduction Market Position Atv Segment: Performance-oriented utility ATV with enhanced comfort for two riders. Competitive Analysis Key Competitors 2007: Polaris Sportsman X2, Can-Am Outlander MAX, Yamaha Grizzly 660 Key Features Tandem Seating: TRV designation signifies a factory-configured two-seater model, a significant feature for utility and recreational use. Le Trim: Limited Edition trim typically includes premium features, enhanced styling, or specialized equipment not found on base models. 4X4 Capability: Robust 4x4 drivetrain for superior traction in challenging terrain. Manual Details Coverage Areas Manual Type: Factory Parts Manual Language: English Format: PDF Download Page Count Estimated Page Count: Refer to specific manual for exact count; typically extensive for factory parts catalogs. Manual Coverage Systems Covered Engine And Related Components: Accelerator, Air Intake, Battery and Starter Motor, Cam Chain, Cooling, Crank Balancer, Crankshaft and Piston, Cylinder, Cylinder Head and Camshaft/Valve, Magneto, Oil Filter/Pump, Starter Clutch, Throttle Body, Water Pump Transmission And Drivetrain: Clutch, V-Belt, Drive Train, Gear Shifting, Secondary Drive, Secondary Transmission, Transmission Chassis And Body: Canopy and Taillight, Cargo Box and Tailgate, Console, Floor Panel, Frame and Related Parts, Hood and Headlight, Seat, Tilt Frame Suspension And Steering: Front Suspension, Rear Suspension, Steering, Sway Bar Braking System: Front Brake, Rear and Parking Brake Fuel And Exhaust System: Gas Tank, Engine and Exhaust Electrical System: Wiring Harness Procedures Included Part Identification And Ordering: Detailed illustrations, exploded views, and comprehensive parts lists for accurate ordering and replacement. Assembly And Disassembly: Step-by-step instructions for disassembly and reassembly of major components and systems. Technical Depth Depth Of Coverage: Factory-level detail covering all OEM parts and their relationships within the vehicle's systems. Essential for part identification, replacement, and understanding component integration. Manual Specifications File Format File Type: PDF Accessibility Features: Printable, Zoomable, Searchable Text Software Requirements: Adobe Reader, Foxit Reader, or any compatible PDF reader. Print Quality Illustration Clarity: High-resolution factory illustrations and exploded views. Binding Type Binding: Digital Download (Printable) Paper Type Paper Quality: N/A (Digital Format) Engine Specifications Primary Engine Engine Type: V-Twin, 4-stroke Displacement: 641cc (39.1 cubic inches) Bore X Stroke: Specific dimensions available in service manual, but generally around 76mm x 70mm Cooling System: Liquid-cooled Fuel Induction: Carbureted (likely Mikuni BSR42) Performance Horsepower Est: Approximately 45-50 HP (exact figures often proprietary for ATVs, but consistent with class) Torque Est: Significant low-end torque for pulling power. Fuel System Fuel Type: Unleaded gasoline Fuel Capacity: Typically around 5-6 gallons (19-23 Liters) Transmission Standard Transmission Type: Automatic CVT (Continuously Variable Transmission) Drive Selection: 2WD/4WD with front differential lock (likely electronic activation) Features Transmission Gearing: High and Low range, Reverse, Park Belt Drive: Utilizes a V-belt system for power transmission from the engine to the drive train. Dimensions Exterior Length Est: Approximately 90-100 inches (228-254 cm) for a TRV model. Width Est: Approximately 45-50 inches (114-127 cm) Height Est: Approximately 45-50 inches (114-127 cm) Cargo Front Rack Capacity Est: Typically 100-150 lbs (45-68 kg) Rear Rack Capacity Est: Typically 200-250 lbs (90-113 kg) Weights Dry Weight Est: Approximately 650-750 lbs (295-340 kg) Towing Capacity Est: Typically 1000-1200 lbs (454-544 kg) Safety Features Ratings Atv Safety Standards: Meets ANSI/SVIA standards for Class 1 ATVs. Active Features Braking System Type: Hydraulic disc brakes (front and rear). Engine Braking: CVT system provides some engine braking effect. Passive Features Lighting: Dual halogen headlights, taillight, and brake light. Roll Over Protection: ATVs do not typically have integrated roll cages; rider safety relies on proper operation and protective gear. Technology Features Infotainment Infotainment Features: ATVs of this era typically do not feature advanced infotainment systems. Instrumentation is usually limited to speedometer, odometer, fuel gauge, and indicator lights. Driver Assistance Traction Control: Not typically found on 2007 models; 4x4 and differential lock are the primary traction aids. Connectivity Connectivity Features: No standard connectivity features like Bluetooth or USB ports. Maintenance Service Intervals Oil Change Interval: Typically every 100 hours or 6 months; consult manual for exact specifications. Air Filter Cleaning: Regular inspection and cleaning, especially in dusty conditions. Replace as needed. Spark Plug Replacement: Refer to manual, typically around 100-200 hours or annually. Fluid Specifications Engine Oil Type: API SG or higher, SAE 10W-40 (or 20W-50 depending on climate). Specific Arctic Cat P/N often recommended. Transmission Fluid Type: CVT belt drive systems often use specific CVT fluid or a recommended gear oil. Consult manual for P/N and capacity. Coolant Type: Ethylene glycol-based antifreeze (e.g., 50/50 mix with distilled water). Specific P/N provided in manual. Known Issues Cvt Belt Wear: CVT belts can wear over time and require replacement. Proper maintenance and avoiding excessive slippage prolong belt life. Cooling System Maintenance: Regular flushing and inspection of...
