Manual Coverage
|
|
Systems Covered
|
|
Instrument Cluster:
|
Indicator lights, gauges, driver information center operation
|
|
Entertainment Systems:
|
Audio system operation, radio controls, entertainment options
|
|
Climate Controls:
|
HVAC system operation, automatic climate control, manual controls
|
|
Lighting:
|
Headlight operation, interior lighting, fog lights
|
|
Driver Controls:
|
Steering wheel controls, gear selector, parking brake
|
|
Locks And Security:
|
Door locks, keyless entry, anti-theft system
|
|
Seating And Safety Restraints:
|
Seat adjustment, seat belts, airbag system operation
|
|
Driving Operations:
|
Starting the engine, driving, parking, towing information
|
|
Customer Assistance:
|
Warranty information, roadside assistance, dealer services
|
|
Cleaning And Care:
|
Interior and exterior cleaning procedures
|
|
Maintenance And Specifications:
|
General maintenance guidelines and vehicle specifications
|
|
Engine Compartment:
|
Identification of engine components, fluid fill points
|
|
Engine Oil:
|
Oil type, capacity, and checking procedure
|
|
Battery:
|
Battery maintenance and jump starting procedures
|
|
Fuel Information:
|
Recommended fuel type, octane rating
|
|
Air Filter:
|
Information on air filter replacement (general)
|
|
Part Numbers:
|
Some basic part numbers (e.g., tire size, oil filter, likely not extensive)
|
|
Refill Capacities:
|
Fluid capacities for engine oil, coolant, windshield washer fluid, etc.
|
|
Lubricant Specifications:
|
Specifications for various lubricants and fluids
|
|
Accessories:
|
Information on available factory-installed accessories
|
|
Reporting Safety Defects:
|
Information on reporting safety defects (U.S. only)
|
|
Procedures Included
|
|
Basic Maintenance:
|
Checking fluid levels, tire pressure, basic fluid changes
|
|
Warning Lights:
|
Explanation of dashboard warning lights and their meanings
|
|
Tire Changing:
|
Procedure for changing a flat tire, jack points
|
|
Jump Starting:
|
Correct procedure for jump starting the vehicle
|
|
Fuse Replacement:
|
Locating and replacing fuses
|
|
Technical Depth
|
|
Depth:
|
Owner-level maintenance and operation. Does not cover advanced diagnostics or repair procedures typically found in a service manual.
|
|
Engine Specifications
|
|
Primary Engine
|
|
Engine Option 1 Type:
|
3.5L V6 (LZ9)
|
|
Engine Option 1 Displacement:
|
3.5 Liters / 3500 cc
|
|
Engine Option 1 Horsepower:
|
224 hp @ 6200 rpm
|
|
Engine Option 1 Torque:
|
223 lb-ft @ 3200 rpm
|
|
Engine Option 2 Type:
|
3.6L V6 (HFV6 - High Feature V6)
|
|
Engine Option 2 Displacement:
|
3.6 Liters / 3564 cc
|
|
Engine Option 2 Horsepower:
|
252 hp @ 6300 rpm
|
|
Engine Option 2 Torque:
|
251 lb-ft @ 3200 rpm
|
|
Engine Option 3 Type:
|
3.6L V6 VVT (LLT - Direct Injection)
|
|
Engine Option 3 Displacement:
|
3.6 Liters / 3564 cc
|
|
Engine Option 3 Horsepower:
|
265 hp @ 6300 rpm
|
|
Engine Option 3 Torque:
|
251 lb-ft @ 3200 rpm
|
|
Performance
|
|
Aspiration:
|
Naturally Aspirated
|
|
Fuel System
|
|
Fuel Delivery:
|
Sequential Port Fuel Injection (MPI) for LZ9 and HFV6, Direct Injection (DI) for LLT
|
|
Recommended Fuel:
|
87 octane unleaded gasoline (89 octane recommended for 3.6L LLT for optimal performance)
|
|
Technical Features
|
|
Valve Train:
|
DOHC (Dual Overhead Camshafts), 24 valves
|
|
Cylinder Block Material:
|
Aluminum
|
|
Cylinder Head Material:
|
Aluminum
|
|
Safety Features
|
|
Ratings
|
|
NHTSA Front Impact Driver:
|
5 Stars
|
|
NHTSA Front Impact Passenger:
|
5 Stars
|
|
NHTSA Side Impact Front Driver:
|
5 Stars
|
|
NHTSA Side Impact Front Passenger:
|
5 Stars
|
|
NHTSA Side Impact Rear Driver:
|
5 Stars
|
|
NHTSA Side Impact Rear Passenger:
|
5 Stars
|
|
IIHS Front Offset Crash Test:
|
Good
|
|
IIHS Side Impact Crash Test:
|
Good
|
|
IIHS Rear Impact Crash Test:
|
Good
|
|
Active Features
|
|
ABS:
|
Standard Anti-lock Braking System (ABS)
|
|
Traction Control:
|
Standard Traction Control System (TCS)
|
|
Electronic Stability Control:
|
Standard StabiliTrak Electronic Stability Control (ESC)
|
|
Passive Features
|
|
Airbags:
|
Frontal airbags, side-impact airbags, roof rail airbags (standard or optional depending on trim)
|
|
Seat Belts:
|
3-point seat belts with pretensioners
|
|
Child Seat Anchors:
|
LATCH (Lower Anchors and Tethers for CHildren) system
|
|
Maintenance
|
|
Service Intervals
|
|
Oil Change Interval:
|
Typically every 7,500 miles or 6 months, or as indicated by the oil life monitoring system.
|
|
Tire Rotation Interval:
|
Every 7,500 miles
|
|
Engine Air Filter Replacement:
|
Inspect every 30,000 miles, replace as needed (or every 45,000-60,000 miles as preventative maintenance).
|
|
Cabin Air Filter Replacement:
|
Inspect every 15,000 miles, replace as needed (or every 20,000-30,000 miles).
|
|
Transmission Fluid Change Interval:
|
Inspect regularly, change fluid and filter typically around 100,000 miles, or as per severe service schedule.
|
|
Coolant Replacement:
|
Initial change at 100,000 miles, then every 50,000 miles thereafter (GM Super Coolant).
|
|
Fluid Specifications
|
|
Engine Oil Type:
|
SAE 5W-30, meeting GM dexos1 specification (or API SN/GF-5).
|
|
Engine Oil Capacity:
|
4.5 quarts (4.2 liters) for 3.5L V6; 5.0 quarts (4.7 liters) for 3.6L V6.
|
|
Coolant Type:
|
GM Super Coolant (Orange color, silicate-free, P-OAT based).
|
|
Brake Fluid Type:
|
DOT 3
|
|
Windshield Washer Fluid:
|
Approved washer fluid or water.
|
|
Known Issues
|
|
Common Issue 1:
|
Transmission issues (hesitation, rough shifting) with the 6T70 transmission, especially in earlier models. Maintenance of fluid is critical.
|
|
Common Issue 2:
|
Catalytic converter failures or P0420/P0430 codes.
|
|
Common Issue 3:
|
Water pump leaks on 3.6L V6 engines.
|
|
Common Issue 4:
|
Power steering leaks or pump noise.
|
|
Part Numbers Example
|
|
Oil Filter 3.5L V6 Example:
|
GM Part Number 19179401 or AC-Delco PF46/PF46E
|
|
Oil Filter 3.6L V6 Example:
|
GM Part Number 12621080 or AC-Delco PF64
|
