🏷️ Basic Information Identification Make: Jaguar Model: XKR Model Year Range: 2003-2006 👋 Introduction Market Position Positioning: Premium Grand Tourer Competitive Analysis Competitors: Porsche 911, BMW M6, Mercedes-Benz SL-Class, Aston Martin DB9 Key Features Engine: Supercharged 4.2-liter V8 Performance Orientation: High performance, sporty handling, luxurious grand touring comfort Design Era: X100 generation successor, distinct Jaguar styling 📋 Manual Details Coverage Areas Manual Type: Workshop Service Repair Manual Page Count: 1920 Language: English Format: PDF Delivery Method: Instant Download 📖 Manual Coverage Systems Covered Engine: Supercharged V8 (4.2L) Engine Management: Jaguar Electronic Engine Control (JEC) with diagnostics Fuel System: Electronic Fuel Injection (EFI), fuel pump, fuel injectors, fuel pressure regulator Cooling System: Radiator, water pump, thermostat, cooling fan, coolant hoses Ignition System: Coil-on-plug ignition, spark plugs, ignition coils Exhaust System: Exhaust manifolds, catalytic converters, mufflers, exhaust pipes Transmission: ZF 6HP26 Automatic Transmission Transmission Control: Electronic transmission control module (ETC) and shift logic Drivetrain: Rear-wheel drive, driveshaft, differential, axles Suspension: Front and rear independent suspension, adaptive damping, springs, shock absorbers/struts, anti-roll bars Steering: Hydraulic power steering system, steering rack, steering column Brakes: Front and rear ventilated discs, ABS (Anti-lock Braking System), EBD (Electronic Brakeforce Distribution), DSC (Dynamic Stability Control), brake calipers, brake lines, parking brake Wheels And Tires: Wheel specifications, tire pressure monitoring system (TPMS), lug nut torque Body And Chassis: Body structure, panels, doors, hood, trunk, bumpers, weatherstripping Interior: Seating, dashboard, trim panels, airbags, seat belts HVAC: Heating, Ventilation, and Air Conditioning (HVAC) system, climate control, refrigerant, components Electrical System: Battery, alternator, starter motor, wiring diagrams, fuses, relays, lighting (headlights, taillights, interior lights), horn Infotainment System: Audio system, navigation system (if equipped), display unit Security System: Immobilizer, remote keyless entry, alarm system Procedures Included Maintenance: Scheduled maintenance, oil changes, filter replacements, fluid checks and top-ups Troubleshooting: System diagnostics, common fault codes, symptom-based troubleshooting guides Repair: Component removal, disassembly, repair, reassembly, and installation Adjustment: Setting clearances, adjustments for various systems (e.g., throttle body, parking brake) Installation: Step-by-step guides for installing new or replacement parts Disassembly: Detailed instructions for taking components apart Checks: Procedures for verifying the proper function and condition of components Technical Depth Depth: Comprehensive, bumper-to-bumper coverage Detail Level: Includes special tools, service data, precautions, and factory specifications Visuals: Detailed illustrations, exploded diagrams, drawings, and photos Accuracy: Precise measurements, wear limits, and tightening torques 📊 Manual Specifications File Format File Format: PDF Printability: Yes, all pages printable Software Requirement: Adobe Reader Operating System Compatibility: Windows, Mac, Linux OS Searchability: Implied by PDF format, though not explicitly stated as searchable text ⚙️ Engine Specifications Primary Engine Engine Code: AJ34S Configuration: 4.2L (4196cc) DOHC 32-valve V8 Aspiration: Roots-type Supercharger with intercooler Performance Horsepower: 390 hp @ 6100 rpm (approx.) Torque: 399 lb-ft @ 3500 rpm (approx.) Fuel System Fuel Delivery: Sequential Multi-Port Fuel Injection (MPI) Recommended Fuel: Premium Unleaded Gasoline (91 octane or higher) 🔧 Transmission Standard Type: 6-Speed Automatic (ZF 6HP26) Optional Manual Transmission: Not available for XKR models Features Sport Mode: Adaptive shift logic with Sport mode Manual Shifting: Steering wheel mounted paddle shifters or J-gate shifter 📐 Dimensions Exterior Body Styles: Coupe and Convertible Wheelbase: Approx. 102.4 inches (2601 mm) Length: Approx. 187.4 inches (4760 mm) Width: Approx. 71.3 inches (1811 mm) Height: Approx. 52.7 inches (1339 mm) Weights Curb Weight: Approx. 3800 - 3950 lbs (1725 - 1790 kg) depending on body style 🛡️ Safety Features Ratings Crash Test Data: Refer to specific NHTSA/IIHS data for the model years, generally good for the era but detailed data for this manual's specific scope may require separate lookup. Active Features Dynamic Stability Control: Standard (DSC) Traction Control: Standard Anti Lock Brakes: Standard (ABS) Electronic Brakeforce Distribution: Standard (EBD) Brake Assist: Standard Passive Features Airbags: Front airbags, side airbags, and optional curtain airbags (convertible models) Seat Belts: Pre-tensioned seat belts with force limiters 💡 Technology Features Infotainment Display: Touchscreen display for navigation and climate control (often part of the 'Premium' or 'Luxury' packages) Audio System: Premium audio systems available (e.g., Alpine, Bowers & Wilkins on some models/options) Navigation: Optional GPS navigation system Driver Assistance Adaptive Cruise Control: Available as an option on some models. Connectivity Phone Integration: Bluetooth connectivity for hands-free calling available on later models or as an option. 🔧 Maintenance Service Intervals Oil Change Interval: Typically every 10,000 miles or 12 months, whichever comes first (refer to manual for exact specification) Transmission Fluid Change: Check manual; often considered 'lifetime' fluid but periodic checks and changes recommended, especially under severe use. Fluid Specifications Engine Oil Type: Synthetic 5W-30 or 0W-30, API SN or higher, ACEA A5/B5 (consult manual for exact OEM specification and capacity) Coolant Type: Jaguar-specified OAT (Organic Acid Technology) coolant, typically a pink or orange color (e.g., Ford Premium Coolant Gold or equivalent) Brake Fluid Type: DOT 4 or DOT 4 LV (Low Viscosity) (consult manual for specific OEM...
