The 2009 tC is a compact sport coupe designed for younger buyers seeking a stylish, affordable, and reliable vehicle. Built on the XZ10 platform, which spanned from 2004 to 2010, this model offers a blend of sporty aesthetics and practical functionality. It is powered by a 2.4-liter inline-4 cylinder engine producing 158 horsepower and 162 lb-ft of torque, paired with either a 5-speed manual or an optional 5-speed automatic transmission. The tC is recognized for its strong safety ratings, including 5-star NHTSA front and side impact assessments, and generally positive consumer reliability reports. This comprehensive service and repair manual covers the 2009 tC in detail, providing factory-level technical information essential for maintenance and repair. It thoroughly details all major vehicle systems, including the engine, transmission, drivetrain, suspension, steering, brakes, and electrical system. The manual offers step-by-step procedures for routine maintenance, diagnostics, troubleshooting, and complete component overhauls, including engine and transmission rebuilds. With its extensive coverage, this manual serves as an indispensable resource for owners, mechanics, and technicians aiming to maintain the performance, reliability, and longevity of their tC. 🏷️ Basic Information Identification Make: Scion Model: tC Year: 2009 Generation Generation Code: XZ10 Generation Years: 2004-2010 👋 Introduction Market Position Vehicle Segment: Compact Sport Coupe Target Audience: Younger buyers seeking a stylish, affordable, and reliable coupe. Competitive Analysis Key Competitors: Honda Civic Coupe, Mitsubishi Eclipse, Nissan Sentra SE-R. Key Features Manual Advantage: Licensed OE materials ensure accuracy and completeness, offering a significant advantage over generic repair guides. Convenience: Instant online access, compatible with multiple devices, more convenient and cost-effective than outdated printed manuals. Cost Savings: Empowers owners to perform maintenance and repairs themselves, saving significant costs compared to dealership or independent shop labor. Licensing: Officially licensed, guaranteeing the authenticity and integrity of the technical data. 📋 Manual Details Coverage Areas Primary Coverage: 2009 Scion tC Related Years Covered: May include minor variations applicable to adjacent model years of the XZ10 generation. Page Count Estimated Page Count: Extensive, comparable to factory service manuals (typically 1000+ pages). Manual Type Type: Service and Repair Manual Software Language Language: English Format Format: PDF Download (accessible via web browser) 📖 Manual Coverage Systems Covered Engine: Complete engine diagnostics, overhaul, fuel system, ignition system, lubrication system, cooling system, emissions control. Transmission: Manual and Automatic transmission service, diagnosis, repair, and fluid specifications. Drivetrain: Front-wheel drive system, axles, CV joints, differential. Suspension: Front and rear suspension systems, shock absorbers, springs, control arms, bushings, alignment procedures. Steering: Power steering system, steering column, rack and pinion, tie rod ends, steering wheel. Brakes: Front and rear brake systems (disc brakes), ABS, hydraulic components, brake fluid specifications, bleeding procedures. Electrical System: Complete automotive electrical system, battery, charging system, starter, lighting, wipers, power accessories, fuses, relays, wiring diagrams. Climate Control: HVAC system, air conditioning, heater, climate control unit, blower motor, refrigerant R134a. Body And Interior: Body panels, doors, glass, interior trim, seats, airbags, safety restraints. Body And Exterior: Bumpers, fenders, hood, trunk lid, mirrors, exterior trim, lighting fixtures. Procedures Included Maintenance: Scheduled maintenance, oil changes, filter replacements, fluid checks, tire rotation, spark plug replacement. Troubleshooting: Diagnostic procedures for common and complex issues, symptom-based troubleshooting guides, error code explanations. Repair: Step-by-step repair instructions for all major vehicle systems, including component removal, installation, and adjustment. Diagnostics: OBD-II diagnostic codes and procedures, advanced electronic diagnostics. Rebuilds: Detailed instructions for engine and transmission rebuilds, including specifications and tolerances. Technical Depth Depth Level: Factory-level technical information, suitable for professional technicians and advanced DIY enthusiasts. 📊 Manual Specifications File Format Format: PDF Searchability: Likely text-searchable for quick information retrieval. Print Quality Print Ability: Printable pages for offline use or step-by-step repair guidance. Binding Type Binding: N/A (Digital format) Paper Type Paper Quality: N/A (Digital format) ⚙️ Engine Specifications Primary Engine Engine Code: 2AZ-FE Engine Type: Inline-4 Cylinder, DOHC, 16-Valve Displacement: 2.4 Liters (2362 cc) Bore X Stroke: 88.5 mm x 96.0 mm Compression Ratio: 9.8:1 Performance Horsepower: 158 hp @ 6000 rpm Torque: 162 lb-ft @ 4000 rpm Fuel System Fuel Delivery: Electronic Fuel Injection (EFI) with Sequential Port Injection Fuel Type: Unleaded Gasoline (87 Octane Recommended) Engine Management ECU: Toyota ECM (likely Denso) 🔧 Transmission Standard Type: 5-Speed Manual Optional Type: 5-Speed Automatic (with Sequential Shift Mode) Features Automatic Features: Artificial intelligence shift control (AI-Shift) for adaptive shifting. Fluid Specifications Manual Transmission Fluid: API GL-4, SAE 75W-90 (Specific Toyota specification may be required). Automatic Transmission Fluid: Toyota ATF WS (World Standard) or equivalent. 📐 Dimensions Exterior Length: 170.1 inches Width: 69.1 inches Height: 56.7 inches Wheelbase: 106.3 inches Weights Curb Weight Manual: Approx. 3,042 lbs Curb Weight Automatic: Approx. 3,086 lbs Gross Vehicle Weight Rating: Approx. 3,880 lbs 🛡️ Safety Features Ratings NHTSA Front Impact: 5-Star (Driver and Passenger) NHTSA Side Impact: 5-Star (Front and Rear Passengers) IIHS Front Crashworthiness: Good Active Features ABS: Standard Anti-lock Braking System Traction...
