🏷️ Basic Information Identification Make: Suzuki Model: X-90 Year: 1997 Codes Chassis Code: EL90 Vin Prefix: JS3 👋 Introduction Market Position Segment: Subcompact Crossover SUV / Sport Utility Vehicle Niche: Known for its distinctive compact, two-door, convertible-like design (removable roof panel) and sporty, off-road capable persona. Competitive Analysis Key Competitors: While unique, it competed in a segment with vehicles like the Geo Tracker, Daihatsu Sportrak (Rocky), and small Jeep models. Key Features Distinctive Design: Removable roof panel (often called a 'targa' top), compact 2-door configuration, high ground clearance, and a distinctive styling. Drivetrain Options: Available in 2WD and 4WD (with selectable 4WD system). Target Audience Target Demographic: Enthusiasts seeking a unique, compact, and somewhat capable off-road vehicle, often favored by younger buyers or those looking for a fun, quirky vehicle. 📋 Manual Details Coverage Areas Primary Coverage: 1997 Suzuki X-90 Related Models Covered: Likely covers variations and specific configurations for the 1997 model year. Page Count Estimated Page Count: Extensive (exact count not specified, but typical for a full service manual). Online format provides dynamic content. Manual Type Type: Service and Repair Manual Software Language Language: English Format Format: Online Software (Web Browser Accessible) 📖 Manual Coverage Systems Covered Powertrain: Engine, Drivetrain (Transmission, Differentials, Axles) Chassis: Suspension, Steering, Brakes, Wheels, Tires Electrical: Engine Control Module (ECM), Body Control Module (BCM), Lighting, Instruments, Audio, HVAC Controls, Wiring Diagrams Body: Body Panels, Doors, Glass, Interior Trim, HVAC System Procedures Included Maintenance: Scheduled maintenance, fluid changes, filter replacements, inspections Repair: Engine overhaul, transmission repair, brake component replacement, suspension component overhaul, steering system repair, electrical component troubleshooting and replacement, bodywork repair Diagnostics: Troubleshooting guides, diagnostic trouble codes (DTCs) interpretation (if applicable to the era), symptom-based diagnostics Technical Depth Depth: Comprehensive, from basic maintenance to detailed engine and transmission rebuilds. Licensed OE materials imply factory-level detail. 📊 Manual Specifications File Format Online Accessibility: Accessible via web browser on PC, laptop, smartphone, or tablet with internet connection. Print Quality Print Quality: N/A (Online software, printable sections may vary in quality). Binding Type Binding Type: N/A (Digital Format) Paper Type Paper Type: N/A (Digital Format) Access Duration Access Duration: 1 Year (with options for extension/discounted renewals). ⚙️ Engine Specifications Primary Engine Engine Type: Inline 4-Cylinder Engine Code: G16A Displacement: 1.6 Liters (1590 cc) Valvetrain: SOHC (Single Overhead Camshaft), 16 Valves Performance Horsepower: Approx. 95 hp @ 5600 rpm Torque: Approx. 105 lb-ft @ 3000 rpm Fuel System Fuel Delivery: Multi-point Fuel Injection (MPI) Fuel Type: Unleaded Gasoline (87 Octane Recommended) Cooling System Coolant Type: Ethylene Glycol based, typically a 50/50 mix with distilled water. Refer to manual for specific Suzuki coolant specification. 🔧 Transmission Standard Transmission Type: 5-speed Manual Transmission Optional Transmission Type: 4-speed Automatic Transmission Features Transfer Case: 2-speed Transfer Case with selectable 2WD/4WD (on 4WD models) Fluid Specifications Manual Transmission Fluid: API GL-4, SAE 75W-90 Gear Oil. Capacity approx. 2.5 liters. Automatic Transmission Fluid: Dexron II or equivalent. Capacity approx. 5.5 liters. 📐 Dimensions Exterior Length: Approx. 3740 mm (147.2 in) Width: Approx. 1695 mm (66.7 in) Height: Approx. 1620 mm (63.8 in) Wheelbase: Approx. 2060 mm (81.1 in) Weights Curb Weight Min: Approx. 1070 kg (2359 lbs) Curb Weight Max: Approx. 1150 kg (2535 lbs) Gross Vehicle Weight Rating Gvwr: Not readily available, but typical for this class. Cargo Cargo Volume: Limited due to compact nature, especially with rear seats in place. 🛡️ Safety Features Ratings NHTSA Rating: No specific NHTSA ratings easily available for this model year and niche vehicle. Active Features ABS: Available on some models (typically 4WD variants). Passive Features Airbags: Driver and Passenger Frontal Airbags Seat Belts: 3-point seat belts with pretensioners for front occupants. Lap belts for rear passengers. 💡 Technology Features Infotainment Audio System: Basic AM/FM stereo with cassette player, optional CD player. Limited speaker count. Driver Assistance Cruise Control: Optional on some higher trim levels. Connectivity Connectivity Features: None beyond basic audio system and potentially a power outlet. 🔧 Maintenance Service Intervals Oil Change: Every 5,000 miles or 6 months, whichever comes first. Air Filter Replacement: Every 15,000 miles or 12 months. Spark Plug Replacement: Every 30,000 miles (use specified NGK spark plugs, e.g., NGK BKR6E). Coolant Flush: Every 30,000 miles or 24 months. Fluid Specifications Engine Oil Type: SAE 10W-30 API SG or higher. Capacity approx. 3.6 liters (3.8 US quarts) with filter change. Brake Fluid Type: DOT 3. Power Steering Fluid Type: ATF Dexron II or equivalent (if equipped with power steering). Known Issues Common Wear Items: Front and rear suspension bushings, catalytic converter (due to age/heat), clutch wear (manual transmission), minor electrical gremlins. Rust Prone Areas: Wheel wells, rocker panels, chassis frame components, especially in corrosive climates. 📚 Vehicle History Brand Heritage Suzuki SUV History: Suzuki has a long history of producing small, capable off-road vehicles, including the popular Samurai and Sidekick/Vitara lines, which...
