🏷️ Basic Information Identification Make: Yamaha Model: Star Bolt / Bolt R-Spec Chassis Code: XVS950 Model Years Covered: 2014, 2015, 2016 Vehicle Type: Cruiser Motorcycle 👋 Introduction Market Position Target Audience: Do-it-yourself mechanics, owners seeking to save on dealer labor costs, and motorcycle enthusiasts. Value Proposition Cost Savings: Enables owners to perform routine maintenance and repairs, potentially saving hundreds or thousands in dealership labor costs ($70+ per hour). Key Features Visual Aids: Detailed diagrams, illustrations, photos, and exploded views enhance understanding and ease of repair. Product Benefit Accessibility: Instant download provides immediate access to repair information without shipping delays. 📋 Manual Details Identification Product Name: 2014-2016 Yamaha Star Bolt & Bolt R-Spec XVS950 Factory Service Repair Manual Manual Identifier: LIT-11616-27-30 Coverage Areas: All repair topics including general information, periodic maintenance, fuel system, cooling system, engine top end, engine lubrication system, engine removal/installation, crankshaft/crankcase, transmission, wheels/tires, final drive, brakes, suspension, steering, frame, and electrical system. Page Count Page Count: 580 Manual Type Manual Type: Factory Service Repair Manual Language Language: English Format File Format: PDF Download 📖 Manual Coverage Systems Covered Engine Systems: Engine top end, lubrication system, removal/installation, crankshaft, crankcase. Fuel System: Comprehensive coverage of fuel delivery, injection, and related components. Cooling System: Details on cooling system operation, maintenance, and repair. Drivetrain: Transmission, final drive (belt drive system), wheels, and tires. Braking System: Service procedures for hydraulic brake systems. Suspension Steering: Front and rear suspension components, steering system. Frame Bodywork: Frame structure, body components, and mounting procedures. Electrical System: Wiring diagrams, ignition, lighting, starting system, battery, and electronic components. Procedures Included Maintenance: Periodic maintenance schedules, fluid changes, filter replacements, adjustments. Diagnostics: Troubleshooting guides, diagnostic charts, symptom-to-cause identification. Repair: Step-by-step repair instructions for all major vehicle systems. Disassembly Assembly: Detailed procedures for component removal and reinstallation. Technical Depth Technical Depth: Comprehensive, covering from basic maintenance to in-depth engine and transmission overhauls, electrical troubleshooting, and component diagnostics. 📊 Manual Specifications File Quality Resolution: High Resolution Interactivity Navigation: Easy-to-use clickable menu, bookmarks, keyword searchable. Searchability: Fully keyword searchable text. Printability Print Options: Print one page, one chapter, or the entire manual. Compatibility Operating Systems: Compatible with all versions of Windows & Mac. Software Requirements Reader Requirement: Adobe PDF Reader required. ⚙️ Engine Specifications Primary Engine Engine Type: Air-cooled, 4-stroke, SOHC, 4-valve, V-twin Displacement: 942 cc (57.4 cu. in.) Bore X Stroke: 85 mm x 83 mm Compression Ratio: 9.0:1 Fuel System Fuel Delivery: Fuel injection with twin-spray injectors Ignition Ignition System: TCI (Transistor Controlled Ignition) Lubrication Lubrication Type: Wet sump with oil cooler Performance Horsepower Approx: 58 hp @ 5,500 rpm (estimated, for reference; manual provides detailed performance specs) Torque Approx: 59.9 lb-ft @ 3,000 rpm (estimated, for reference; manual provides detailed performance specs) 🔧 Transmission Gearbox Transmission Type: Constant mesh, 5-speed Clutch Clutch Type: Wet, multiple-disc Final Drive Final Drive Type: Belt drive Gear Ratios Gear Ratios: Detailed in manual 📐 Dimensions Overall Length Overall Length: 2,290 mm (89.9 in) Overall Width Overall Width: 820 mm (32.3 in) Overall Height Overall Height: 1,135 mm (44.7 in) for Bolt R-Spec / 1,095 mm (43.1 in) for standard Bolt Seat Height Seat Height: 690 mm (27.2 in) Wheelbase Wheelbase: 1,570 mm (61.8 in) Ground Clearance Ground Clearance: 130 mm (5.1 in) Weights Wet Weight: Approx. 252 kg (555.7 lbs) for Bolt / 250 kg (551 lbs) for Bolt R-Spec Fuel Capacity: 13 L (3.4 gal) 🛡️ Safety Features Braking System Front Brake: Hydraulic disc, 298 mm Rear Brake: Hydraulic disc, 270 mm Wheels Tires Front Tire: 100/90-19 M/C 57H Rear Tire: 150/80-16 M/C 71H Safety Features ABS: Available on some models/trims (manual will specify if applicable) 💡 Technology Features Engine Technology Valve Train: SOHC (Single Overhead Camshaft) with 4 valves per cylinder, optimized for smooth power delivery and efficiency. Fuel Injection: Advanced fuel injection system with dual injectors per cylinder for precise fuel atomization and optimal combustion. Design Philosophy Style: Minimalist 'Salt Flat Racer' aesthetic with a focus on clean lines and accessible customization. 🔧 Maintenance Service Intervals Initial Service: Typically around 1,000 km (600 miles) for first service, covering oil change, filter check, and basic adjustments. Periodic Maintenance: Detailed schedule provided in the manual, usually every 5,000-10,000 km (3,000-6,000 miles) for major checks, fluid changes, and component inspections. Fluid Specifications Engine Oil Type: Yamalube 20W-40 API SG, SJ, SL, SM or higher, SE recommended. Manual will specify exact grade and API classification. Engine Oil Capacity: Approx. 3.70 L (3.91 US qt) without filter change, 3.90 L (4.12 US qt) with filter change. Manual provides precise capacity. Brake Fluid Type: DOT 4 SAE J1703 or FMVSS 116. Coolant Type: Yamaha-specific liquid-cooled engine coolant or equivalent ethylene glycol-based coolant with deionized water. Final Drive Oil: Not applicable, uses belt drive. Known Issues Common Wear Items: Belt drive components (tension, alignment, replacement), brake pads, tires, and...
