Audi A4 B5 1997 1998 1999 2000 Workshop Service Repair Manual Pdf
- 정가
- $142.00
- 할인가
- $142.00
- 정가
-
- 단가
- / 단위
Basic Information Identification Make: Audi Model: A4 Chassis Code: B5 Model Years: 1997, 1998, 1999, 2000 Introduction Market Position Segment: Compact Executive Sedan/Wagon Target Audience: Premium segment, appealing to buyers...
Type: car
공급업체:
Sku: 132965
Tags:
Audi
car
Manual
Repair Guide
픽업 사용 가능 여부를 로드할 수 없습니다.
공유
| Basic Information | |
| Identification | |
| Make: | Audi |
| Model: | A4 |
| Chassis Code: | B5 |
| Model Years: | 1997, 1998, 1999, 2000 |
| Introduction | |
| Market Position | |
| Segment: | Compact Executive Sedan/Wagon |
| Target Audience: | Premium segment, appealing to buyers seeking refinement, performance, and quattro capability. |
| Competitive Analysis | |
| Key Competitors: | BMW 3 Series, Mercedes-Benz C-Class, Volvo S40/V40. |
| Key Features | |
| Design Language: | Clean, understated European styling characteristic of Audi. |
| Platform Basis: | Shared platform with Volkswagen Passat B5, but with distinct Audi tuning and features. |
| Quattro AWD: | Availability of the renowned quattro all-wheel-drive system, enhancing traction and stability. |
| Manual Details | |
| Coverage Areas | |
| Manual Type: | Workshop Service Repair Manual |
| Language: | English |
| Format: | |
| Provider Statement: | Used by dealership technicians for maintenance, servicing, diagnosis, and repair. |
| Page Count | |
| Estimated Page Count: | Highly detailed, likely exceeding 2000 pages (typical for comprehensive workshop manuals). |
| Manual Coverage | |
| Systems Covered | |
| Engine Mechanical: | Engine assembly, disassembly, cylinder head, crankshaft, pistons, connecting rods, timing components, lubrication system. |
| Engine Electrical: | Ignition system, fuel injection system (ECU, injectors, sensors), starter system, alternator, battery, wiring diagrams. |
| Transmission Manual: | Clutch, gearbox assembly, shift mechanisms, final drive. |
| Transmission Automatic: | Transmission assembly, valve body, torque converter, electronic control unit (ECU), fluid specifications. |
| Drivetrain: | Front-wheel drive (FWD), quattro all-wheel drive (AWD) system, driveshafts, CV joints, differentials. |
| Suspension: | Front and rear suspension components, shock absorbers, springs, control arms, bushings, wheel bearings. |
| Steering: | Power steering system, steering rack, steering column, alignment specifications. |
| Brakes: | Front and rear brake systems, calipers, rotors, pads, ABS (Anti-lock Braking System), hydraulic system. |
| Body And Chassis: | Body panels, doors, hood, trunk, interior trim, structural components, jacking points. |
| Electrical Systems: | Lighting, instrumentation, HVAC controls, power windows, central locking, audio system, SRS (Supplemental Restraint System) / Airbags. |
| Climate Control: | Air conditioning system, heating system, ventilation, refrigerant, components. |
| Procedures Included | |
| Maintenance Procedures: | Oil changes, filter replacements, spark plug replacement, coolant flush, brake fluid flush, belt inspection/replacement. |
| Diagnostic Procedures: | Troubleshooting guides for common symptoms, fault code interpretation, component testing. |
| Repair Procedures: | Step-by-step instructions for component removal, installation, and overhaul. |
| Overhaul Procedures: | Detailed instructions for engine, transmission, and major component rebuilds. |
| Wiring Diagrams: | Comprehensive electrical schematics for all vehicle systems. |
| Technical Specifications: | Torque values, clearances, fluid capacities, pressure readings. |
| Technical Depth | |
| Diagnostic Tools: | Information on using diagnostic scan tools (e.g., VAG-COM/VCDS) for fault code retrieval and system diagnostics. |
| Precision Measurements: | Detailed measurements for critical engine and chassis components. |
| Special Tools: | Identification and use of specialized tools required for specific repair procedures. |
| Manual Specifications | |
| File Format | |
| PDF Quality: | High-resolution, searchable PDF with clear text and images. |
| Printable: | Printable pages for workshop use. |
| Print Quality | |
| Image Clarity: | Clear, legible diagrams and illustrations. |
| Binding Type | |
| Binding: | Not applicable for PDF format, but implies digital accessibility. |
| Paper Type | |
| Paper Type: | Not applicable for PDF format. |
| Engine Specifications | |
| Primary Engine | |
| Engine Options: | 1.8L Turbocharged I4 (AEB, APU, ARK, AWM), 2.8L V6 (AAH, ACK, ALG, AMX, APR, AQD, AHA), 2.5L I5 (Audi RS4 B5 - AGU/APP/AZR - Not typically covered in standard A4 manuals, but a variant). |
| Engine Codes Detailed: | 1.8T: AEB (150 hp), APU/ARK/AWM (170 hp). 2.8L V6: AAH (172 hp), ACK/ALG/AMX/APR/AQD/AHA (190 hp V6 30v). |
| Performance | |
| Horsepower Range: | 150 hp to 190 hp (excluding RS4 variants). |
| Torque Range: | 164 lb-ft to 210 lb-ft (excluding RS4 variants). |
| Fuel System | |
| Fuel Injection: | Multi-point fuel injection (MPI) for V6, Electronic fuel injection (EFI) with turbocharging for 1.8T. |
| Fuel Type: | Premium Unleaded Gasoline (91 RON or higher recommended). |
| Transmission | |
| Standard | |
| Manual Transmission: | 5-speed manual gearbox. |
| Optional | |
| Automatic Transmission: | 4-speed automatic transmission (e.g., 01V for V6, 01M for 4-cyl) with Tiptronic functionality. |
| Features | |
| Drive Types: | Front-wheel drive (FWD) and quattro all-wheel drive (AWD). |
| Dimensions | |
| Exterior | |
| Length: | Approx. 4516 mm (Sedan) / 4575 mm (Avant). |
| Width: | Approx. 1772 mm. |
| Height: | Approx. 1413 mm (Sedan) / 1452 mm (Avant). |
| Weights | |
| Curb Weight: | Approx. 1370 kg (1.8T FWD) to 1600 kg (2.8 V6 quattro Avant). |
| Gross Vehicle Weight Rating: | Varies by engine and drivetrain configuration. |
| Safety Features | |
| Ratings | |
| NHTSA Crash Test Ratings: | Typically good for its era, though specific ratings may vary by year and test methodology. Refer to original NHTSA data for precise scores. |
| Active Features | |
| ABS: | Standard Anti-lock Braking System (ABS). |
| Esp: | Optional Electronic Stability Program (ESP) available on later models or higher trims. |
| Passive Features | |
| Airbags: | Frontal airbags for driver and passenger, optional side airbags. |
| Seatbelts: | Three-point seatbelts with pretensioners for all occupants. |
| Technology Features | |
| Infotainment | |
| Audio System: | Factory Audi Symphony or Concert stereo systems, often with CD player and cassette, optional Bose premium sound. |
| Navigation: | Optional factory navigation system available on higher trims. |
| Driver Assistance | |
| Cruise Control: | Standard cruise control. |
| Parking Sensors: | Not commonly available for this model year. |
| Connectivity | |
| Bluetooth: | Not standard; aftermarket solutions or dealer-installed options may exist. |
| Aux Input: | Not standard on factory head units; aftermarket adapters are common. |
| Maintenance | |
| Service Intervals | |
| Oil Change Interval: | Typically 5,000-7,500 miles or 6-12 months, depending on driving conditions and oil type. Consult manual for specific recommendations. |
| Timing Belt Replacement: | Crucial for 30v V6 engines (e.g., ACK, ALG). Interval around 75,000-105,000 miles. The 1.8T uses a timing chain (less frequent replacement, but tensioners can fail). |
| Fluid Specifications | |
| Engine Oil: | Refer to manual for specific viscosity (e.g., 5W-40 synthetic, 0W-30 synthetic). Always use high-quality synthetic oil. |
| Coolant: | G12 or G12+ coolant (pink/red) mixed with distilled water. |
| Transmission Fluid Manual: | GL-4 rated gear oil, specific viscosity may vary. |
| Transmission Fluid Automatic: | ATF (Automatic Transmission Fluid) specific to Audi/VW spec, e.g., G 052 162 A2 or equivalent. |
| Brake Fluid: | DOT 4 or DOT 4 Plus brake fluid. |
| Known Issues | |
| Engine 1.8T Coil Packs: | Ignition coil pack failure leading to misfires. |
| Engine 1.8T Piston Washers: | Potential for piston washer failure leading to oil consumption and internal damage (less common on later B5 1.8Ts but possible). |
| Engine V6 Timing Belt: | Critical failure if not replaced at recommended intervals; also tensioners and water pump are common replacements. |
| Engine V6 Oil Flushes: | Sludge buildup can be an issue if oil changes are neglected, especially on the 30v V6. |
| Suspension Components: | Wear in control arm bushings, ball joints, and tie rod ends leading to steering looseness and noise. |
| Cv Boots: | Torn CV boots causing clicking noises during turns and eventual CV joint failure. |
| ABS Sensor Failure: | ABS wheel speed sensor failure can illuminate ABS warning light. |
| Climate Control Eccs: | Climate control unit failures, blower motor resistor issues. |
| Vehicle History | |
| Brand Heritage | |
| Audi Legacy: | Audi has a long history of engineering excellence, known for quattro, advanced quattro, and refined interiors. |
| Model Evolution | |
| B5 Generation: | The B5 generation (1995-2001) marked a significant step forward for Audi in terms of design, technology, and market presence, competing directly with established luxury brands. |
| Production | |
| Manufacturing Locations: | Primary production in Ingolstadt, Germany. |
| Awards & Recognition | |
| Recognitions | |
| Car And Driver 10Best: | Audi A4 (specifically the 1.8T quattro) was a frequent recipient of Car and Driver's 10Best list in the mid-to-late 1990s, praised for its handling, performance, and value. |
| Ratings | |
| Initial Reviews: | Widely praised at launch for its refined interior, solid build quality, and the then-new 1.8T engine's blend of performance and efficiency. |
| Certifications | |
| Tsi Certified: | Manual reflects dealership standards, implying adherence to factory specifications and procedures (though 'TSI Certified' is not an industry standard term for manuals). |
